OTHER EQUIPMENT105
CAUTION
Observe the following precautions.
Failure to do so may cause the driv-
er ’s floor mat to slip, possibly inter-
fering with the pedals while driving.
An unexpectedly high speed may re-
sult or it may become difficult to
stop the vehicle, leading to a serious
accident.
When installing the driver’s floor mat:
DDo not use floor mats designed for
other models or different model
year vehicles, even if they are
Toyota Genuine floor mats.
DOnly use floor mats designed for
the driver ’s seat.
DDo not use two or more floor mats
on top of each other.
DDo not place the floor mat bottom−
side up or upside−down.
Before driving:
DEnsure that the floor mat has been
placed correctly.
DWith the engine stopped and the
shift lever in neutral, fully depress
each pedal to the floor to make
sure it does not interfere with the
floor mat.
Dyna100/150_EE

106OTHER EQUIPMENT
Dyna100/150_EE

INFORMATION BEFORE DRIVING YOUR TOYOTA107
Section 2
INFORMATION BEFORE DRIVING YOUR
TOYOTA
DBreak−in period 108...................................
DFuel 108..............................................
DOperation in foreign countries 110.......................
DDPF system 110.......................................
DEngine exhaust cautions 114...........................
DFacts about engine oil consumption 115.................
DBrake system 116.....................................
DBrake pad wear indicators 119..........................
DLuggage stowage precautions 119......................
DLimited−slip differential 120.............................
DYour Toyota’s identification 120.........................
DSuspension and chassis 122............................
Dyna100/150_EE

108INFORMATION BEFORE DRIVING YOUR TOYOTA
Drive gently and avoid high speeds.
Your vehicle does not need an elaborate
break−in. But following a few simple tips
for the first 1000 km (600 miles) can add
to the future economy and long life of
your vehicle:
DAvoid full throttle acceleration when
starting and driving.
DAvoid racing the engine.
DTry to avoid hard stops during the first
300 km (200 miles).
DDo not drive slowly with the manual
transmission in a high gear.
DDo not drive for a long time at any
single speed, either fast or slow.
DDo not tow a trailer during the first 800
km (500 miles).Selecting the proper fuel is essential
for satisfactory engine performance.
Engine damage caused by use of improp-
er fuels is not covered under Toyota’s new
vehicle warranty.
NOTICE
zDo not use improper fuels. If im-
proper fuels are used the engine
will be damaged.
zDo not use a fuel that contains
more than 50 ppm of sulfur. Use of
such a high sulfur fuel may damage
the engine.
zEU area: FAME (Fatty Acid Methyl
Ester) fuel sold under names such
as “B30” or “B100” and fuel
containing a large amount of FAME
should not be used. The use of
these fuels will damage the ve-
hicle’s fuel system. In case of any
doubt, ask any authorized Toyota
dealer or repairer, or another duly
qualified and equipped professional.
zExcept EU area: FAME (Fatty Acid
Methyl Ester) fuel sold under names
such as “B30” or “B100” and fuel
containing a large amount of FAME
should not be used. Your vehicle
can use diesel mixed with 5% max
biodiesel FAME (B5). The use of
fuel with more than 5% FAME con-
tent (B5) will damage the vehicle’s
fuel system. You must ensure that
refueling is carried out only from a
source where fuel specification and
quality can be guaranteed. In case
of any doubt, ask any authorized
Toyota dealer or repairer, or anoth-
er duly qualified and equipped pro-
fessional.
Dyna100/150_EE
Break−in period Fuel

INFORMATION BEFORE DRIVING YOUR TOYOTA109
FUEL TYPE
Use only diesel fuel.
EU area:
Your vehicle must use only diesel fuel
conforming to European standard
EN590.
Except EU area:
Your vehicle must use only diesel fuel
that contains 50 ppm or less of sulfur
and has a cetane number of 48 or
higher.
CETANE NUMBER
Select cetane number 48 or higher.
Use of fuel with a cetane number lower
than stated will cause persistent heavy
knocking. If severe, this will lead to en-
gine damage.
If your engine knocks...
If you detect heavy knocking even when
using the recommended fuel, or if you
hear steady knocking while holding a
steady speed on level roads, consult any
authorized Toyota dealer or repairer, or
another duly qualified and equipped pro-
fessional.
However, occasionally, you may notice
light knocking for a short time while accel-
erating or driving up hills. This is normal
and there is no need for concern.FUEL TANK CAPACITY
L (gal., Imp. gal.)
Model

