TOYOTA iA 2016 Owners Manual (in English)

iA_OM_OM99M17z_(U)
3614-3. Bluetooth®
4
Interior Features
Say: [Beep] “Yes”
Prompt: “Home, Work, Mobile, or Other?”
Say: [Beep] “Mobile” (Say “Home”, “Work”, “Mobile”, or “Other”,
for the desired location to be registered.)
Prompt: “Mobile (Location to be registered). Is this correct?”
Say: [Beep] “Yes”
Prompt: “Number, please.”
Say: [Beep] “XXXXXXXXXXX” (Say the phone number to be reg-
istered.)
Prompt: “XXXXXXX XXXX (Phone number regist ration). After the
beep, continue to add numbers, or say Go-Back to re-enter the
last entered numbers, or press the Pick-Up button to save the
number.”
(Registration)
Press the pick-up button or say “Enter”, then go to Step 17.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 15.
(Telephone number correction)
Say, “Go Back”. The prompt replies, “Go Back. The last entered
numbers have been removed.”. Then go back to Step 13.
Prompt: “Number saved. Would you like to add another number
for this entry?”
Say: [Beep] “Yes” or “No”.
If “Yes”, an additional phone number registration can be made for
the same entry.
If “No”, the system returns to standby status.8
9
10
11
12
13
14
15
16
17
18
19

362
iA_OM_OM99M17z_(U)
4-3. Bluetooth®
Import contact:
Phonebook data from your device (Mobile phone) can be sent and
registered to your Bluetooth
® Hands-Free phonebook using Blue-
tooth®.
Press the pick-up button or talk button with a short press.
Say: [Beep] “Phonebook”
Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”
Say: [Beep] “Import contact”
Prompt: “The hands free System is ready to receive a contact
from a phone. Only a home, a work, and a mobile number can be
imported, This process requires operation of a mobile phone.
refer to the phone’s manual for more information”
Device (Mobile phone) operation: Select one entry from the
phonebook and send it using Bluetooth
®.
Prompt: “X (Number of locations which include data) numbers
have been imported. What name would you like to use for these
numbers?”
Say: [Beep] “XXXXX... (Ex. “Mary’s phone”)” (Say a voice tag for
the name registered.)
Prompt: “Adding XXXXX... (Ex. “Mary’s phone”) (Voice tag). Is
this correct?”
Say: [Beep] “Yes”
Prompt: “Number saved. Would you like to import another con-
tact?”
Say: [Beep] “Yes” or “No”
If “Yes”, the procedure proceeds to Step 5.
If “No”, the system returns to standby status.
● Editing phonebook
The data registered to the Bluetooth
® Hands-Free phonebook can
be edited.
Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.
1
2
3
4
5
6
7
8
9
10
11
12
13

iA_OM_OM99M17z_(U)
3634-3. Bluetooth®
4
Interior Features
Press the pick-up button or talk button with a short press.
Say: [Beep] “Phonebook”
Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”
Say: [Beep] “Edit”
Prompt: “Please say the name of the entry you would like to edit
or say, “List names”.”
Say: [Beep] “XXXXX... (Ex. “Mary’s phone”)” (Say the voice tag
for the registered name to be edited in the phonebook.)
Prompt: “Home, Work, Mobile, or Other?”
Say: [Beep] “Home” (Say the regi stered location to be edited:
“Home”, “Work”, “Mobile”, or “Other”.)
Prompt: “XXXXX... (Ex. “Mary’s phone”) (Registered voice tag)
XXXX (Ex. “Home”) (Registered location). Is this correct?”
Say: [Beep] “Yes”
Prompt: “The current number is XXXXXXXXXXX (Ex. “555-
1234”) (Currently registered number). New number, please.”
If there was no previous phone number registered to a location (Ex.
“Work”), the prompt will only read out “Number, please”
Say: [Beep] “XXXXXXXXXXX (Ex. “555-5678”)” (Say the new
phone number to be registered.)
Prompt: “XXXXXXXX (Telephone number) After the beep, con-
tinue to add numbers, or say Go-B ack to re-enter the last entered
numbers, or press the Pick-Up button to save the number.”
(Number Change)
Press the pick-up button, then go to Step 15.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 13.
(Telephone number correction) Say, “Go Back”. The prompt
replies, “Go Back. The last entered numbers have been
removed. Number, please.”. Then go back to Step 12.
Prompt: “Number changed.”
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

