TOYOTA LAND CRUISER 1998 Factory Repair Manual

I06746
AC1LN-04
- AIR CONDITIONINGROOM TEMPERATURE SENSOR (for Front A/C)
AC-87
2812 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ROOM TEMPERATURE SENSOR
(for Front A/C)
INSPECTION
1. REMOVE ROOM TEMPERATURE SENSOR
(a) Remove the lower No. 1 panel set screw.
(b) Release the lower No. 1 panel set claws.
(c) Disconnect the connector and the aspirator hose.
(d) Remove the screw and the room temperature sensor.
2. INSPECT ROOM TEMPERATURE SENSOR CIRCUIT
(See page DI-1316)
3. INSTALL ROOM TEMPERATURE SENSOR
(a) Install the room temperature sensor to the lower No. 1
panel with the screw.
(b) Connect the aspirator hose and the connector.
(c) Install the lower No. 1 panel with the screw.

I06748
AC1LO-05
AC-88
- AIR CONDITIONINGROOM TEMPERATURE SENSOR (for Rear A/C)
2813 Author
: Date
:
2004 LAND CRUISER (RM1071U)
ROOM TEMPERATURE SENSOR
(for Rear A/C)
INSPECTION
1. REMOVE ROOM TEMPERATURE SENSOR
Using a scrwedriver, pull out the room temperature sensor, then
disconnect the connector.
HINT:
Tape the screwdriver tip before use.
2. INSPECT ROOM TEMPERATURE SENSOR
(See page DI-1330)
3. INSTALL ROOM TEMPERATURE SENSOR
(a) Connect the connector.
(b) Insert the room temperature sensor to the roof headlining.

I06809
AC1LM-05
AC-86
- AIR CONDITIONINGSOLAR SENSOR
2811 Author
: Date
:
2004 LAND CRUISER (RM1071U)
SOLAR SENSOR
INSPECTION
1. REMOVE SOLAR SENSOR
Using a screwdriver, pull out the solar sensor, then disconnect
the connector.
HINT:
Tape up the screwdriver tip before use.
2. INSPECT SOLAR SENSOR CIRCUIT
(See page DI-1333)
3. INSTALL SOLAR SENSOR
(a) Connect the connector.
(b) Insert the solar sensor to the instrument panel.

AT07I-05
D13117N´m (kgf´cm, ft´lbf) : Specified torqueClip
Oil Cooler PipeClip
Clip
Clip
Clip
Oil Cooler Stay
Oil Cooler
12 (122, 9)
Oil Cooler Bracket
Radiator Grille Sub-assy
7.5 (76, 66 in.´lbf)
7.5 (76, 66 in.´lbf)
Power Steering
Oil Cooler Sub-assy
Oil Cooler Bracket
5.0 (51, 44 in.´lbf)
5.0 (51, 44 in.´lbf)5.0 (51, 44 in.´lbf)
5.0 (51, 44 in.´lbf)
5.0 (51, 44 in.´lbf)
12 (122, 9)
12 (122, 9)
AT-16
- AUTOMATIC TRANSMISSIONAIR COOLED OIL COOLER
1870 Author
: Date
:
2004 LAND CRUISER (RM1071U)
AIR COOLED OIL COOLER
COMPONENTS

AT07K-05
- AUTOMATIC TRANSMISSIONAIR COOLED OIL COOLER
AT-19
1873 Author
: Date
:
INSTALLATION
Installation is in the reverse order of removal (See page AT-17).
HINT:
After installtion, check fluid level (See page AT-3-1).

AT113-01
D12665
D01688
D01689
D01690
- AUTOMATIC TRANSMISSIONAIR COOLED OIL COOLER
AT-17
1871 Author
: Date
:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE RADIATOR GRILLE SUB-ASSY
(a) Remove the 3 screws.
(b) Release the 2 clips and remove the radiator grille sub-
assy.
2. SEPARATE POWER STEERING OIL COOLER SUB-
ASSY
Remove the 2 bolts and separate the power steering oil cooler
sub-assy .
Torque: 7.5 N´m (76 kgf´cm, 66 in.´lbf)
3. REMOVE OIL COOLER
(a) Loosen the 2 clips and disconnect the 2 hoses.
(b) Remove the 4 bolts and oil cooler.
Torque: 12 N´m (117 kgf´cm, 8 ft´lbf)
(c) Remove the 8 bolts, the 2 oil cooler brackets and the 2
stays.
Torque: 4.9 N´m (50 kgf´cm, 43 in.´lbf)

D12666
D01692
AT-18
- AUTOMATIC TRANSMISSIONAIR COOLED OIL COOLER
1872 Author
: Date
:
2004 LAND CRUISER (RM1071U)
4. REMOVE OIL COOLER PIPE BRACKET
(a) Loosen the 2 clips and disconnect the 2 hoses.
(b) Remove the 2 bolts and the oil cooler pipe bracket.
Torque: 4.9 N´m (50 kgf´cm, 43 in.´lbf)
(c) Loosen the 2 clips and disconnect the 2 hoses.

AT10Z-02
D12704
A B
OrangeBlue
D12739
D12704
A B
OrangeBlue AT-6
- AUTOMATIC TRANSMISSIONATF TEMPERATURE SENSOR
1860 Author
: Date
:
ATF TEMPERATURE SENSOR
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN (See page AT-1 1)
4. REMOVE OIL STRAINER (See page AT-1 1)
5. REMOVE ATF TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid valve connectors.
(b) Remove the 2 bolts and disconnect the 2 ATF tempera-
ture sensors.
(c) Disconnect the solenoid connector.
(d) Remove the bolt and the transmission wire harness.
6. INSTALL ATF TEMPERATURE SENSOR
(a) Install the transmission wire harness.
(b) Install the bolt.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(c) Connect the solenoid connector.
(d) Connect the 7 solenoid valve connectors.
(e) Connect the 2 ATF temperature sensors with the 2 bolts.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp warning lampBlue
7. INSTALL OIL STRAINER (See page AT-8)
8. INSTALL OIL PAN (See page AT-8)
9. FILL ATF AND CHECK ATF LEVEL (See page AT-3-1)
10. INSTALL ENGINE NO.2 UNDER COVER

AT07M-02
D12728
Clutch No.2 (C2) Clutch No.3 (C
3)
Clutch No.1 (C
1)One-way Clutch
No.1 (F1)
One-way Clutch
No.2 (F
2)
Brake No.3
(B
3)
Brake No.1 (B1)
Brake No.2 (B2)One-way Clutch
No.3 (F
3)Brake No.4 (B4)
Shift Solenoid Valve SLT
Shift Solenoid Valve SL1Shift Solenoid Valve S1
Shift Solenoid Valve S2Shift Solenoid Valve SR Shift Solenoid Valve SL2Shift Solenoid Valve SLU
AT-2
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
1853 Author
: Date
:
2004 LAND CRUISER (RM1071U)
OPERATION

SL1
Park
Reverse
Neutral
1st
2nd
4th
5th
1st
4th
1st
3rd
1st
1st
S1C1C2B1B2B3B4F3F1F2
: Operating
Gear
Position Shift Lever
Position
2nd
2nd
2nd3rd 3rd
R
N
D
4
3
2
L P
S2 SR
SL2C3SLU
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
xx
x
x
x
x
x
x
x
x
x
x
x
x
x x
x
x x x
x x
x
x x
x x
xx
x
x
xx
x
x
x
x
xx
x
x
x
x
x
xx
x
x
x
x
x x
x
x
F1, F2, F3 : Operate only when drivingx
- AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM
AT-3
1854 Author
: Date
:
2004 LAND CRUISER (RM1071U)
