LUBRICATION OIL NOZZLE
1996 LAND CRUISER (RM451U)
INSPECTION
1. INSPECT CHECK VALVES
Push the valve with a wooden stick to check if it is stuck.
If stuck, replace the check valve.
2. INSPECT OIL NOZZLES
Check the oil nozzles for damage or clogging.
If necessary, replace the oil nozzle.