364
iA_OM_OM99M17z_(U)
4-3. Bluetooth®
●Phonebook data deletion
Erasing individual phonebook data
Individual data register ed to the Bluetooth
® Hands-Free phonebook
can be cleared.
Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.
Press the pick-up button or talk button with a short press.
Say: [Beep] “Phonebook”
Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”
Say: [Beep] “Delete”
Prompt: “Please say the name of the entry you would like to
delete or say, “List names”.”
Say: [Beep] “XXXXX... (Ex. “John ’s phone”)” (Say the registered
voice tag to be deleted from the phonebook.)
Prompt: “Deleting XXXXX... (E x. “John’s phone”) (Registered
voice tag) Home (Registered lo cation). Is this correct?”
Say: [Beep] “Yes”
Prompt: “XXXXX... (Ex. “John’s phone”) (Registered voice tag)
Home (Registered location) deleted.”
Complete deletion of the phonebook data:
All data registered to the Bluetooth
® Hands-Free phonebook can
be erased.
Do this function only when parked. It is too distracting to attempt while driv-
ing and you may make too many errors to be effective.
Press the pick-up button or talk button with a short press.
Say: [Beep] “Phonebook”
Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”
Say: [Beep] “Erase all”
Prompt: “Are you sure you want to erase everything from your
Hands Free system phonebook?”
Say: [Beep] “Yes”
Prompt: “You are about to delete everything from your Hands
Free system phonebook. Do you want to continue?”
Say: [Beep] “Yes”
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8

iA_OM_OM99M17z_(U)
3654-3. Bluetooth®
4
Interior Features
Prompt: “Please wait, erasing the Hands Free system phone-
book.”
Prompt: “Hands-Free system phonebook erased.”
● Read-out of names registered to the Bluetooth
® Hands-Free
phonebook
Bluetooth
® Hands-Free can read out the list of names registered to
its phonebook.
Press the pick-up button or talk button with a short press.
Say: [Beep] “Phonebook”
Prompt: “Select one of the following: New entry, edit, list names,
delete, erase all or import contact.”
Say: [Beep] “List names”
Prompt: “XXXXX..., XXXXX..., XXXXX... (Ex. “John’s phone”,
Mary’s phone, Bill’s phone)” (Voice guidance reads out the voice
tags registered to the phonebook.)
Press the talk button with a short press during the read-out at the
desired name, and then say one of the following voice com-
mands to execute it.
● “Continue”: Continues the list readout.
● “Call”: Calls the registered phonebook data when the talk but-
ton is short- pressed.
● “Edit”: Edits the registered phonebook data when the talk but-
ton is short- pressed.
● “Delete”: Deletes the registered phonebook data when the talk
button is short-pressed.
● “Previous”: Returns to the previous phonebook data in read-
out when the talk butt on is short-pressed.
Prompt: “End of list, would you like to start from the beginning?”
Say: [Beep] “No”
The procedure returns to Step 3.
9
10
1
2
3
4
5
6
7
8

366
iA_OM_OM99M17z_(U)
4-3. Bluetooth®
■Redial Function
Redialing the number of the person previously dialed using the
phone is possible.
Press the pick-up button or talk button with a short press.
Say: [Beep] “Redial”
Prompt: “Dialing”
■Telephone Number Input
Press the pick-up button or talk button with a short press.
Say: [Beep] “Dial”
Prompt: “Number, please”
Say: [Beep] “XXXXXXXXXXX (Telephone number)”
Prompt: “XXXXXXXXXXX. (Teleph one number) After the beep,
continue to add numbers, or say
Go-Back to re-enter the last entered numbers, or press the Pick-
Up button to execute dialing.”
(Dialing)
Press the pick-up button or say “Dial”, then go to Step 7.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 5.
(Telephone number correction) Say, “Go Back”. The prompt
replies, “Go Back. The last entered numbers have been
removed.”. Then go back to Step 3.
Prompt: “Dialing”
The “Dial” command and a telephone number can be combined.
Ex. In Step 2, say, “Dial 123-4567” then, Steps 3 and 4 can be skipped.
1
2
3
1
2
3
4
5
6
7

