TOYOTA HIGHLANDER 2018 Owners Manual (in English)

4716-3. Using the storage features
6
Interior features
HIGHLANDER_U (OM0E031U)
WARNING
■When installing/stowin g the luggage cover
Make sure that the luggage cover is securely installed/stowed. Failure to do
so may result in serious injury in the event of sudden braking or a collision.
■ Caution for the luggage cover
● Do not place anything on the luggage cover to avoid death or serious
injury.
● Do not allow children to climb on the luggage cover. Climbing o n the lug-
gage cover could result in damage to the luggage cover, possibl y causing
death or serious injury to the child.
■ When extending the luggage cover unit
Do not point the luggage cover unit at your face or body, as do ing so may
cause injuries if the cover ends extend suddenly.
NOTICE
■ When using the luggage cover
● Do not put heavy items on the luggage cover.
●Install the cover unit in the correct direc-
tion so that the lock release button
faces upward.

472
HIGHLANDER_U (OM0E031U)
6-4. Using the other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover.
The vanity light turns on.
■ To prevent battery discharge
If the vanity lights remain on for 20 minutes while the engine is off, the lights
will turn off automatically.
Other interior features
Sun visors
1
2
3
Vanity mirrors

4736-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM0E031U)
Push the lid.
Push the lid back up half way.
■To use the overhead console from the conversation mirror state
Fully close the lid, then open it again. (
P. 465)
The clock can be adjusted by pressing the buttons.
Adjusts the hours
Adjusts the minutes
Conversation mirror
1
2
Clock
1
2

4746-4. Using the other interior features
HIGHLANDER_U (OM0E031U)
■The clock is displayed when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ When the battery is disconnected
The time display will automatically be set to 1:00.
The temperature display shows
temperatures within the range of
-40 F (-40 C) to 122 F (50C).
■The outside temperature is displayed when
Vehicles without a smart key system
The engine switch is in the “ON” position.
Vehicles with a smart key system
The engine switch is in IGNITION ON mode.
■ Display
In the following situations, the correct outside temperature ma y not be dis-
played, or the display may take longer than normal to change:
● When the vehicle is stopped, or moving at low speeds (less than 15 mph
[25 km/h]).
● When the outside temperature has changed suddenly (at the entra nce/exit
of a garage, tunnel, etc.)
■ When the outside tempe rature display flashes
If the outside temperature is 37 F (3°C) or less, the ice warning indicator
flashes 10 times, and then illuminates.
■ When “--” or “E” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display

4756-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM0E031U)
The power outlet can be used for the following components:
12 V: Accessories that run on less than 10 A
120 VAC: Accessories t hat use less than 100 W
■12 V
Front
Open the lid.
Console box
Open the console box lid ( P.
461) and open the lid.
Open the lid.
■120 VAC (if equipped)
Open the lid.
Power outlets

4766-4. Using the other interior features
HIGHLANDER_U (OM0E031U)
■The power outlets can be used when
12 V
Vehicles without a smart key system:
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system:
The engine switch is in ACCESSORY or IGNITION ON mode.
120 VAC
The engine switch is in IGNITION ON mode.
■ When the engine restarts after h aving been stopped by the Stop & Start
system (if equipped)
The power outlets may be temporarily unusable, but this is not a malfunction.
NOTICE
■To avoid damaging the power outlets
Close the power outlet lids when the power outlets are not in u se.
Foreign objects or liquids that enter the power outlets may cau se a short cir-
cuit.
■ To prevent blown fuses
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 VAC
Do not use a 120 VAC appliance that requires more than 100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protec-
tion circuit will cut the power supply.
■ To prevent battery discharge
Do not use the power outlets longer than necessary when the engine is not
running.
■ Appliances that may not operate properly (120 VAC)
The following 120 VAC appliances may not operate properly even if their
power consumption is under 100 W:
● Appliances with high initial peak wattage
● Measuring devices that process precise data
● Other appliances that require an extremely stable power supply

4776-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM0E031U)
The USB charging ports are used to supply 2.1 A of electricity at 5 V
to external devices.
The USB charging ports are for charging only. They are not desi gned
for data transfer or other purposes.
Depending on the external device, it may not charge properly. R efer to
the manual included with the dev ice before using a USB charging
port.
■Using the USB charging ports
Open the lid.
■ The USB charging ports can be used when
Vehicles without a smart key system
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system
The engine switch is in ACCESSORY or IGNITION ON mode.
■ Situations in which the USB charg ing ports may not operate correctly
● If a device which consumes more than 2.1 A at 5 V is connected
● If a device designed to communicate with a personal computer, s uch as a
USB memory device, is connected
● If the connected external device is turned off (depending on de vice)
● If the temperature inside the vehicle is high, such as after the vehicle has
been parked in the sun
■ About connected external devices
Depending on the connected external device, charging may occasi onally be
suspended and then start again. This is not a malfunction.
USB charging ports
FrontRear

4786-4. Using the other interior features
HIGHLANDER_U (OM0E031U)
NOTICE
■To prevent damage to the USB charging ports
● Do not insert foreign objects into the ports.
● Do not spill water or other liquids into the ports.
● When the USB charging ports are not in use, close the lids. If a foreign
object or liquid enters a port may cause a short circuit.
● Do not apply excessive force to or impact the USB charging port s.
● Do not disassemble or modify the USB charging ports.
■ To prevent damage to external devices
● Do not leave external devices in the vehicle. The temperature i nside the
vehicle may become high, resulting in damage to an external dev ice.
● Do not push down on or apply unnecessary force to an external device or
the cable of an external device while it is connected.
■ To prevent battery discharge
Do not use the USB charging ports for a long period of time wit h the engine
stopped.

4796-4. Using the other interior features
6
Interior features
HIGHLANDER_U (OM0E031U)
Pull the tab up.
Hook the sunshade on to the
anchors.
To lower the sunshade, pull the tab
up slightly to unhook the shade
from the anchors, and lower it
slowly.
Rear sunshades (if equipped)
1
2
NOTICE
To ensure normal operation of the rear sunshades, observe the following
precautions.
● Do not place anything where it may hinder the opening/closing of a sun-
shade.
● Do not place anything on the rear sunshades.

4806-4. Using the other interior features
HIGHLANDER_U (OM0E031U)
Ty p e A
Fold down the armrest for use.
Ty p e B
Lower the armrest from the
highest position to the lowest
position.
Raise the armrest to the
desired angle.
To unlock the armrest, lift the arm-
rest to raise it to the highest posi-
tion.
Armrest
1
2
NOTICE
To prevent damage to the armrest, do not apply too much load on the arm-
rest.