Fuel tank capacity
KDY22160 (15.9, 13.2)
KDY231
KDY25180 (21.1, 17.6)
KDY261

: See “Model code” on page vi in the
beginning of this manual if you are not
sure of your vehicle model.
Dyna100/150_EE

11 0INFORMATION BEFORE DRIVING YOUR TOYOTA
If you plan to drive your Toyota in
another country...
First,comply with the vehicle registration
laws.
Second,confirm the availability of the cor-
rect fuel.The DPF (Diesel Particulate Filter) sys-
tem is designed to reduce the deposit
in diesel engine exhaust gases by trap-
ping the deposit in the filter. The sys-
tem performs automatic regeneration to
burn off the deposit trapped in the fil-
ter.
Regeneration
Regeneration is performed as necessary
in accordance with driving conditions.
System characteristics
The DPF system has the following charac-
teristics:
DIdle speed increases during regenera-
tion.
DThe smell of the exhaust gas differs
from that of a conventional diesel ve-
hicle.
Dyna100/150_EE
Operation in foreign
countriesDPF system

INFORMATION BEFORE DRIVING YOUR TOYOTA111
DPF system indicator light
If the DPF system indicator light comes
on, the deposit built up in the filter needs
to be regenerated. To regenerate the filter,
the following driving methods are recom-
mended:
DDriving continuously (for example, driv-
ing at approximately 60 km/h [36 mph]
for approximately 20 minutes).
DAvoiding short trips, or by driving con-
tinuously (leaving the engine running
for long periods of time).
DPerform manual regeneration. (with the
DPF system manual regeneration
switch)
The DPF indicator light will extinguish
when regeneration is complete. However,
if this driving cannot be carried out, or if
the light does not extinguish even after
driving, have the vehicle inspected by any
authorized Toyota dealer or repairer, or
another duly qualified and equipped pro-
fessional immediately.
When driving, pay sufficient attention to
weather, road condition, terrain and traffic
conditions, and drive according to traffic
laws.If the DPF system indicator light flashes

,
perform the following operations:

: The deposit built up in the filter needs
to be regenerated.
Without the DPF system manual regen-
eration switch—Have the vehicle in-
spected by any authorized Toyota dealer
or repairer, or another duly qualified and
equipped professional immediately.
With the DPF system manual regenera-
tion switch—Perform manual regeneration
or have the vehicle inspected by any au-
thorized Toyota dealer or repairer, or
another duly qualified and equipped pro-
fessional immediately. If regeneration is
not performed and you continue to drive
for a while, the malfunction indicator light
will come on. When the malfunction indi-
cator comes on, manual regeneration can-
not be performed.
Under the following driving conditions, the
DPF system indicator light may come on
earlier than normal.

:
DWhen only driving at low speeds (for
example 20 km/h [12 mph] or below).
DIf the engine is turned on and off fre-
quently (for example, the engine is not
left running for more than 10 minutes
at a time).

: Differs in accordance with weather,
driving condition, etc.
For the manual regeneration procedure,
refer to the following instructions.
Dyna100/150_EE

11 2INFORMATION BEFORE DRIVING YOUR TOYOTA
Manual regeneration switch
With the DPF system manual regenera-
tion switch—
To start manual regeneration:
1. Stop the vehicle in a safe place with
the engine running.
Make sure that there are no flammable
materials near the exhaust pipe.
2. Shift the transmission into neutral
and apply the parking brake.
3. Push the manual regeneration
switch.
The DPF system indicator light and the
indicator light on the switch will change
from solid or rapid flashing to slow flash-
ing. The engine idle speed will increase.
In 15 to 40

minutes, manual regeneration
will be completed and the lights will go
off. The engine idle speed will be reduced.

