4616-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)
Unlock with the master key
(vehicles without a smart key
system) or mechanical key
(vehicles with a smart key sys-
tem)
Lock with the master key (vehi-
cles without a smart key sys-
tem) or mechanical key
(vehicles with a smart key sys-
tem)
Open (pull lever)
■Power back door main switch (vehicles with power back door)
The power back door main switch is located in the glove box. ( P. 126)
To open the console box lids,
press on the knob and slide both
lids.
Glove box
1
2
3
Console box

4626-3. Using the storage features
HIGHLANDER_U (OM0E031U)
■Tray in the console box
■
Front
■Rear
The tray slides forward/backward and can
be removed.
Bottle holders

4636-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)
■When using the bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
■
Front
■Rear (second seats)
Ty p e A
Pull the armrest down.
(  P. 480)
WARNING
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
Cup holders

4646-3. Using the storage features
HIGHLANDER_U (OM0E031U)
Ty p e B
Fold the side table up for use.
(
P. 4 8 2 )
■Rear (third seats)
■ Removing the cup holder insert (front cup holder)
The cup holder insert may be removed for
cleaning.
WARNING
Do not place anything other than cups or aluminum cans in the c up holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks t o prevent
burns.

4656-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)
Auxiliary boxes
OverheadDriver’s side instrument panel
Push the lid. Pull the tab to open.
WARNING
■Items unsuitable for storing (overhead)
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items insi de may fall
out, resulting in an accident.

4666-3. Using the storage features
HIGHLANDER_U (OM0E031U)
■Cable pass through
The open tray is provided with a hole that allows cables to be passed through
the tray from the USB/AUX port, USB charging ports or power out let.
Open tray
Remove the cover.
WARNING
■Items unsuitable for the open tray
Observe the following precautions when putting items in the ope n tray. Fail-
ure to do so may cause items to be thrown out of the tray in the event of
sudden braking or steering. In these cases, the items may interfere with
pedal operation or cause driver distraction, resulting in an ac cident.
● Do not store items in the tray that can easily shift or roll ou t.
● Do not stack items in the tray higher than the tray’s edge.
● Do not put items in the tray that may protrude over the tray’s edge.

4676-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)
Raise the hooks to use.
Cargo hooks are provided for
securing loose items.
Luggage compartment features
Cargo hooks
Grocery bag hooks
NOTICE
Do not hang any object heavier than 6.6 lb. (3 kg) on the groce ry bag hooks.

4686-3. Using the storage features
HIGHLANDER_U (OM0E031U)■
Center deck under tray
Pull the strap upwards to
open the center deck board.
To secure the center deck
board, remove the hook on
the backside of the center
deck board and attach the
hook to the head restraint on
the third seats as shown.
■Deck side box
Pull the strap upwards to open
the side deck board.
Auxiliary boxes
1
2
WARNING
Do not drive with any of the deck boards opened. Items may fall out and
cause injury.

4696-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)■
Installing the luggage cover
Fold down the third seats. ( P. 155)
To take out the luggage
cover unit, lift and remove
the center deck board and
side deck board. ( P. 4 6 8 )
Press the lock release but-
tons to extend the ends of
the luggage cover unit.
To install the luggage cover
unit, with the lock release
buttons facing upward, insert
one end into the recess, then
compress the other end and
insert it into the other recess.
Pull out the luggage cover
and hook it ont o the anchors.
Luggage cover (if equipped)
1
2
3
4
5

4706-3. Using the storage features
HIGHLANDER_U (OM0E031U)■
Removing the luggage cover
Release the cover from the
left and right anchors and
allow it to react.
Compress the end of the lug-
gage cover and lift up the
luggage cover up.
■Stowing the luggage cover
Open the center deck board and the side deck board. (P. 4 6 8 )
To store the luggage cover
unit, compress both ends
until they lock.
Store the unit with the lock
release buttons facing up and
the cover portion facing the rear
of the vehicle.
1
2
1
2
