TOYOTA LAND CRUISER 1996 J80 Workshop Manual

SA1V0−02
R13847
SST
SA−58
−
SUSPENSION AND AXLE FRONT LEADING ARM
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACE BUSHINGS
Using SST and a press, replace the bushing from the leading
arm. SST Front side: 09710−30050
SST Rear side: 09710 −22042 (09710−02061)
HINT:
When assembling a new bushing, as shown in the illustration.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V1−01
−
SUSPENSION AND AXLE FRONT LEADING ARM
SA−59
1996 LAND CRUISER (RM451U)
INSTALLATION
Installation is in the reverse order of removal (See page SA−57 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V2−01
R07756
R08394
R13153
Paint
SA−60
−
SUSPENSION AND AXLE FRONT STABILIZER BAR
917
Author: Date:
1996 LAND CRUISER (RM451U)
FRONT STABILIZER BAR
REMOVAL
1. REMOVE FRONT WHEEL
Torque:
Steel wheel: 147 N·m (1,500 kgf·cm, 109 ft·lbf)
Aluminum wheel: 103 N·m (1,050 kgf·cm, 76 ft·lbf)
2. REMOVE STABILIZER BAR
(a) Remove the nut and disconnect the stabilizer bar with the
link from the bracket.
Torque: 103 N·m (1,050 kgf·cm, 76 ft·lbf)
HINT:
After stabilizing the suspension, torque the nut.
(b) Remove the bolt and nut and remove the stabilizer bar from the axle housing.
Torque: 25 N·m (260 kgf·cm, 19 ft·lbf)
HINT:
After stabilizing the suspension, torque the nut.
(c) Remove the 2 bolts, cover and cushion from the stabilizer
bar.
Torque: 18 N·m (185 kgf·cm, 13 ft·lbf)
HINT:
Install the cushions on the lines painted on the stabilizer bar and
install the covers onto cushions.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V3−01
−
SUSPENSION AND AXLE FRONT STABILIZER BAR
SA−61
1996 LAND CRUISER (RM451U)
INSTALLATION
Installation is in the reverse order of removal (See page SA−60 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V4−01
SA−62
−
SUSPENSION AND AXLE REAR AXLE SHAFT
919
Author: Date:
1996 LAND CRUISER (RM451U)
REAR AXLE SHAFT
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V5−01
−
SUSPENSION AND AXLE REAR AXLE SHAFT
SA−63
1996 LAND CRUISER (RM451U)
REMOVAL
REMOVE REAR AXLE SHAFT
(a) Remove the 6 set nuts and plate washers.
Torque: 34 N·m (340 kgf·cm, 25 ft·lbf)
(b) Using a brass bar and hammer, strike the center part of the axle shaft to remove the 6 cone washers.
(c) Install and gradually tighten 2 bolts evenly and pull the axle shaft.
(d) Remove the 2 bolts from the rear axle shaft.
(e) Remove the rear axle shaft and gasket.
NOTICE:
Be careful not to damage the oil seal.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V6−01
RA0377
SA−64
−
SUSPENSION AND AXLE REAR AXLE SHAFT
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT REAR AXLE SHAFT
(a) Check for wear or damage.
(b) Using a dial indicator, check the runout of axle shaft. Maximum runout: 0.8 mm (0.031 in.)
If the runout is greater than the maximum, replace the axle
shaft.
2. REPLACE OIL SEAL
(a) Using SST, remove the oil seal. SST 09308−00010
(b) Using SST and a hammer, install a new oil seal into the hub.
SST 09517−36010
(c) Apply MP grease to the oil seal lip.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V7−02
−
SUSPENSION AND AXLE REAR AXLE SHAFT
SA−65
1996 LAND CRUISER (RM451U)
INSTALLATION
Installation is in the reverse order of removal (See page SA−63 ).
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V8−01
SA−66
−
SUSPENSION AND AXLE REAR AXLE HUB
923
Author: Date:
1996 LAND CRUISER (RM451U)
REAR AXLE HUB
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

SA1V9−01
−
SUSPENSION AND AXLE REAR AXLE HUB
SA−67
1996 LAND CRUISER (RM451U)
REMOVAL
1. REMOVE REAR WHEEL
2. REMOVE REAR AXLE SHAFT (See page SA−63 )
3. REMOVE BRAKE CALIPER AND DISC (See page BR−34 )
4. DISCONNECT ABS SPEED SENSOR
Remove the bolt and disconnect the ABS speed sensor.
5. REMOVE REAR AXLE BEARING LOCK NUT
(a) Remove the 2 screws from the lock nut.
(b) Using SST, remove the lock nut. SST 09509−25011
6. REMOVE REAR AXLE HUB
(a) Pull out the axle hub, remove the lock nut plate and outer
bearing.
(b) Remove the axle hub.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010
