TOYOTA GT86 2018 (in English) User Guide

9
P
R
N
D
M
Park*
Reverse
Neutral
Drive
“M” mode
+ (“M” mode)
- (“M” mode)
+ (“M” mode)- (“M” mode)
Paddle shift switchesShift lever
* The ignition switch must be “ON” and the brake pedal depressed t\
o shift from
Park.
Shift the shift lever to “M” position from “D” position.
+: Upshifting
-: Downshifting
Refer to the Owner’s Manual for more details.
Pull(2) Push
(1) Pull slightly
(3) Lower
Set Release
“M” (MANUAL) MODE
Automatic transmission (if equipped)
FEATURES & OPERATIONS
Lift up ring to shift into reverse
Manual transmission (if equipped)
Parking brake
OVERVIEW
FEATURES & OPERATIONS
SAFETY & EMERGENCY FEATURES

10
Normal mode
Sport mode
Use for sporty driving or when driving in mountainous regions with lots \
of curves.
Press this switch and the “SPORT” indicator illuminates.
Snow mode
Use for accelerating and driving on slippery road surfaces such as snow.\
Press this
switch and the “SNOW” indicator illuminates.
To cancel SPORT mode or SNOW mode, press the same side of the switch aga\
in
and it returns to normal driving mode.Refer to the Owner’s Manual for more details.
Driving modes
Cruise control
1 The set speed may also be cancelled by depressing the brake pedal.2 The set speed may be resumed once vehicle speed exceeds 25 mph.
System ON/OFF
Increase speed
Decrease speed
Cancel1
Resume2
Set
FEATURES & OPERATIONS
NORMAL SPORTSNOW
TURNING SYSTEM ON/OFF
AUTOMATIC TRANSMISSION (IF EQUIPPED)
FUNCTIONS

11
There are two types of control modes to accommodate various driving pref\
erences.
Normal mode
Use for secure and smooth normal driving.
“TRACK” mode
Use for the feeling of added control and maneuverability. Press this swi\
tch and the
“TRACK” and “VSC OFF” indicators illuminate. To cancel and g\
o back to normal
mode while in “TRACK” mode, press “TRACK” or “VSC OFF”\
switch again.
Refer to the Owner’s Manual for more details.
Hill-start Assist Control (HAC)
Hill-start assist control (HAC) helps to maintain braking force to ass\
ist starting off
forward while facing uphill or starting off backward while facing downhi\
ll. As HAC
is initially disabled, enable the system to make it operable. The enable\
d/disabled
setting will be maintained the next time the engine is started.
The hill-start assist control ON indicator will be illuminated when syst\
em is enabled
and flash while the system is operating.
To enable system, refer to the Owner’s Manual for limitations and mor\
e information.
AUTOMATIC TRANSMISSION/MANUAL TRANSMISSION/ (IF EQUIPPED)
OVERVIEW
FEATURES & OPERATIONS
SAFETY & EMERGENCY FEATURES

12
HeightLock release button
Windshield wipers & washers
For more details, refer to the Owner’s Manual.
* Intermittent windshield wiper frequency adjustment. Rotate to increase/decrease wipe
frequency.
Lights & turn signals
Parking lights Low beam
Headlights
Right turn
Left turn
Lane change
Lane change
High beam
High beam flasher
AUTO OFF
Daytime Running Light system (DRL) Automatically turns on the headlights to make
vehicle more visible to other drivers. Not for use at night.