iA_OM_OM99M17z_(U)
3674-3. Bluetooth®
4
Interior Features
■Emergency calls
A call can be made to the emergency phone number (911 U.S.A./
Canada) using the voice input command.Press the pick-up button or talk button with a short press.
Say: [Beep] “Emergency”
Prompt:
“Dialing “911”, is this correct?”
Say: [Beep] “Yes”
Prompt: “Dialing”
■Telephone Number Input
Practice this while parked until you are confident you can do it while driving in
a non-taxing road situation. If you are not completely comfortable, make all
calls from a safe parking position, and only start driving when you can devote
your full attention to driving.
Prompt: “Incoming call, press the pick-up button to answer”
To accept the call, press the pick-up button.
To reject the call, press the hang-up button.
Press the hang-up butt on during the call. A beep sound will confirm
that call is ended.
The microphone can be muted during a call.
Press the talk button with a short press.
Say: [Beep] “Mute”
Prompt: “Microphone muted”
■Canceling mutePress the talk button with a short press.
Say: [Beep] “Mute off”
Prompt: “Microphone unmuted”
Receiving an Incoming Call
Hanging Up a Call
Mute
1
2
3
4
5
1
2
1
2
3
1
2
3

368
iA_OM_OM99M17z_(U)
4-3. Bluetooth®
Communication between the hands-free unit and a device (Mobile
phone) is canceled, and the line can be switched to a standard call
using a device (Mobile phone).Press the talk button with a short press.
Say: [Beep] “Transfer call”
Prompt: “Transferred call to phone”
Communication between devices (Mobile phone) can be switched to
Bluetooth
® Hands-Free.
Press the talk button with a short press.
Say: [Beep] “Transfer call”
Prompt: “Transferred call to Hands Free system”
A call can be interrupted to receive an incoming call from a third party.
Switch to a new incoming call using the following methods.
Method 1: Press the pick-up button.
Prompt: “Swapping calls.”
Method 2: Press the talk button with a short press.
Say: [Beep] “Swap calls”
Prompt: “Swapping calls.”
●To refuse an incoming call, press the hang-up button.
● After receiving a new incoming call, the previous call is placed on hold.
Transferring a Call from Hands- Fr ee to a Device (Mobile Phone)
Transferring a Call from a Device (Mobile Phone) to Hands-Free
Call interrupt
1
2
3
1
2
3
1
2
1
2
3

iA_OM_OM99M17z_(U)
3694-3. Bluetooth®
4
Interior Features
■Switching calls
Switching back to the previous call can also be done.
Method 1:Press the pick-up button.
Prompt: “Swapping calls.”
Method 2: Press the talk button with a short press.
Say: [Beep] “Swap calls”
Prompt: “Swapping calls.”
■Three-way call functionPress the talk button with a short press.
Say: [Beep] “Join calls”
Prompt: “Joining calls”
■Making a call using a telephone numberPress the talk button with a short press.
Say: [Beep] “Dial”
Prompt: “Number, please”
Say: [Beep] “XXXXXXXXXXX (Telephone number)”
Prompt: “XXXXXXXXXXX. (Teleph one number) After the beep,
continue to add numbers, or sa y Go-Back to re-enter the last
entered numbers, or press the Pick-Up button to execute dial-
ing.”
(Dialing)
Press the pick-up button or say “Dial”, then go to Step 7.
(Adding/inputting telephone number)
Say, “XXXX” (desired telephone number), then go to Step 5.
(Telephone number correction) Say, “Go Back”. The prompt
replies, “Go Back. The last entered numbers have been
removed.”. Then go back to Step 3.
Prompt: “Dialing”
1
2
1
2
3
1
2
3
1
2
3
4
5
6
7

370
iA_OM_OM99M17z_(U)
4-3. Bluetooth®
■Making calls using the phonebookPress the talk button with a short press.
Say: [Beep] “Call”
Prompt: “Name please.”
Say: [Beep] “XXXXX... (Ex. “J ohn’s phone”)” (Say a voice tag
registered in the phonebook.)
Prompt: “Calling XXXXX... (Ex. “John’s phone”) XXXX (Ex. “at
home”). Is this correct?” (Voice tag and phone number location
registered in phonebook).
Say: [Beep] “Yes”
Prompt: “Dialing”
■Redialing function
Press the talk button with a short press.
Say: [Beep] “Redial”
Prompt: “Dialing”
■Ending the current call
Press the hang-up button during the call.
This function is used when transmi tting DTMF via the user’s voice.
The receiver of a DTMF transmission is generally a home telephone
answering machine or a company’s automated guidance call center
(When you send tone signals back according to the voice guidance
recording).
Press the talk button with a short press.
Say: [Beep] “X XXX... send” (Say DTMF code)
Prompt: “Sending XXXX... (DTMF code)”
DTMF (Dual Tone Multi- Fr equency Signal) Transmission
1
2
3
4
5
6
7
1
2
3
1
2
3
