TOYOTA DYNA 100/150 2014 Owners Manual (in English)

DO−IT−YOURSELF MAINTENANCE: Electrical components205
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the engine switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
DTo prevent burning yourself, do not
replace the light bulbs while they
are hot.
DHalogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if
scratched or dropped. Hold a bulb
only by its plastic or metal case.
Do not touch the glass part of a
bulb with bare hands.
NOTICE
Only use a bulb of the listed type.
The inside of the lens of exterior lights
such as headlights may temporarily fog up
when the lens becomes wet in the rain or
in a car wash. This is not a problem
because the fogging is caused by the
temperature difference between the outside
and inside of the lens, just like the
windshield fogs up in the rain. However, if
there is a large drop of water on the
inside of the lens, or if there is water
pooled inside the light, contact any
authorized Toyota dealer or repairer, or
another duly qualified and equipped
professional.Light bulbs
WTy p e
Headlights60/55A
Front position lights21/5B
Front turn signal lights21B
Side turn signal lights21B
Rear turn signal lights21B
Stop/tail lights21/5B
Back−up lights21B
Rear fog light21B
License plate lights10B
Interior light10C
A: H4 halogen bulbs
B: Single end bulbs
C: Double end bulbs
Dyna100/150_EE
Replacing light bulbs—

206DO−IT−YOURSELF MAINTENANCE: Electrical components
1. Single cab models: Tilt the cab. (See
“Tilt cab” on page 18 in Section 1−2
for details.)
Unplug the connector.
If the connector is tight, wiggle it.2. Remove the rubber cover.
Dyna100/150_EE
—Headlights

DO−IT−YOURSELF MAINTENANCE: Electrical components207
3. Release the bulb retaining spring
and remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutouts of the mounting
hole.4. Install the rubber cover with the
“TOP” mark upward, and fit it se-
curely on the boss. Plug in the con-
nector.
Make sure the rubber cover fits securely
on the bulb base and the mounting body.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact any authorized Toyota
dealer or repairer, or another duly quali-
fied and equipped professional.
Dyna100/150_EE

208DO−IT−YOURSELF MAINTENANCE: Electrical components
Use a Phillips−head screwdriver.
a: Front turn signal light
b: Front position light
Front of
vehicle
Use a Phillips−head screwdriver.
Dyna100/150_EE
—Front turn signal and front
position lights
—Side turn signal lights

DO−IT−YOURSELF MAINTENANCE: Electrical components209
Use a Phillips−head screwdriver.
a: Rear turn signal light
b: Stop/tail light
c: Back−up light
Use a Phillips−head screwdriver.
a: Rear turn signal light
b: Stop/tail light
c: Back−up light
Dyna100/150_EE
—Rear turn signal, stop/tail
and back−up lights (type A)—Rear turn signal, stop/tail
and back−up lights (type B)

210DO−IT−YOURSELF MAINTENANCE: Electrical components
Use a Phillips−head screwdriver.Use a Phillips−head screwdriver.
Dyna100/150_EE
—Rear fog light —License plate lights

SPECIFICATIONS211
Section 8
SPECIFICATIONS
DDimensions 212.......................................
DWeights 214...........................................
DEngine 215............................................
DFuel 215..............................................
DService specifications 216..............................
DTires 218.............................................
DFuses 219............................................
Dyna100/150_EE

212SPECIFICATIONS
mm (in.)
Model


1Overall lengthOverall widthOverall height
KDY221R−TBMDYW4430 (174.4)1695 (66.7)1975 (77.8)
KDY221R−TBMDYW34345 (171.1)1695 (66.7)1965 (77.4)
2050 (80.7)

2
KDY221L−TBMDYW4430 (174.4)1695 (66.7)1975 (77.8)
KDY221L−TBMDYW34345 (171.1)1695 (66.7)1965 (77.4)
2050 (80.7)

2
KDY231R−TBMGYW34590 (180.7)1900 (74.8)1975 (77.8)
2060 (81.1)

2
KDY231L−TBMGYW34590 (180.7)1900 (74.8)1975 (77.8)
2060 (81.1)

2
KDY231L−PBMEYW34590 (180.7)1900 (74.8)2000 (78.7)
2150 (84.6)
KDY231L−PSMBYW4690 (184.6)1695 (66.7)1985 (78.1)
KDY231L−PSMBYW34590 (180.7)1695 (66.7)1995 (78.5)
2140 (84.3)

2
KDY251R−TBMGYW35905 (232.5)1900 (74.8)1975 (77.8)
2060 (81.1)

2
KDY251L−TBMGYW35905 (232.5)1900 (74.8)1975 (77.8)
2060 (81.1)

2
KDY251L−PBMEYW35905 (232.5)1900 (74.8)2000 (78.7)
2140 (84.3)

2
KDY261L−TBMGYW36475 (254.9)1900 (74.8)1975 (77.8)
2060 (81.1)

2
KDY261L−PBMEYW36475 (254.9)1900 (74.8)2000 (78.7)
2140 (84.3)

2
Dyna100/150_EE
Dimensions

SPECIFICATIONS213
mm (in.)
Model


1Wheel baseFront treadRear tread
KDY221R−TBMDYW2300 (90.6)1435 (56.5)1365 (53.7)
KDY221R−TBMDYW32300 (90.6)1435 (56.5)1365 (53.7)
KDY221L−TBMDYW2300 (90.6)1435 (56.5)1365 (53.7)
KDY221L−TBMDYW32300 (90.6)1435 (56.5)1365 (53.7)
KDY231R−TBMGYW32545 (100.2)1435 (56.5)1500 (59.1)
KDY231L−TBMGYW32545 (100.2)1435 (56.5)1500 (59.1)
KDY231L−PBMEYW32545 (100.2)1435 (56.5)1500 (59.1)
KDY231L−PSMBYW2545 (100.2)1435 (56.5)1365 (53.7)
KDY231L−PSMBYW32545 (100.2)1435 (56.5)1365 (53.7)
KDY251R−TBMGYW33350 (131.9)1435 (56.5)1500 (59.1)
KDY251L−TBMGYW33350 (131.9)1435 (56.5)1500 (59.1)
KDY251L−PBMEYW33350 (131.9)1435 (56.5)1500 (59.1)
KDY261L−TBMGYW33750 (147.6)1435 (56.5)1500 (59.1)
KDY261L−PBMEYW33750 (147.6)1435 (56.5)1500 (59.1)


1: The model code appears on the manufacturer ’s plate or label with the heading “MOD-
EL”.
See “Your Toyota’s identification” on page 120 in Section 2 for the manufacturer ’s
plate or label location.


2: High roof models
Dyna100/150_EE

214SPECIFICATIONS
kg (lb.)
Model
Gross Vehicle
Mass(GVM)
Maximum Permissible Axle
Capacity (MPAC)
ModelMass (GVM)FrontRear
Dyna100
Single cab
3000 (6614)1800(3968)1800(3968)Dyna100

Double cab
3210 (7077)1800(3968)1800(3968)
Dyna 150
3500 (7716)1800 (3968)2550 (5622)
kg (lb.)
ModelDrawbarloadTowing capacityModelDrawbarloadWith brakeWithout brake
Dyna 100
110 (243)2000 (4409)750 (1653)
Dyna 150
115 (254)2200 (4850)750 (1653)

: See “Model code” on page vi in the beginning of this manual if you are not sure of
your vehicle model.
Dyna100/150_EE
Weights