Automatic light cut off system Automatically turns lights off after 30-second delay,
or lock switch on remote may be pushed afterlocking.
Interval wipe
Slow
FastPull to wash and wipe
Single wipe Adjust frequency*
Seats-Head restraints
FEATURES & OPERATIONS
HEADLIGHTS
TURN SIGNALS

13
Seats-Fold down rear seats
(1) Pull(2) Fold down
Windows
Automatic operation Push the switch completely down or pull it completely up and
release to fully open. To stop window midway, operate the switch in the \
opposite
direction.
Window lock switch Deactivates all passenger windows. Driver’s window
remains operable.
Window lock switch
Up
Down
Driver door window controls
Seat position
(forward/backward)Seatback angle
Height crank (diver side only) Seatback lock release
Seat adjustments-Front
OVERVIEW
FEATURES & OPERATIONS
SAFETY & EMERGENCY FEATURES

14
Multi-Information Display (MID)
Push “DISP” to change information in the following:
(1) Outside temperature
(2) Current fuel consumption
(3) Average fuel consumption
(4) Setting screen for the REV (engine RPM) indicator*
Push “ODO TRIP” to change information in the following:
(1) Odometer
(2) Trip meter
(3) Setting screen for shift position indicator and shift-up indicator\
(manual
transmission)
* Only displayed when the vehicle is stopped.
For more details, refer to the Owner’s Manual.
Menu icons
Content display area
Odometer/trip meter
display area
Use meter control switches on the steering wheel to scroll through the f\
ollowing
information screens:
Drive information
Exclusive content for 86
Setting display
Warning message display
For more details, refer to the Owner’s Manual.
FEATURES & OPERATIONS
MONOCHROME DISPLAY (IF EQUIPPED)
COLOR DISPLAY (IF EQUIPPED)

15
“” Select menu icons.
“” Change displayed
content, scroll up/down
the screen and move the
cursorReturns to the previous screen.
EnterMulti-information display (MID)
Steering wheel switches
Cup/bottle holders
Changing the positionChanging the tray size
CUP HOLDERS
BOTTLE HOLDERS
OVERVIEW
FEATURES & OPERATIONS
SAFETY & EMERGENCY FEATURES

16
FEATURES & OPERATIONSDoor locks
Trunk release
Push and hold
From insideFrom outside (without Smart Key)
Clock
00
* The ignition switch must be “ON.”
Hold wheel, push lever down, set angle and length, and return lever.
NOTE: Do not attempt to adjust while the vehicle is in motion.
Tilt & telescopic steering wheel
Lock release lever
AngleLength
Minute set
Hour set Round off
minutes
Lock
Unlock

17
Power outlets
AUX/USB port
AUX port
By inserting a mini plug (not included) into the AUX port, you can lis\
ten to music
from a portable audio device through the vehicle’s speaker system whi\
le in AUX
mode.
USB port
By connecting a USB memory or USB-compatible portable audio device to th\
e
USB port, you can listen to music from the portable audio device or USB \
memory
through the vehicle’s speaker system.
Refer to the Toyota Audio Manual or Toyota.com for more details.
Designed for car accessories. The “ENGINE START STOP”/ignition swi\
tch must be
in the ACCESSORY or IGNITION ON/“ACC” or “ON” position to be\
use.
Console trayGlove box
OVERVIEW
FEATURES & OPERATIONS
SAFETY & EMERGENCY FEATURES

18
FEATURES & OPERATIONSAir conditioning/heating
For more details, refer to the Owner’s Manual.
Airflow vent
“
” and “” mode uses outside air only Rear window defogger
Recirculate cabin air
(outside air when OFF)
Climate control OFF Recirculate cabin air
(outside air when OFF)Rear window and outside
rear view mirror defoggers
Air Conditioning ON/OFF
Windshield airflow
Defogging
windshield
Airflow vent
Temperature selector
(driver side)
Temperature selector
(front passenger side)
Automatic climate control ON
Adjust the temperature setting, and airflow
vents and fan will adjust automatically.
Fan speed/Airflow
vent display
Temperature display
(driver side)
Temperature display
(front passenger side)
“DUAL” button
Indicator ON: Separate temperature
settings for driver and passenger.
Indicator OFF: Synchronize temperature
settings for driver and passenger. Air Conditioning ON/OFF
Fan speed Temperature selector
Manual air conditioning
Automatic air conditioning
