1984-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
MP3/WMA/AAC
1 Press “ ” or “” on the
“FOLDER” button until the
desired folder number
appears.
 Press and hold “ ” on the
“FOLDER” button, the top file
stored in the top folder in the
disc will be selected.
1 Each time is selected,
the mode changes as follow:
Audio CD
track repeat  off
MP3/WMA/AAC
file repeat  folder repeat  off
1 Each time is selected,
the mode changes as follow:
Audio CD
random  off
MP3/WMA/AAC
1 folder random  1 disc ran-
dom  off Selecting a control icon
Inputting the selected control
icon
Volume up/down
Fast-forward/rewind
Play/pause
Stop
Displaying the option screen
Selecting a chapter
Selecting a folder
Repeat play
Random playback
Playing an SD card
This system can play music,
still pictures and video that
are stored in an SD card.
Press the “SD” button if an
SD card has already been
inserted in the SD card slot.
Remote controller
A
B
C
D
E
F
G
H

2004-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
You can display still pictures that
are stored on an SD card.
1Select “Picture”.
2 Select the desired still picture
to show.
 Select or to show the
next or previous page.
3 Selected picture is displayed
on the screen.
 Press the or button to
display the next or previous
still picture.
 Press the “SD” button to return to the SD menu screen.
Press the “OPTION” button
while displaying a still picture,
the following screen appears.
Press the “OPTION” button
once again or select “Hide But-
tons” to turn off the option
screen.
Turning off the option screen
Displaying the slideshow
setup screen
Returning to “Library View”
screen
Zooming out the still pictures
Rotating the still pictures
Displaying the detail informa-
tions of the still picture
Starting slideshow
Playing still pictures
Option screen
A
B
C
D
E
F
G

2014-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
You can display still pictures one
by one at a constant interval.
1Select “Slideshow” to start
slideshow.
 When pressing the or
button during slideshow, the
previous or next still picture
will be shown, and the slide-
show will continue from that
picture.
 Press the “ENT” or “OPTION”
button to stop slideshow.
1 Select or to rotate a
still picture.
 The rotate information will be
maintained until the system is
turned off or the SD card is
removed.
1 Select to zoom out the
still pictures.
 Select again to cancel
zoom out.
 This function is only available
for smallsized still pictures. 1
Select “Detailed Information”.
2 Detail informations of the still
picture are displayed.
1 Select “Setup”.
2 The slideshow settings can
be changed. After the set-
tings are changed, select
“OK”.
Selects slideshow interval
time (seconds)
“5s”  “10s”  “15s”  “30s” 
“60s”
Selects slideshow effect
“Fade”  “Slide” “Wipe1”
 “Wipe2”  “Dissolve”
 “Zoom” “Off”
Selects on/off repeat slide-
show
Starting slideshow
Rotating the still pictures
Zoom out the still pictures
Displaying the detail infor-
mations of the still picture
Slideshow setup
A
B
C

2034-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
MovieTurning off the option screen
Displaying the detail informa-
tion
Rewind
Stop
Play/pause
Fast-forward
Searching for a title
Searching for a chapter
Changing the playback mode
Changing the audio channel
Displaying the top menu
screen
Returning to the predeter-
mined scene
Changing the audio language
Changing the subtitle lan-
guage 1
Select “Detailed Information”.
2 Detail informations of the
video are displayed.
SD video
SD AVCHD
Movie
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Displaying the detail infor-
mations of the video

2064-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●The Wi-Fi® networks serve
best-effort traffic.
Using the DLNA mode
Plays or displays music,
pictures and video that are
stored on a DLNA server.
This device supports a
DLNA renderer function.
This device can play and
display content from
devices equipped with a
DLNA server function.
Make sure to install
DMC-compatible software
on the DLNA server.
Press the “INPUT” button
repeatedly until the DLNA
mode is selected.
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with
Wi-Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization ther-
apy-pacemakers or implantable
cardioverter defibrillators should
consult the manufacturer of the
device for information about its
operation under the influence of
radio waves. Radio waves could
have unexpected effects on the
operation of such medical
devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.

2074-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
Selecting a control icon
Inputting the selected control
icon
Turning on the DLNA mode
Volume up/down
Fast-forward/rewind
Play/pause
Displaying the option screen1
Press the button to
play/pause.
 Press and hold the but-
ton while pausing, the video is
played slowly.
1 Press and hold /
or / .
1 Display the DLNA operation
screen.
2 Check that “Wi-Fi
*” is on.
3 Connect a device to the rear
seat entertainment system
via Wi-Fi
®.
4 Operate the device to stream
video/music/photos.
*:Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●DLNA streaming will stop in the
following situations:
Remote controller
A
B
C
D
E
F
G
3OD\LQJSDXVL\
QJD
YLGHRPXVLF
)DVWIRUZDUGL\
QJRU
UHZLQGLQJDW\
UDFNILOH
&RQQHFWLQJWKHV\\
VWHP

