TOYOTA HIGHLANDER 2016 XU50 / 3.G Owners Manual

4516-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM48F09U)
Unlock with the master key
(vehicles without a smart key
system) or mechanical key
(vehicles with a smart key sys-
tem)
Lock with the master key (vehi-
cles without a smart key sys-
tem) or mechanical key
(vehicles with a smart key sys-
tem)
Open (pull lever)
■Power back door main switch (vehicles with power back door)
The power back door main switch is located in the glove box. ( P. 130)
To open the console box lids,
press on the knob and slide both
lids.
Glove box
1
2
3
Console box

4526-3. Using the storage features
HIGHLANDER_U (OM48F09U)
■Tray in the console box
■
Front
■Rear
The tray slides forward/backward and can
be removed.
Bottle holders

4536-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM48F09U)
■When using the bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
■
Front
■Rear (second seats)
Ty p e A
Pull the armrest down.
(  P. 467)
WARNING
Do not place anything other than a bottle in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
Cup holders

4546-3. Using the storage features
HIGHLANDER_U (OM48F09U)
Ty p e B
Fold the side table up for use.
(
P. 469)
■Rear (third seats)
■ Removing the cup holder insert (front cup holder)
The cup holder insert may be removed for
cleaning.
WARNING
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks to prevent
burns.

4556-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM48F09U)
Auxiliary boxes
OverheadDriver’s side instrument panel
Push the lid. Pull the tab to open.
WARNING
■Items unsuitable for storing (overhead)
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.

4566-3. Using the storage features
HIGHLANDER_U (OM48F09U)
■Cable pass through
The open tray is provided with a hole that allows cables to be passed through
the tray from the USB/AUX port or power outlet.
Open tray
Remove the cover.
WARNING
■Items unsuitable for the open tray
Observe the following precautions when putting items in the open tray. Fail-
ure to do so may cause items to be thrown out of the tray in the event of
sudden braking or steering. In these cases, the items may interfere with
pedal operation or cause driver distraction, resulting in an accident.
●Do not store items in the tray that can easily shift or roll out.
● Do not stack items in the tray higher than the tray’s edge.
● Do not put items in the tray that may protrude over the tray’s edge.

4576-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM48F09U)
Raise the hooks to use.
Cargo hooks are provided for
securing loose items.
Luggage compartment features
Cargo hooks
Grocery bag hooks
NOTICE
Do not hang any object heavier than 6.6 lb. (3 kg) on the grocery bag hooks.

4586-3. Using the storage features
HIGHLANDER_U (OM48F09U)■
Center deck under tray
Pull the strap upwards to
open the center deck board.
To secure the center deck
board, remove the hook on
the backside of the center
deck board and attach the
hook to the head restraint on
the third seats as shown.
■Deck side box
Pull the strap upwards to open
the side deck board.
Auxiliary boxes
1
2
WARNING
Do not drive with any of the deck boards opened. Items may fall out and
cause injury.

459
6
Interior features
HIGHLANDER_U (OM48F09U)
6-4. Using the other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The vanity light turns on.
■ To prevent battery discharge
If the vanity lights remain on for 20 minutes while the engine is off, the lights
will turn off automatically.
Other interior features
Sun visors
1
2
3
Vanity mirrors

4606-4. Using the other interior features
HIGHLANDER_U (OM48F09U)
Push the lid.
Push the lid back up half way.
■To use the overhead console from the conversation mirror state
Fully close the lid, then open it again. (
P. 455)
Conversation mirror
1
2
