TOYOTA LAND CRUISER 1996 J80 Workshop Manual

LU0KE−03
LU−2
−
LUBRICATION OIL AND FILTER
1996 LAND CRUISER (RM451U)
REPLACEMENT
CAUTION:
Prolonged and repeated contact with mineral oil will result
in the removal of natural fats from the skin, leading to dry-
ness, irritation and dermatitis. In addition, used engine oil
contains potentially harmful contaminants which may
cause skin cancer.Care should be taken, therefore, when
changing engine oil to minimize the frequency and length
of time your skin is exposed to used engine oil. Protective
clothing and gloves that cannot be penetrated by oil should
be worn. The skin should be thoroughly washed with soap
and water, or use water−less hand cleaner, to remove any
used engine oil. Do not used gasoline, thinners, or sol-
vents.In order to preserve the environment, used oil and
used oil filters must be disposed of only at designated dis-
posal sites.
1. DRAIN ENGINE OIL
(a) Remove the oil filler cap.
(b) Remove the oil drain plug, and drain the oil into a contain-
er.
2. REPLACE OIL FILTER
(a) Using SST, remove the oil filter. SST 09228−44011
(b) Check and clean the oil filter installation surface.
(c) Apply clean engine oil to the gasket of a new oil filter.
(d) Lightly screw the oil filter into place, and tighten it until the
gasket contacts the seat.
(e) Using SST, tighten it an additional 3/4 turn. SST 09228−44011
3. FILL WITH ENGINE OIL
(a) Clean and install the oil drain plug with a new gasket.
Torque: 25 N·m (250 kgf·cm, 18 ft·lbf)
(b) Fill with new engine oil. Oil grade:
See step 1 in oil pressure check
Capacity:
Drain and refill
w/ Oil filter change
7.2 liters (7.5 US qts, 6.3 lmp. qts)
w/o Oil filter change
6.9 liters (7.3 US qts, 6.1 lmp. qts)
Dry fill
8.0 liters (8.5 US qts, 7.0 lmp. qts)
(c) Reinstall the oil filler cap.
4. START ENGINE AND CHECK FOR LEAKS
5. RECHECK ENGINE OIL LEVEL
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KF−04
−
LUBRICATION OIL PUMP
LU−3
714
Author: Date:
1996 LAND CRUISER (RM451U)
OIL PUMP
COMPONENTS
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU−4
−
LUBRICATION OIL PUMP
715
Author: Date:
1996 LAND CRUISER (RM451U)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KG−02
−
LUBRICATION OIL PUMP
LU−5
1996 LAND CRUISER (RM451U)
REMOVAL
HINT:
When repairing the oil pump, the oil pan and strainer should be
removed and cleaned.
1. DRAIN ENGINE OIL
2. REMOVE ENGINE UNDER COVER
3. DRAIN ENGINE COOLANT
4. REMOVE RADIATOR (See page CO−14 )
5. DISCONNECT A/C COMPRESSOR AND BRACKET
(a) Loosen the idler pulley nut and adjusting bolt, and remove
the drive belt.
(b) Remove the 4 mounting bolts, and disconnect the com- pressor from the bracket.
HINT:
Put aside the compressor, and suspend it.
(c) Remove the 5 bolts and A/C compressor bracket.
6. REMOVE RADIATOR PIPE
(a) Disconnect the No.2 radiator hose from the water inlet.
(b) Remove the 2 nuts and radiator pipe.
7. REMOVE WATER PUMP
Remove the 4 bolts, 2 nuts, water pump and gasket.
8. REMOVE CYLINDER HEAD (See page EM−28 )
9. DISCONNECT OIL COOLER PIPE BRACKET FROM NO.1 OIL PAN
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU−6
−
LUBRICATION OIL PUMP
1996 LAND CRUISER (RM451U)
10. REMOVE OIL LEVEL SENSOR
(a) Remove the 4 bolts and level sensor.
(b) Remove the gasket from the level sensor.
11. REMOVE BOLTS HOLDING NO.1 OIL PAN TO TRANS-
MISSION HOUSING
Remove the 6 bolts.
12. REMOVE NO.2 OIL PAN
(a) Remove the 17 mounting bolts and 2 nuts.
(b) Insert the blade of SST between the No.1 and No.2 oil pans, cut off applied sealer and remove the No.2 oil pan.
SST 09032−00100
NOTICE:
Be careful not to damage the No.2 oil pan contact surface
of the No.1 oil pan.Be careful not to damage the oil pan
flange.
13. REMOVE NO.1 OIL PAN
(a) Remove the 21 mounting bolts and 2 nuts.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