2084-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)• Select “Refresh” button to change
the Wi-Fi
® setting information.
(  P.208)
• The DLNA connection is turned off on the device.
•The Wi-Fi
® function is turned off.
(  P.211)
• The rear seat entertainment sys- tem source is changed to different
source. ( P.181)
After a device has been con-
nected to the vehicle Wi-Fi®
access point once, the access
point information will remain on
the device, enabling it automati-
cally connect the next time the
device is brought within access
point range, unless the access
point name or password is
changed.
To change the access point
name and password, select
“Refresh”. If changed while a
device is connected to the
access point, the connection will
be canceled.
1 Select “Refresh”. 2
Select “Yes”.
●When the Wi-Fi® information is
refreshed, connected devices are
disconnected, so make sure to do
the wireless connection settings
again.
●The access point name and pass-
word are only changed when
“Refresh” is selected (they are not
changed when the engine switch
is turned off and
back on).
The Wi-Fi® function is turned
on/off.
Select to display Wi-Fi
® sys-
tem information
Changing the access point
name and password
DLNA operation
A
B

2094-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Connect your smartphone to
a Wi-Fi
® network and send a
picture from a DLNA-compat-
ible application.
2 Picture is displayed on the
screen.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the picture
again, select “DLNA”. 1
Connect your smartphone to
a Wi-Fi® network and send a
video from a DLNA-compati-
ble application.
2 Video will start playing.
 Press the “INPUT” button to
return to the DLNA menu
screen. To display the video
again, select “DLNA”.
Playing still picturesPlaying video

2114-8. Rear seat entertainment system operation
4
Audio/visual system
HIGHLANDER_HIGHLANDER HV_NAVI_(U)
1Select “Wi-Fi*”.
2 DLNA standby stops.
*:Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●Miracast® is a registered trade-
mark of Wi-Fi Alliance®.
●Wi-Fi® is a registered trademark
of Wi-Fi Alliance®.
●The Wi-Fi® networks serve
best-effort traffic.
●If a connected device is taken out
of the Wi-Fi® connection area, the
connection will be severed.
●Depending on the environment in
which the access point is used,
the communication speed may be
low or communication may not be
possible.
●When a device is connected to the
rear seat entertainment system
via Wi-Fi
®, the device may not be
able to be connected to the inter-
Stop DLNA standbyUsing the Miracast®
mode
The screen of a Miracast®
compatible device (with
Android OS version 4.4 or
later) can be displayed on
the rear seat entertainment
system display.
This function is not avail-
able if the smartphone is
not certified by Wi-Fi Alli-
ance
® as Miracast® device.
Refer to the instruction
manual and other documen-
tation included with the
external device to determine
whether it supports Mira-
cast
®.
Press the “INPUT” button
repeatedly until the Mira-
cast
® mode is selected.

2124-8. Rear seat entertainment system operation
HIGHLANDER_HIGHLANDER HV_NAVI_(U)net via mobile network (3G or 4G).
1
Display the Miracast® opera-
tion screen. 2
Check that the following
screen is displayed.
3 Using your Miracast
®-com-
patible device, perform a
Miracast
® connection opera-
tion to connect to the rear
seat entertainment system
display.
4 The screen of the Mira-
cast
®-compatible device is
displayed on the rear seat
display.
 Press the “INPUT” button to
return to the “Rear-Mira-
cast™” screen. To display the
video again, select “Mira-
cast™”.
●Depending on the device, Mira-
cast® may be displayed as
“Screen Mirroring”, “Media Out-
put”, etc.
●Miracast® streaming will stop in
the following situations:
• The Miracast
® function of the con-
nected device is turned off.
• Select “Disconnect” on the
“Rear-Miracast™” screen.
• The rear seat entertainment sys- tem source is changed to a differ-
ent source. ( P.181)
WA R N I N G
●Use Wi-Fi® devices only when
safe and legal to do so.
●Your audio unit is fitted with
Wi-Fi® antennas. People with
implantable cardiac pacemak-
ers, cardiac resynchronization
therapy-pacemakers or implant-
able cardioverter defibrillators
should maintain a reasonable
distance between themselves
and the Wi-Fi
® antennas. The
radio waves may affect the
operation of such devices.
●Before using Wi-Fi® devices,
users of any electrical medical
device other than implantable
cardiac pacemakers, cardiac
resynchronization ther-
apy-pacemakers or implantable
cardioverter defib rillators should
consult the manufacturer of the
device for information about its
operation under the influence of
radio waves. Radio waves could
have unexpected e ffects on the
operation of such medical
devices.
NOTICE
●Do not leave your smartphone
in the vehicle. In particular, high
temperatures inside the vehicle
may damage the smartphone.
Connecting to the system
