TOYOTA LAND CRUISER 1998 Factory Repair Manual
Manufacturer: TOYOTA, Model Year: 1998, Model line: LAND CRUISER, Model: TOYOTA LAND CRUISER 1998Pages: 3115, PDF Size: 54.88 MB
Page 1171 of 3115
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Case 1
Case 2
Case 3
Case 4
Output voltage of heated oxygen
sensor (sensor 1: front sensor)
Injection volume
Output voltage
Output voltage of heated oxygen
sensor (sensor 2: rear sensor)Mainly suspect
trouble area
OK
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
Sensor 1: front sensor
(sensor 1, heater, sensor 1
circuit)
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NGExtremely rich or lean of the
actual air-fuel ratio
(Injector, fuel pressure, gas
leakage in exhaust system,
etc.) OK
OK
OK
Almost no reaction
'
Sensor 2: rear sensor
(sensor 2, heater, sensor 2
circuit)
Almost no reactionAlmost no reaction
Almost no reaction
DI-122
- DIAGNOSTICSENGINE
315 Author: Date:
2004 LAND CRUISER (RM1071U)
The following A/F CONTROL procedure enables the technician to check and graph the voltage output of
the heated oxygen sensors (sensor 1 and 2).
For displaying the graph indication, enter ºACTIVE TEST / A/F CONTROL / USER DATAº then select ºO2S
B1S1 and O2S B1S2º by pressing ºYESº button and push ºENTERº button before pressing ºF4º button.
NOTICE:
If the vehicle is short of fuel, the air-fuel ratio becomes LEAN and DTCs P0133 and/or P0153 will be
recorded, and the MIL then comes on.
If different DTCs related to different systems while terminal E2 as ground terminal are output simulta-
neously, terminal E2 may be open.
Read freeze frame data using the hand-held tester or the OBD II scan tool. Freeze frame data records
the engine conditions when a malfunction is detected. When troubleshooting, it is useful for determin-
ing whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio
was lean or rich, etc. at the time of the malfunction.
A high heated oxygen sensor (sensor 1) voltage (0.5 V or more) could be caused by a rich air fuel mix-
ture. Check for conditions that would cause the engine to run rich.
A low heated oxygen sensor (sensor 1) voltage (0.4 V or less) could be caused by a lean air fuel mix-
ture. Check for conditions that would cause the engine to run lean.
Page 1172 of 3115
- DIAGNOSTICSENGINE
DI-123
316 Author: Date:
2004 LAND CRUISER (RM1071U)
1 Are there any other codes (besides DTC P0133 or P0153) being output?
PREPARATION:
(a) Connect the hand-held tester or the OBD II scan tool to the DLC3.
(b) Turn the ignition switch ON and push the hand-held tester or OBD II scan tool main switch ON.
(c) When using hand-held tester, enter the following menus: DIAGNOSIS / ENHANCED OBD II / DTC
INFO / CURRENT CODES.
CHECK:
Read the DTC using the hand-held tester or the OBD II scan tool.
RESULT:
Display (DTC Output)Proceed to
ºP0133 and/or P0153ºA
ºP0133 or P0153º and other DTCsB
HINT:
If any other codes besides ºP0133 and/or P0153º are output, perform the troubleshooting for those DTCs
first.
B Go to relevant DTC chart (See page DI-36).
A
Page 1173 of 3115
A20315
0.45V
0.35V
DI-124
- DIAGNOSTICSENGINE
317 Author: Date:
2004 LAND CRUISER (RM1071U)
2 Check output voltage of heated oxygen sensor during idling.
PREPARATION:
(a) Warm up the heated oxygen sensor with the engine speed at 2,500 rpm for approximately 90 seconds.
(b) Connect the hand-held tester or OBD II scan tool to the DLC3.
(c) When using hand-held tester, enter the following menu: DIAGNOSIS / ENHANCED OBD II / DATA
LIST / ALL / O2S B1 S1 or B2 S1.
CHECK:
Check the output voltage of the heated oxygen sensor while idling the OBD II scan tool or hand-held tester.
OK:
Heated oxygen sensor output voltage:
Alternates between less than 0.35 V and more than 0.45 V, and period of ºtº must exist less than
0.6 seconds (See the following table).
OK Go to step 9.
NG
Page 1174 of 3115
A20870
E1 +B
OX
+BHT
OX E1HT H5
H7
H6
H8
Components Side:
Bank1 Sensor1, Bank2 Sensor1
Bank1 Sensor2, Bank2 Sensor2
A21543
1
23
4 EFI or ECD Relay
- DIAGNOSTICSENGINE
DI-125
318 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check resistance of heated oxygen sensor heater.
PREPARATION:
Disconnect the H5, H6, H7 or H8 heated oxygen sensor con-
nector.
CHECK:
Measure resistance between terminals of the heated oxygen
sensor.
OK:
Tester ConnectionSpecified Condition
HT (H5-1) - +B (H5-2)11 to 16 W (20°C)
HT (H6-1) - +B (H6-2)11 to 16 W (20°C)
HT (H7-1) - +B (H7-2)11 to 16 W (20°C)
HT (H8-1) - +B (H8-2)11 to 16 W (20°C)
NG Replace heated oxygen sensor.