: Differs in accordance with the outside
temperature.
Do not depress the accelerator or clutch
pedal after pressing the DPFsystem
manual regeneration switch. Doing so will
stop manual regeneration. If manual re-
generation is stopped, perform manual re-
generation again as soon as possible.
If the engine and exhaustsystem are hot,
such as after driving, manual regeneration
will take less time.
CAUTION
DBe careful not to touch the hot ex-
haust system and stay away from
exhaust gases. During regeneration,
the exhaust gases become hotter
than usual. Never leave flammable
items near the exhaust system.
DDo not drive, idle or park your ve-
hicle over anything that might burn
easily such as grass, leaves, paper
or rags.
Dyna100/150_EE

INFORMATION BEFORE DRIVING YOUR TOYOTA11 3
NOTICE
To prevent damage to the system and
a fire hazard, observe the following
precautions:
zUse only diesel fuel.
zDo not drive for long periods of
time while the DPF system indicator
light is flashing.
zDo not use fuel other than the spe-
cified type.
zDo not use engine oil other than
the recommended type.
zDo not modify the exhaust pipe.
zOperating the vehicle when the en-
gine oil contains a significant
amount of diesel fuel may result in
damage to the engine. If a signifi-
cant amount of fuel is present,
change the oil as soon as possible.
zDo not drive with an extremely low
fuel level; running out of fuel could
cause the engine to misfire, creat-
ing an excessive load on the cata-
lytic converter.
zDo not pull−or push−start your ve-
hicle.
zDo not turn off the engine switch
while the vehicle is moving.
zKeep your engine switch in good
running order. Malfunctions in the
engine electrical system or fuel sys-
tem could cause an extremely high
catalytic converter temperature.
zIf the engine becomes difficult to
start or stalls frequently, take your
vehicle in for a check−up to any
authorized Toyota dealer or repairer,
or another duly qualified and
equipped professional.
zTo ensure that the catalytic convert-
er and the entire emission control
system operate properly, your ve-
hicle must receive the periodic in-
spections required by the Toyota
Maintenance Schedule. For sched-
uled maintenance information, refer
to the “Toyota Service Booklet” or
“Toyota Warranty Booklet”.
Dyna100/150_EE

11 4INFORMATION BEFORE DRIVING YOUR TOYOTA
CAUTION
DExhaust gases include harmful car-
bon monoxide (CO) that is colorless
and odorless. Inhaling exhaust
gases may lead to death or a seri-
ous health hazard.
DThe exhaust should be checked
occasionally. If there is a hole or
crack caused by corrosion, damage
to a joint or abnormal exhaust
noise, be sure to have the vehicle
inspected and repaired by any
authorized Toyota dealer or repairer,
or another duly qualified and
equipped professional. Failure to do
so may allow exhaust gases to
enter the vehicle, resulting in death
or a serious health hazard.
DIf the vehicle is in a poorly venti-
lated area, turn the engine off. In a
closed area, such as a garage, ex-
haust gases may collect and enter
the vehicle. This may lead to death
or a serious health hazard.
DDo not remain for a long time in a
parked vehicle with the engine run-
ning. If it is unavoidable, however,
do so only in an unconfined area
and adjust the heating or cooling
system to force outside air into the
vehicle.
DIf the smell of exhaust is noticed
inside the vehicle, open the win-
dows. Large amounts of exhaust in
the vehicle can cause driver drowsi-
ness and an accident, resulting in
death or a serious health hazard.
Have the vehicle inspected by any
authorized Toyota dealer or repairer,
or another duly qualified and
equipped professional immediately.
DDo not leave the engine running in
an area with snow build−up, or
where it is snowing. If snowbanks
build up around the vehicle while
the engine is running, exhaust
gases may collect and enter the ve-
hicle. This may lead to death or a
serious health hazard.
DWhen taking a nap in the vehicle,
always turn the engine off. Other-
wise, you may accidentally move
the shift lever or depress the accel-
erator pedal, which could cause an
accident or fire due to engine over-
heating. Additionally, if the vehicle
is parked in a poorly ventilated
area, exhaust gases may collect and
enter the vehicle, leading to death
or a serious health hazard.
DToyota does not recommend occu-
pying the rear cargo area when it
is fitted with a slide−in camper,
camper shell or other type cover
while the engine is running. This
caution applies to both driving and
stopped or parked situations with
the engine running. Particular care
should be taken to prevent exhaust
gases from entering camper bodies,
trailers or other enclosures on or
around your vehicle. If exhaust
fumes are detected, open all win-
dows and thoroughly ventilate the
area.
Dyna100/150_EE
Engine exhaust cautions