P22576
−
LUBRICATION OIL PUMP
LU−7
1996 LAND CRUISER (RM451U)
(b) Remove the No.1 oil pan by prying the portions (A) be-
tween the cylinder block and No.1 oil pan with a screw-
driver.
NOTICE:
Be careful not to damage the contact surfaces of the cylin-
der block and No.1 oil pan.
14. REMOVE OIL PAN BAFFLE PLATE
Remove the bolt, 7 nuts and baffle plate.
15. REMOVE OIL STRAINER
Remove the bolt, 2 nuts, oil strainer and gasket.
16. REMOVE CRANKSHAFT PULLEY (See page EM−13 )
17. REMOVE DRIVE BELT IDLER PULLEY
Remove the bolt and idler pulley.
18. REMOVE OIL PUMP (TIMING CHAIN COVER) (See page EM−13 )
19. REMOVE TIMING CHAIN AND CAMSHAFT TIMING GEAR
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU08R−03
LU−8
−
LUBRICATION OIL PUMP
1996 LAND CRUISER (RM451U)
DISASSEMBLY
1. REMOVE DRIVE AND DRIVEN ROTORS
Remove the 7 screws, pump cover, drive rotor, driven rotor and
gasket.
HINT:
At the time of installation, place a new gasket on the pump body.
2. REMOVE RELIEF VALVE
Remove the plug, gasket, spring and relief valve. Torque: 49 N·m (500 kgf·cm, 36 ft·lbf)
HINT:
At the time of installation, install a new gasket to the plug.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KH−01
−
LUBRICATION OIL PUMP
LU−9
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT RELIEF VALVE
Coat the valve with engine oil and check that it falls smoothly
into the valve hole by its own weight.
If it does not, replace the relief valve. If necessary, replace the
oil pump assembly.
2. INSPECT ROTOR BODY CLEARANCE
Using a thickness gauge, measure the clearance between the
driven rotor and body.
Standard body clearance:
0.100 − 0.170 mm (0.0039 − 0.0067 in.)
Maximum body clearance:
0.30 mm (0.0118 in.)
If the body clearance is greater than maximum, replace the ro-
tors as a set. If necessary, replace the oil pump assembly.
3. INSPECT ROTOR SIDE CLEARANCE
Using a thickness gauge and precision straight edge, measure
the clearance between the rotors and precision straight edge. Standard side clearance:
0.030 − 0.090 mm (0.0012 − 0.0035 in.)
Maximum side clearance:
0.15 mm (0.0059 in.)
If the side clearance is greater than maximum, replace the ro-
tors as a set. If necessary, replace the oil pump assembly.
4. INSPECT ROTOR TIP CLEARANCE
Using a thickness gauge, measure the clearance between the
drive and driven rotor tips. Standard tip clearance:
0.030 − 0.160 mm (0.0012 − 0.0063 in.)
Maximum tip clearance:
0.25 mm (0.0098 in.)
If the tip clearance is greater than maximum, replace the rotors
as a set.
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU08T−03
LU−10
−
LUBRICATION OIL PUMP
1996 LAND CRUISER (RM451U)
REPLACEMENT
REPLACE CRANKSHAFT FRONT OIL SEAL (See page EM−99)
Brought to you by BirfMark
Brought to you by BirfMark
Version 1.11 - 03/16/2010

LU0KJ−01
−
LUBRICATION OIL PUMP
LU−11
1996 LAND CRUISER (RM451U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page LU−8 ).
