SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS35
The driver ’s seat belt pretensioner is
designed to be activated in response to
a severe frontal impact.
When the airbag sensor detects the shock
of a severe frontal impact, the driver ’s
seat belt is quickly drawn back in by the
retractor so that the belt snugly restrains
the driver.
Collisionsoccurring at certain speeds and
angles may cause the seat belt preten-
sioner and SRS airbag not to operate all
together.This indicator comes on when the en-
gine switch is turned to the “ON” posi-
tion. It goes off after about 6 seconds.
This means the driver ’s seat belt pre-
tensioner is operating properly.
This warning light system monitors the
airbag sensor assembly, airbag sensor,
driver ’s seat belt pretensioner assembly,
inflator, interconnecting wiring and power
sources. (For details, see “Service remind-
er indicators and warning buzzer” on page
73 in Section 1−5.)
Dyna100/150_EE
—Driver’s seat belt
pretensioner

36SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
The driver ’s seat belt pretensionersystem
mainly consists of the following compo-
nents and their locations are shown in the
illustration.
1. SRS warning light
2. Airbag sensor
3. Driver ’s seat belt pretensioner assem-
bly
4. Airbag sensor assembly
The driver ’s seat belt pretensioner is con-
trolled by the airbag sensor assembly. The
airbag sensor assembly consists of a saf-
ing sensor and airbag sensor.
When the driver ’s seat belt pretensioner is
activated, an operating noise may be
heard and a small amount of smoke−like
gas may be released. This gas is harm-
less and does not indicate that a fire is
occurring.
Once the driver ’s seat belt pretensioner
has been activated, the seat belt retractor
remains locked.
If the vehicle is involved in multiple colli-
sions, the pretensioner will activate for the
first collision, but will not activate for the
second or subsequent collisions.
CAUTION
Observe the following precautions to
reduce the risk of injury in the event
of sudden braking or an accident.
Failure to do so may cause death or
serious injury.
DIf the pretensioner has activated,
the SRS warning light will come on.
In that case, the seat belt cannot
be used again and must be re-
placed at any authorized Toyota
dealer or repairer, or another duly
qualified and equipped professional.
DDo not modify, remove, strike or
open the seat belt pretensioner as-
semblies, airbag sensor or sur-
rounding area or wiring. Consult
any authorized Toyota dealer or re-
pairer, or another duly qualified and
equipped professional about any re-
pair and modification.
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS37
NOTICE
Do not perform any of the following
changes without consulting any autho-
rized Toyota dealer or repairer, or
another duly qualified and equipped
professional. Such changes can inter-
fere with proper operation of the
driver ’s seat belt pretensioner in
some cases.
zInstallation of electronic devices
such as an RF−transmitter, cassette
tape player or compact disc player
zRepairs on or near the driver ’s seat
belt retractor assembly
zModification of the suspension sys-
tem
zModification of the front end struc-
ture
zAttachment of a grille guard (bull
bar, kangaroo bar, etc.), snowplow,
winches or any other equipment to
the front end
zRepairsmadeonornearthefront
end structure or console
This driver ’s seat belt pretensionersystem
has a service reminder indicator to inform
the driver of operating problems. If any of
the following conditions occurs, this
indicates a malfunction of the airbag or
pretensioner. Contact any authorized
Toyota dealer or repairer, or another duly
qualified and equipped professional, as
soon as possible to service the vehicle.
DThe light does not come on when the
engine switch is turned to the “ON”
position or remains on for more than
6 seconds or flashes.
DThe light comes on or starts flashing
while driving.
DIf the driver ’s seat belt does not retract
or cannot be pulled out due to a mal-
function or activation of the relevant
driver ’s seat belt pretensioner.
Dyna100/150_EE

38SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
In the following cases, contact any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
as soon as possible:
DThe front of the vehicle (shaded in the
illustration) was involved in an accident
that was not severe enough to cause
the driver ’s seat belt pretensioner to
operate.
DThe driver ’s seat belt pretensioner as-
sembly or surrounding area is
scratched, cracked, or otherwise dama-
ged.
The SRS (Supplemental Restraint Sys-
tem) airbag is designed to provide fur-
ther protection for the driver in addition
to the primary safety protection pro-
vided by the seat belt.
In response to a severe frontal impact,
the SRS airbag works together with the
seat belt to help reduce injury by inflating.
The SRS airbag helps to reduce injuries
mainly to the driver ’s head or chest
caused by directly hitting the steering
wheel.
Be sure to wear your seat belt properly.
CAUTION
The driver who is too close to the
steering wheel during airbag deploy-
ment can be killed or seriously in-
jured. Toyota strongly recommends
that:
DThe driver sit as far back as pos-
sible from the steering wheel while
still maintaining control of the ve-
hicle.
DAll vehicle occupants must be prop-
erly restrained using the available
seat belts.
Dyna100/150_EE
SRS driver airbag

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS39
This indicator comes on when the en-
gine switch is turned to the “ON” posi-
tion. It goes off after about 6 seconds.
This means the SRS airbag is operating
properly.
This warning light system monitors the
airbag sensor assembly, airbag sensor,
driver ’s seat belt pretensioner assembly,
inflator, interconnecting wiring and power
sources. (For details, see “Service
reminder indicators and warning buzzer”
on page 73 in Section 1−5.)The SRS airbag system is designed to
activate in response to a severe frontal
impact within the shaded area between
the arrows in the illustration.
The SRS airbag will deploy in the event
of an impact that exceeds the set thresh-
old level (the level of force corresponding
to an approximately 20−30 km/h [12−18
mph] frontal collision with a fixed wall that
does not move or deform).
If the severity of the impact is below the
above threshold level, the SRS airbag
may not deploy.
However, this threshold velocity will be
considerably higher if the vehicle strikes
an object, such as a parked vehicle or
sign pole, which can move or deform on
impact, or if it is involved in an underride
collision (e.g. a collision in which the nose
of the vehicle “underrides”, or goes under,
the bed of a truck, etc.).
It is possible that in some collisions at the
lower zone of airbag sensor detection and
activation the SRS airbag and seat belt
pretensioner will not operate all together.
For the safety of all occupants, always
wear your seat belts properly.
Dyna100/150_EE

40SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
Collision from the rear
Collision from the side
Vehicle rollover
The SRS airbag is not designed to in-
flate if the vehicle is involved in a side
or rear collision, if it rolls over, or if
it is involved in a low−speed frontal
collision.
Hitting a curb,
edge of pavement
or hard materialFalling into or
jumping over
a deep hole
Landing hard or vehicle falling
The SRS airbag may deploy if a serious
impact occurs to the underside of your
vehicle. Some examples are shown in
the illustration.
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS41
The SRS airbag system consists mainly of
the following components, and their loca-
tions are shown in the illustration.
1. SRS warning light
2. Airbag module for driver
(airbag and inflator)
3. Airbag sensor
4. Airbag sensor assembly
The airbag sensor assembly consists of a
safing sensor and airbag sensor.
In a severe frontal impact, the sensor de-
tects deceleration and the system triggers
the airbag inflator. At this time a chemical
reaction in the inflator quickly fills the air-
bag with non−toxic gas to help restrain
the forward motion of the driver.
When the airbag inflates, it produces a
fairly loud noise and releases some
smoke and residue along with non−toxic
gas. This does not indicate a fire. This
gas is normally harmless; however, for
those who have delicate skin, it may
cause a minor skin irritation. Be sure to
wash off any residue as soon as possible
to prevent any potential skin irritation.
Deployment of the airbag happens in a
fraction of a second, so the airbag must
inflate with considerable force. While the
system is designed to reduce serious inju-
ries, it may also cause minor burns or
abrasions and swelling.The steering wheel hub may be hot for
several minutes, but the airbag itself will
not be hot. The airbag is designed to
inflate only once.
CAUTION
The SRS airbag system is designed
only as a supplement to the primary
protection of the driver side seat belt
system. The driver can be killed or
seriously injured by the inflating air-
bag if he/she does not wear the avail-
able seat belt properly. During sudden
braking just before a collision, an un-
restrained driver can move forward
into direct contact with or close prox-
imity to the airbag which may then
deploy during the collision. To ensure
maximum protection in an accident,
the driver and all passengers in the
vehicle must wear their seat belts
properly. Wearing a seat belt properly
during an accident reduces the
chances of death or serious injury or
being thrown out of the vehicle. For
instructions and precautions concern-
ing the seat belt system, see “Seat
belts” on page 28 in this Section.
Dyna100/150_EE

42SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
CAUTION
DDo not put objects or your pets on
or in front of the steering wheel
pad. They might restrict inflation or
cause death or serious injury as
they are projected rearward by the
force of a deploying airbag. Like-
wise, the driver should not hold ob-
jects in his/her arms or on his/her
knees.
DDo not modify or remove any wir-
ing. Do not modify, remove, strike
or open any components such as
the steering wheel pad, steering
wheel, column cover or airbag sen-
sor assembly. Doing so may cause
sudden SRS airbag inflation or dis-
able the system, which could result
in death or serious injury.
Failure to follow these instructions
can result in death or serious injury.
Consult any authorized Toyota dealer
or repairer, or another duly qualified
and equipped professional, about any
repairs and modifications.
NOTICE
Do not perform any of the following
changes without consulting any
authorized Toyota dealer or repairer,
or another duly qualified and
equipped professional. Such changes
can interfere with proper operation of
the SRS airbag system in some cases.
zInstallation of electronic devices
such as an RF−transmitter, cassette
tape player or compact disc player
zModification of the suspension sys-
tem
zModification of the front end struc-
ture
zAttachment of a grille guard (bull
bar, kangaroo bar, etc.), snowplow,
winches or any other equipment to
the front end
zRepairsmadeonornearthefront
end structure, console, steering col-
umn or steering wheel
Dyna100/150_EE

SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS43
This SRS airbag system has a service
reminder indicator to inform the driver of
operating problems. If either of the follow-
ing conditions occurs, this indicates a mal-
function of the airbag. Contact any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
as soon as possible to service the ve-
hicle.
DThe light does not come on when the
engine switch is turned to the “ON”
position or remains on for more than
6 seconds or flashes.
DThe light comes on or starts flashing
while driving.
In the following cases, contact any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
as soon as possible:
DThe SRS airbag has been inflated.
DThe front of the vehicle (shaded in the
illustration) was involved in an accident
that was not severe enough to cause
the SRS airbag to inflate.
DThe pad section of the steering wheel
(shaded in theillustration) is scratched,
cracked, or otherwise damaged.
Dyna100/150_EE

44SEATS, SEAT BELTS, STEERING WHEEL AND MIRRORS
Toyota strongly urges the use of child
restraint systems for children small
enough to use them.
If a child is too large for a child restraint
system, the child should sit in the seat
and must be restrained using the vehicle’s
seat belt. See “Seat belts” on page 28 for
details.
CAUTION
DFor effective protection in automo-
bile accidents and sudden stops, a
child must be properly restrained,
using a seat belt or child restraint
system depending on the age and
size of the child. Holding a child in
your arms is not a substitute for a
child restraint system. In an acci-
dent, the child can be crushed
against the windshield, or between
you and the vehicle’s interior.
DSingle cab models
—
Toyota strongly urges use of a
proper child restraint system which
conforms to the size of the child.
Double cab models

—
Toyota strongly urges use of a
proper child restraint system which
conforms to the size of the child,
installed on the rear seat.
According to accident statistics, the
child is safer when properly
restrained in the rear seat than in
the front seat.
DMake sure you have complied with
all installation instructions provided
by the child restraint manufacturer
and that the system is properly se-
cured. If it is not secured properly,
it may cause death or serious injury
to the child in the event of a sud-
den stop, sudden swerve or acci-
dent.

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Dyna100/150_EE
Child restraint—
—Child restraint precautions
