audio TOYOTA HIGHLANDER 2020 Accessories, Audio & Navigation (in English)

1904-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
BD video
The secondary audio that for the
secondary video can be
changed.
1 Select “PinP Audio”.
2 Each time “PinP Audio” is
selected, another secondary
audio stored on the disc is
selected.
“Off”: Secondary audio can be
turned off
BD video
The color key button is used for
various uses according to direc-
tions of contents.
1 Select “Color Keys”. 2
The color key buttons are
displayed on the screen.
BD video
The 10 key pad is used when
inputting numbers according to
directions of contents.
1 Select “Keypad”.
2 The 10 key pad is displayed
on the screen.
Changing the secondary
audio
Displaying the color key but-
tons
Displaying the 10 key pad

1914-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Video CD
1 Select “Select Number”.
2 Input the track number, and
select “OK”.
Video CD
If there is the next or previous
page while the disc menu is dis-
played, the page can be
switched.
1 Select “Prev. Page” or “Next
Page”.
2 Next or previous page is dis-
played.
BD video, DVD video,
AVCHD, BDAV
The initial setting can be
changed.
1 Select “Setup”.
2 Select the settings to be
changed. After the settings
are changed, select “OK”.
Changing the initial audio
language
Changing the initial subtitle
language
Changing the initial lan-
guage of the disc menu
Setting the angle mark
Setting the DVD parental
control level
Setting the BD parental con-
trol age
Setting a quick playback
Searching by track
Displaying the next or previ-
ous page
Initial setup
A
B
C
D
E
F
G

1924-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
Setting a sound dynamic
range
Restores default settings
BD history data such as
bookmarks and resume point
can be deleted.
 Select or to show the
next or previous page.
■Changing the initial audio
language
1 Select “Audio Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.216)
■Changing the initial subtitle
language
1 Select “Subtitle Language”.
2 Select the desired language.
 If you cannot find the desired language, select “Other” and
input the desired language
code. (
P.216)
■Changing the initial lan-
guage of the disc menu
1 Select “Menu Language”.
2 Select the desired language.
 If you cannot find the desired
language, select “Other” and
input the desired language
code. ( P.216)
■Setting the angle mark
If the BD/DVD disc has angle
options, you can turn the angle
mark on/off.
1 Each time “Angle Mark” is
selected, “On” or “Off” can be
selected.
■Setting the DVD parental
control level
DVD video
The level of viewer restrictions
H
I
J

1934-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
can be set.
1 Select “Parental Control
Level”.
2 Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Select a restriction level
(1-8).
■Setting the BD parental con-
trol age
BD video
The age of viewer restrictions
can be set.
1 Select “BD Parental Control
Age”. 2
Input the 4-digit personal
code and then select “OK”.
 Select 10 times to reset
the personal code in case the
code was forgotten.
3 Input a restriction age (0-255)
and then select “OK”.
■Setting a quick playback
BD video
After inserting a BD disc you
can skip over to the first play-
back point and can immediately
playback the main story.

1944-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
1Each time “Quick Play” is
selected, “On” or “Off” can be
selected.
■Setting a sound dynamic
range
The difference between the low-
est and highest sound volumes
can be adjusted.
1 Select “Sound Dynamic
Range”.
2 Select the desired setting.
“MAX”: Maximum sound
dynamic range
“MID”: Medium sound dynamic
range
“MIN”: Minimum sound dynamic
range Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Selecting a track/file
Selecting a folder
Playing an audio CD
and MP3/WMA/AAC
discs
Press the “DISC” button if a
disc has already been
loaded in the disc slot.
The player will start to play
the disc automatically.
Remote controller
A
B
C
D
E
F
G

1954-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Turning on the audio CD and
MP3/WMA/AAC mode
Repeat play
Random playback
1 Insert a disc or press the
“DISC” button.
 The player will start to play
the disc automatically.
1 Press or until
the desired track/file number
appears.
1 Press and hold or
.
MP3/WMA/AAC
1 Press “ ” or “” on the
“FOLDER” button until the
desired folder number
appears.
 Press and hold “ ” on the
“FOLDER” button, the top file
stored in the top folder in the
disc will be selected.
1 Each time is selected,
the mode changes as follow:
Audio CD
track repeat  off
MP3/WMA/AAC
file repeat  folder repeat  off
1 Each time is selected,
the mode changes as follow:
Audio CD
random  off
MP3/WMA/AAC
1 folder random  1 disc ran-
dom  off
Control screen
Turning on the CD mode
Selecting a track/file
Fast forwarding or
rewinding a track/file
H
A
B
6HOHFWLQJDIROGHU
5HSHDWSOD\
5DQGRPSOD\EDFN

1974-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
1 Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press or until
the desired track/file number
appears.
1 Press and hold or
. You can play music that is
stored on an SD card.
1
Select “Music”.
2 Music will start playing.
Repeat play
Random playback
Playing/pausing an SD
card media
Selecting a chap-
ter/track/file
Fast forwarding or
rewinding a chap-
ter/track/file
Playing music
A
B

1994-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
You can display still pictures one
by one at a constant interval.
1 Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures. 1
Select “Detailed Information”.
2 Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
5  10  15  30  60
Selects slideshow effect
“Fade”  “Slide” “Wipe1”
 “Wipe2”  “Dissolve”
 “Zoom” “Off”
Selects on/off repeat slide-
show
Starting slideshow
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C

2014-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
4
Audio/visual system
Movie Turning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage 1
Select “Detailed Information”.
2 Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Displaying the detail infor-
mations of the video

2024-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER
HV_NAVI_(U)
SD video, SD AVCHD
1 Select “Title” or “Chapter”.
2 Input the title number or
chapter number, and select
“OK”.
SD video
The audio channel can be
changed for SD card with multi-
ple audio channels.
1 Select “Multiplexed Audio”.
2 Each time “Audio” is
selected, the mode changes
in the following order:
“Main”: Main audio channel
“Sub”: Sub audio channel
“Main/Sub”: Both the main and
sub audio channels
SD video
The playback mode can be
changed to program mode or
playlist mode. Playlist mode
cannot be selected if a playlist is
not stored on the SD card.
1 Select “Playback Mode”.
2 Each time “Playback Mode”
is selected, the mode
changes in the following
order:
“Program” mode: Playback in
order of program number
“Playlist” mode: Playback in
order of playlist number
Searching for a title or chap-
ter
Changing the audio channel
Changing the playback mode
