TOYOTA DYNA 100/150 2014 Owners Manual (in English)

DO−IT−YOURSELF MAINTENANCE: Introduction185
If you perform maintenance by yourself,
be sure to follow the correct procedure
given in this Section.
You should be aware that improper or in-
complete servicing may result in operating
problems.
This Section gives instructions only for
those items that are relatively easy for an
owner to perform. As explained in Section
6, there are still a number of items that
must be done by a qualified technician
with special tools.
Utmost care should be taken when work-
ing on your vehicle to prevent accidental
injury. Here are a few precautions that
you should be especially careful to ob-
serve:
CAUTION
DWhen the engine is running, keep
hands, clothing, and tools away
from the moving fan and engine
drive belts. (Removing rings,
watches, and ties is advisable.)
DRight after driving, the engine
compartment—the engine, radiator,
exhaust manifold and power steer-
ing fluid reservoir, etc.—will be hot.
So be careful not to touch them.
Oil and fluids may also be hot.
DIf the engine is hot, do not remove
the radiator cap or loosen the drain
plugs to prevent burning yourself.
DDo not leave anything that may
burn easily, such as paper or rags,
in the engine compartment.
DDo not smoke, cause sparks or al-
low open flames around fuel or the
battery. Their fumes are flammable.
DBe extremely cautious when work-
ing on the battery. It contains poi-
sonous and corrosive sulfuric acid.
DDo not get under your vehicle with
just the body jack supporting it. Al-
ways use automotive jack stands or
other solid supports.
DBe sure that the engine switch is
off if you work near the electric
cooling fans. With the engine
switch on, the electric cooling fans
will automatically start to run if the
engine coolant temperature is high
and/or the air conditioning is on.
DUse eye protection whenever you
work on or under your vehicle
where you may be exposed to flying
or falling material, fluid spray, etc.
DUsed engine oil contains potentially
harmful contaminants which may
cause skin disorders such as in-
flammation or skin cancer, so care
should be taken to avoid prolonged
and repeated contact with it. To re-
move used engine oil from your
skin, wash thoroughly with soap
and water.
DDo not leave used oil within the
reach of children.
DDispose of used oil and filter only
in a safe and acceptable manner.
Do not dispose of used oil and fil-
ter in household trash, in sewers or
onto the ground. Call your dealer or
a service station for information
concerning recycling or disposal.
DTake care when filling the brake and
clutch fluid reservoirs because
brake fluid can harm your hands or
eyes. If fluid gets on your hands or
in your eyes, flush the affected area
with clean water immediately. If you
still feel uncomfortable with your
hands or eyes, go to the doctor.
Dyna100/150_EE
Do−it−yourself service
precautions

186DO−IT−YOURSELF MAINTENANCE: Introduction
NOTICE
zRemember that battery cables carry
high currents. Be careful of acci-
dentally causing a short circuit.
zAdd only “Toyota Super Long Life
Coolant” or similar high quality eth-
ylene glycol based non−silicate,
non−amine, non−nitrite, and non−bo-
rate coolant with long−life hybrid
organic acid technology to fill the
radiator. “Toyota Super Long Life
Coolant” is a mixture of 50% cool-
ant and 50% deionized water.
zIf you spill some of the coolant, be
sure to wash it off with water to
prevent it from damaging the parts
or paint.
zDo not overfill power steering fluid,
or the power steering could be
damaged.
zIf you spill brake fluid, be sure to
wash it off with water to prevent it
from damaging the parts or paint.
zDo not drive with the air cleaner
filter removed, or excessive engine
wear could result.
zBe careful not to scratch the glass
surface with the wiper frame.
zWhen closing the engine access
hole cover or lowering the cab,
check to see that you have not for-
gotten any tools, rags, etc.
Dyna100/150_EE

DO−IT−YOURSELF MAINTENANCE: Engine and Chassis187
Section 7−2
DO−IT−YOURSELF MAINTENANCE
Engine and Chassis
DChecking the engine oil level 188........................
DChecking the engine coolant level 190...................
DChecking the radiator, condenser and intercooler 192.....
DDraining fuel filter water 192............................
DChecking tire inflation pressure 193.....................
DChecking and replacing tires 194........................
DRotating tires 195......................................
DInstalling snow tires and chains 196.....................
DReplacing wheels 197..................................
Dyna100/150_EE

188DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
Low level Full level
Add oil O.K. Too full
With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.
1. To get a correct reading, the vehicle
should be on level ground. After warm-
ing up the engine and turning it off,
wait more than five minutes for the oil
to drain back into the bottom of the
engine.
2. Pull the dipstick out, hold a rag under
the end and wipe it clean.
3. Reinsert the dipstick—push it in as far
as it will go, or the reading will not be
correct.
4. Pull the dipstick out and look at the oil
level while holding a rag under the
end.
NOTICE
Be careful not to drop engine oil on
the vehicle components.
If the oil level is below or only slightly
above the low level, add engine oil of
the same type as already in the engine.
Remove the oil filler capand add engine
oil in small quantities at a time, checking
the dipstick. We recommend that you use
a funnel when adding oil.The approximate quantity of oil needed to
raise the level between low and full on the
dipstick is indicated as follows:
1.9L(2.0qt.,1.7Imp.qt.)
For the engine oil capacity, see “Service
specifications” on page 216 in Section 8.
When the level reaches within the correct
range, install the filler cap hand−tight.
NOTICE
zBe careful not to spill engine oil on
the vehicle components.
zAvoid overfilling, or the engine
could be damaged.
zCheck the oil level on the dipstick
once again after adding the oil.
Dyna100/150_EE
Checking the engine oil level

DO−IT−YOURSELF MAINTENANCE: Engine and Chassis189
ENGINE OIL SELECTION
“Toyota Genuine Motor Oil” is used in
your Toyota vehicle. Toyota recommends
the use of approved “Toyota Genuine
Motor Oil”. Another motor oil of matching
quality can also be used.
Oil grade:
ACEA C2
NOTICE
Using engine oil other than ACEA C2
may damage the catalytic converter.
Recommended viscosity (SAE):
Temperature range anticipated before
next oil change
Preferred
SAE 0W−30 is filled into your Toyota
vehicle at manufacturing, and the best
choice for good fuel economy and good
starting in cold weather.Oil viscosity (0W−30 is explained here as
an example):
The0Win0W−30 indicates the character-
istic of the oil which allows cold startabil-
ity. Oils with a lower value before the W
allow for easier starting of the engine in
cold weather.
The30in0W−30 indicates the viscosity
characteristic of the oil when the oil is at
high temperature. An oil with a higher vis-
cosity (one with a higher value) may be
better suited if the vehicle is operated at
high speeds, or under extreme load condi-
tions.
Dyna100/150_EE

190DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
To ensure excellent lubrication perfor-
mance for your engine, Toyota recom-
mends the use of “Toyota Genuine Motor
Oil”, which has been specifically tested
and approved for all Toyota engines.
Please contact any authorized Toyota
dealer or repairer for further details about
“Toyota Genuine Motor Oil”. Other motor
oils of matching quality also be used.Look at the see−through coolant reser-
voir when the engine is cold. The cool-
ant level is satisfactory if it is between
the “FULL” and “LOW” lines on the
reservoir. If the level is low, add the
coolant. (For the coolant type, see
“Coolant type selection” described be-
low.)
The coolant level in the reservoir will vary
with engine temperature. However, if the
level is on or below the “LOW” line, add
coolant. Bring the level up to the “FULL”
line.
If the coolant level drops within a short
time after replenishing, there may be a
leak in the system. Visually check the
radiator, hoses, radiator cap and drain
cock and water pump.
If you can find no leak, have any autho-
rized Toyota dealer or repairer, or another
duly qualified and equipped professional,
test the cap pressure and check for leaks
in the cooling system.
CAUTION
To prevent burning yourself, do not
remove the radiator cap when the en-
gine is hot.
Dyna100/150_EE
Checking the engine coolant
level

DO−IT−YOURSELF MAINTENANCE: Engine and Chassis191
Coolant type selection
Use of improper coolants may damage
your engine coolingsystem.
Only use “Toyota Super Long Life Coolant”
or similar high quality ethylene glycol
based non−silicate, non−amine, non−nitrite,
and non−borate coolant with long−life
hybrid organic acid technology. (Coolant
with long−life hybrid organic acid
technology is a combination of low
phosphates and organic acids.)
“Toyota Super Long Life Coolant” is a mix-
ture of 50% coolant and 50% deionized
water. This coolant provides protection
down to about−35_C(−31_F).
NOTICE
Do not use plain water alone.
Toyota recommends “Toyota Super Long
Life Coolant”, which has been tested to
ensure that it will not cause corrosion nor
result in malfunction of your engine
coolant system with proper usage. “Toyota
Super Long Life Coolant” is formulated
with long−life hybrid organic acid
technology and has been specifically
designed to avoid engine coolingsystem
malfunction on Toyota vehicles.
Please contact any authorized Toyota
dealer or repairer for further details.
Dyna100/150_EE

192DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
If any of the above parts are extremely
dirty or you are not sure of their condi-
tion, take your vehicle to any authorized
Toyota dealer or repairer, or another duly
qualified and equipped professional.
CAUTION
To prevent burning yourself, be care-
ful not to touch the radiator, con-
denser and intercooler when the en-
gine is hot.
NOTICE
To prevent damage to the radiator,
condenser and intercooler, do not per-
formtheworkbyyourself.
When the fuel filter warning light
comes on, the water in the fuel filter
must be drained immediately.
Place a small tray under the drain plug to
catch the water.
1. Turn the drain plug about 2—2−1/2
turns, as shown above. (Loosening
more than this will cause water oozing
from around the drain plug.)
2. Operate the priming pump until fuel be-
gins to run out.
After draining, retighten the drain plug. Do
not use a tool.
Dyna100/150_EE
Checking the radiator,
condenser and intercoolerDraining fuel filter water