OK
4 Check EFI or ECD relay.
PREPARATION:
Remove the EFI or ECD relay from the engine room R/B.
CHECK:
Inspect the EFI or ECD relay.
OK:
Terminal No.ConditionSpecified Condition
2 - 4ConstantContinuity
UsuallyNo Continuity
1 - 3Apply B+ between
terminals 2 and 4Continuity
NG Replace EFI or ECD relay.
OK
Page 1175 of 3115
A20870
E1 +B
OX
+BHT
OX E1HT H5
H7
H6
H8
Components Side:
Bank1 Sensor1, Bank2 Sensor1
Bank1 Sensor2, Bank2 Sensor2
A19522A19630ECM Connector HT1BHT1A
OX1A
OX2A
HT2BHT2AOX1B E6
OX2B
DI-126
- DIAGNOSTICSENGINE
319 Author: Date:
2004 LAND CRUISER (RM1071U)
5 Check for open and short in harness and connector between ECM and heated
oxygen sensor.
PREPARATION:
(a) Disconnect the H5, H6, H7 or H8 heated oxygen sensor
connector.
(b) Disconnect the E6 ECM connector.
CHECK:
Measure the resistance between the wire harness side connec-
tors.
OK:
Tester ConnectionSpecified Condition
OX (H5-3) - OX1A (E6-23)Below 1 W
HT (H5-1) - HT1A (E6-4)Below 1 W
OX (H6-3) - OX1B (E6-29)Below 1 W
HT (H6-1) - HT1B (E6-5)Below 1 W
OX (H7-3) - OX2A (E6-22)Below 1 W
HT (H7-1) - HT2A (E6-33)Below 1 W
OX (H8-3) - OX2B (E6-21)Below 1 W
HT (H8-1) - HT2B (E6-25)Below 1 W
OX (H5-3) or OX1A (E6-23) -
Body ground10 kW or higher
HT (H5-1) or HT1A (E6-4) -
Body ground10 kW or higher
OX (H6-3) or OX1B (E6-29) -
Body ground10 kW or higher
HT (H6-1) or HT1B (E6-5) -
Body ground10 kW or higher
OX (H7-3) or OX2A (E6-22) -
Body ground10 kW or higher
HT (H7-1) or HT2A (E6-33) -
Body ground10 kW or higher
OX (H8-3) or OX2B (E6-21) -
Body ground10 kW or higher
HT (H8-1) or HT2B (E6-25) -
Body ground10 kW or higher
Page 1176 of 3115
A21040
Reference (Bank 1 Sensor 1 System Drawing)
From
BatteryEFI or ECD
No. 1 FuseEFI or ECD
RelayEFI or ECD
No. 2 FuseHeater Oxygen
Sensor
Heater
SensorHT1A
OX1A
E2
MRELECM
- DIAGNOSTICSENGINE
DI-127
320 Author: Date:
2004 LAND CRUISER (RM1071U)
NG Repair or replace harness or connector.
OK
6 Check air induction system (See page SF-1).
CHECK:
Check the air induction system for vacuum leaks.
NG Repair or replace air induction system.
OK
7 Check fuel pressure (See page SF-7).
CHECK:
Check the fuel pressure (high or low pressure).
NG Check and repair fuel pump, pressure regulator,
fuel pipe line and filter (See page SF-1).
OK
Page 1177 of 3115
DI-128
- DIAGNOSTICSENGINE
321 Author: Date:
2004 LAND CRUISER (RM1071U)
8 Check injector injection (See page SF-24).
NG Replace injector.
OK
Replace heated oxygen sensor.
9 Perform confirmation driving pattern (See page DI-106).
HINT:
Clear all DTCs prior to performing the confirmation driving pattern.
Go
10 Is there DTC P0133 or P0153 being output again?
NO Check for intermittent problems
(See page DI-3).
YES
Replace heated oxygen sensor.
Page 1178 of 3115
- DIAGNOSTICSENGINE
DI-129
322 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC P0134 Oxygen Sensor Circuit No Activity Detected
(Bank 1 Sensor 1)
DTC P0154 Oxygen Sensor Circuit No Activity Detected
(Bank 2 Sensor 1)
CIRCUIT DESCRIPTION
Refer to DTC P0031 on page DI-49.
DTC No.DTC Detecting ConditionTrouble Area
P0134
P0154
After the engine is warmed up, heated oxygen sensor (bank 1,
sensor 1) output does not indicate RICH (more than 0.45 V)
even once when the following conditions continue for 65 sec.
or more:
(a) Engine speed: 1,400 rpm or more
(b) Vehicle speed: 25 to 81 mph (40 to 130 km/h) or more
(c) Throttle valve does not fully closed
(d) 180 sec. or more after starting engine
(e) Engine coolant temperature more than 40°C (104°F)
Open or short in heated oxygen sensor circuit
Heated oxygen sensor
Heated oxygen sensor heater
EFI or ECD relay
Air induction system
Fuel pressure
PCV hose connection
PCV valve and hose
Injector
Gas leakage on exhaust system
PCV piping
ECM
HINT:
Bank 1 refers to bank that includes cylinder No. 1.