DO−IT−YOURSELF MAINTENANCE: Engine and Chassis193
Keep your tire inflation pressures at the
proper level.
The recommended cold tire inflation pres-
sures and tire sizes are given on page
218 in Section 8.
You should check the tire inflation pres-
sure every two weeks, or at least once a
month. And do not forget the spare!
Incorrect tire inflation pressure may waste
fuel, reduce the comfort of driving, reduce
tire life and make your vehicle less safe
to drive.
If a tire frequently needsrefilling,have it
checked by any authorized Toyota dealer
or repairer, or another duly qualified and
equipped professional.
The following instructions for checking
tire inflation pressure should be ob-
served:
DThe pressure should be checked only
when the tires are cold.If your ve-
hicle has been parked for at least 3
hours and has not been driven for
more than 1.5 km or 1 mile since, you
will get an accurate cold tire inflation
pressure reading.
DAlways use a tire pressure gauge.
The appearance of a tire can be mis-
leading. Besides, tire inflation pressur-
es that are even just a few pounds off
can degrade ride and handling.
DDo not bleed or reduce tire inflation
pressure after driving.It is normal for
the tire inflation pressure to be higher
after driving.
DBe sure to reinstall the tire valve
caps.Without the valve caps, dirt or
moisture could get into the valve core
and cause air leakage. If the caps
have been lost, have new ones put on
as soon as possible.
CAUTION
Keep your tires properly inflated.
Otherwise, the following conditions
may occur and cause an accident re-
sulting in death or serious injuries.
Low tire pressure (underinflation)—
DExcessive wear
DUneven wear
DPoor handling
DPossibility of blowouts from an
overheated tire
DPoor sealing of the tire bead
DWheel deformation and/or tire sepa-
ration
DA greater possibility of tire damage
from road hazards
High tire pressure (overinflation)—
DPoor handling
DExcessive wear
DUneven wear
DA greater possibility of tire damage
from road hazards
Dyna100/150_EE
Checking tire inflation
pressure

194DO−IT−YOURSELF MAINTENANCE: Engine and Chassis
Treadwear indicator
CHECKING YOUR TIRES
Check the tire’s tread for treadwear in-
dicators. If the indicators show, replace
the tires. The location of treadwear in-
dicators is shown by the “TWI” or “
”
marks, etc., molded on the sidewall of
each tire.
The tires on your Toyota have built−in
treadwear indicators to help you know
when the tires need replacement. When
the tread depth wears to 1.6 mm (0.06
in.) or less, the indicators will appear. If
you can see the indicators in two or more
adjacent grooves, the tire should be re-
placed. The lower the tread, the higher
the risk of skidding.
The effectiveness of snow tires is lost
if the tread wears down below 4 mm
(0.16 in.).
If you have tire damage such as cuts,
splits, cracks deep enough to expose
the fabric, or bulges indicating internal
damage, the tire should be replaced.
If a tire often goes flat or cannot be prop-
erly repaired due to the size or location
of a cut or other damage, it should be
replaced. If you are not sure, consult with
any authorized Toyota dealer or repairer,
or another duly qualified and equipped
professional.
If air loss occurs while driving, do not
continue driving. Driving even a short dis-
tance can damage a tire beyond repair.Any tires which are over 6 years old
must be checked by a qualified techni-
cian even if damage is not obvious.
Tires deteriorate with age even if they
have never or seldom been used.
This applies also to the spare tire and
tires stored for future use.
REPLACING YOUR TIRES
When replacing a tire, use a tire of the
same size and construction, and the
same or greater load capacity as the
originally installed tires.
Using any other size or type of tire may
seriously affect handling, ride, speedome-
ter/odometer calibration, ground clearance,
and clearance between the body and tires
or snow chains.
CAUTION
Observe the following instructions.
Otherwise, an accident may occur re-
sulting in death or serious injuries.
DDo not mix radial, bias belted, or
bias−ply tires on your vehicle, as
this may cause dangerous handling
characteristics resulting in loss of
control.
DDo not use tires other than the
manufacturer ’s recommended size,
as this may cause dangerous han-
dling characteristics resulting in
loss of control.
DDo not mix tires of different makes,
models or tread patterns, and do
not mix tires of remarkably different
treadwear. This may cause danger-
ous handling characteristics result-
ing in loss of control.
Dyna100/150_EE
Checking and replacing tires