Bank 2 refers to bank that does not includes cylinder No. 1.
Sensor 1 refers to the sensor closer to the engine assembly.
After confirming DTC P0134 and P0154, check the output voltage of the heated oxygen sensor in the
"DIAGNOSIS / ENHANCE OBD II / DATA LIST / ALL" using the OBD II scan tool or the hand-held tester.
If output voltage of the heated oxygen sensor is always less than 0.1 V, heated oxygen sensor circuit
may be open or short.
MONITOR DESCRIPTION
The ECM uses the heated oxygen sensor to optimize the air-fuel mixture in closed-loop fuel control. This
control helps decrease exhaust emissions by providing the catalyst with a nearly stoichiometric mixture.
The sensor detects the oxygen level in the exhaust gas and the ECM uses this data to control the air-fuel
ratio. The sensor output voltage ranges from 0 V to 1 V. If the signal voltage is less than 0.4 V, the air-fuel
ratio is LEAN. If the signal voltage is more than 0.55 V, the air-fuel ratio is RICH. If the conditions for the
closed-loop fuel control are met and after a specified time-period, the sensor's output signal never indicates
RICH, the ECM will conclude that the closed-loop fuel control is malfunctioning. The ECM will illuminate the
MIL and a DTC is set.
DIC28-01
Page 1179 of 3115
DI-130
- DIAGNOSTICSENGINE
323 Author: Date:
2004 LAND CRUISER (RM1071U)
MONITOR STRATEGY
RltdDTCP0134Excessive time to enter closed loop (Bank 1)Related DTCsP0154Excessive time to enter closed loop (Bank 2)
Main sensors/componentsFront heated oxygen sensor
Required sensors/componentsRelated sensors/componentsCrank position sensor, Engine coolant tempera-
ture sensor, Vehicle speed sensor
Frequency of operationOnce per drive cycle
Duration65 sec.
MIL operation1 driving cycle
Sequence of operationNone
TYPICAL ENABLING CONDITIONS
ItSpecificationItemMinimumMaximum
The monitor will run whenever the follow-
ing DTCs are not presentSee ºList of disable a monitorº (on page DI-3)
Both of the following conditions were metA and B
A. Time after following conditions met for
50 sec.(a), (b), (c), (d), (e) and (f)
(a) Engine coolant temperature40C (104°F)-
(b) Engine speed1,400 rpm-
(c) Vehicle speed40 km/h (25 mph)-
(d) IdleOFF
(e) Time after engine start180 sec.-
(f) Fuel enrichment correction factor163.998
B. Neither fail nor pass is determined yet in the present drive cycle
TYPICAL MALFUNCTION THRESHOLDS
Detection CriteriaThreshold
Front heated oxygen sensor voltageLess than 0.45 V
COMPONENT OPERATING RANGE
ParameterStandard value
In the normal condition, the front heated oxygen sensor
voltage0 to 1 V
WIRING DIAGRAM
Refer to DTC P0031 on page DI-49.
Page 1180 of 3115
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Case 1
Case 2
Case 3
Case 4
Output voltage of heated oxygen
sensor (sensor 1: front sensor)
Injection volume
Output voltage
Output voltage of heated oxygen
sensor (sensor 2: rear sensor)Mainly suspect
trouble area
OK
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
Sensor 1: front sensor
(sensor 1, heater, sensor 1
circuit)
+25 %
-12.5 %
More than 0.5 V
Less than 0.4 V
Injection volume
Output voltage
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NG
+25 %
-12.5 %
Injection volume
Output voltage
NGExtremely rich or lean of the
actual air-fuel ratio
(Injector, fuel pressure, gas
leakage in exhaust system,
etc.) OK
OK
OK
Almost no reaction
'
Sensor 2: rear sensor
(sensor 2, heater, sensor 2
circuit)
Almost no reaction
Almost no reaction Almost no reaction
- DIAGNOSTICSENGINE
DI-131
324 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
HINT:
Hand-held tester only:
The narrowing down the trouble area is possible by performing ACTIVE TEST of the following ºA/F CON-
TROLº (Heated oxygen sensor or another can be distinguished).
(a) Perform ACTIVE TEST by hand-held tester (A/F CONTROL).
HINT:
ºA/F CONTROLº is the ACTIVE TEST which changes the injection volume to -12.5 % or +25 %.
(1) Connect the hand-held tester to the DLC3 on the vehicle.
(2) Turn the ignition switch ON.
(3) Warm up the engine with the engine speed at 2,500 rpm for approximately 90 seconds.
(4) Select the item ºDIAGNOSIS / ENHANCED OBD II / ACTIVE TEST / A/F CONTROLº.
(5) Perform ºA/F CONTROLº with the engine in an idle condition (press the right or left button).
RESULT:
Heated oxygen sensor reacts in accordance with increase and decrease of injection volume
+25 % " rich output: More than 0.5 V
-12.5 % " lean output: Less than 0.4 V
NOTICE:
However, there is a few seconds delay in the sensor 1 (front sensor) output. And there is about 20
seconds delay in the sensor 2 (rear sensor).
