Page 1451 of 3115
I01190
DLC1
TC E1
BR3904
Normal code
0.25 Sec. 0.25 Sec.
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI-1005
1198 Author: Date:
2004 LAND CRUISER (RM1071U)
2. INSPECT DIAGNOSIS
(a) Check the DTC (Using hand-held tester).
(1) Prepare hand-held tester.
(2) Connect hand-held tester to DLC3 under the instru-
ment panel lower pad.
(3) Turn the ignition switch ON and turn hand-held tes-
ter switch ON.
(4) Use hand- held tester to check the DTCs. and
ºSnap-shot functionº which records the monitor
data (For operating instructions, see the hand-held
tester instruction book.).
(5) See page DI-1007 to confirm the details of the
DTCs.
(b) Check the DTC (Using diagnosis check wire).
(1) Turn ignition switch ON.
(2) Using SST, connect between terminals 11 (TC) and
3 (E1) of DLC1.
SST 09843-18020
(3) Read the diagnostic trouble code from malfunction
indicator lamp.
HINT:
If a diagnostic trouble code is not output, check the TC ter-
minal circuit.
ECM controls the immobiliser function on this vehicle,
DTC is out put with engine data.
As an example, the blinking patterns for codes; normal,
12 and 99 are shown in the charts.
Page 1452 of 3115
I02680
Malfunction Code (Example Code 12, 99)
0.5 Sec. 0.5 Sec.
1.5 Sec. 2.5 Sec.
One Cycle4.5 Sec. DI-1006
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1199 Author: Date:
2004 LAND CRUISER (RM1071U)
(4) When DTC º99º is output, there is a trouble of
immobiliser. Start troubleshooting referring to
PROBLEM SYMPTOMS TABLE.
(5) After completing the check, disconnect terminals 11
(TC) and 3 (E1) and turn off the display.
HINT:
In the event of 2 or more malfunction codes, indication will begin
from the smaller numbered code and continue in order to the
larger.
(c) Clear the DTC.
The following operations will erase the DTCs and freeze
frame data.
(1) Operating the hand-held tester to erase the codes
(See the hand-held tester instruction book for oper-
ating instructions.).
(2) Disconnecting the battery terminals or EFI fuse.
3. CHECK HAND-HELD TESTER
(a) ECU DATA MONITOR
(1) Make a judgement of good or bad and find out a malfunctioning part by the data monitor.
Standard:
TRANSPONDER KEY ECU
ItemConditionSpecified Condition
IMMOBILISERIgnition switch ON " When key is not inserted in
the ignition switch cylinderUNSET/SET
MASTER KEYIgnition switch ON with master key " Pull out
key from ignition switch cylinderCORRESP/WRONG
SUB KEYIgnition switch ON with sub-key " Pull out key
from ignition switch cylinderCORRESP/WRONG
REGIST MAS CODE-0 - 3
REGIST SUB CODE-0 - 1
KEY SWIgnition switch ON "Without keyON/OFF
IG SWIgnition switch ON "OFFON/OFF
(b) ACTIVE TEST
(1) Make a judgement of good or bad and find out a malfunctioning part by the active test.
Standard:
TRANSPONDER KEY ECU
ItemOperation
SECURITY INDICON / OFF
Page 1453 of 3115
DI1AP-34
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI-1013
1206 Author: Date:
2004 LAND CRUISER (RM1071U)
PROBLEM SYMPTOMS TABLE
SymptomSuspect AreaSee page
Immobiliser is not set.
(Engine starts with key codes other than the registered key code.)1. Transponder key ECUIN-36
Engine does not start.
1. Key
2. Wire harness
3. Transponder key coil
4. Amplifier
5. Transponder key ECU
6. ECM*1
IN-36
BE-196
IN-36
Security indicator is always ON.
1. Multi-display (security indicator)
2. Wire harness
3. Transponder key ECU*2
IN-36
IN-36
Security indicator is always ON.
(Although code has been registered in the automatic registration
mode, indicator is not OFF.)1. Wire harness
2. Transponder key amplifier with coil
3. Transponder key ECUIN-36
BE-196
IN-36
Security indicator is OFF.
(When DTC of immobiliser is output)1. Wire harness
2. Transponder key amplifier with coil
3. Transponder key ECUIN-36
BE-196
IN-36
Security indicator is OFF.
(When DTC of immobiliser is not output)
1. Multi-display (security indicator)
2. Diagnosis circuit
3. Wire harness
4. Transponder key ECU
IN-36
IN-36
Security indicator is abnormally blinking.1. Wire harness
2. Transponder key ECUIN-36
IN-36
No code is output.1. Power source circuit
2. Transponder key ECUDI-1031
IN-36
*1 : Check that the key which did not start the engine has been registered and that it is possible to start with
other already registered key.
*2 : Finish the automatic registration mode because the mode might still remain.
Page 1454 of 3115
DIB5W-01
I25609
T19
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI-1009
1202 Author: Date:
2004 LAND CRUISER (RM1071U)
TERMINALS OF ECM
1. TRANSPONDER KEY ECU
(a) Disconnect the transponder key ECU connector.
Standard:
Symbols (Terminal No.)Wiring ColorConditionSpecified condition
T19-14 Body ground
(GND
Body ground)W-B e Body groundConstantContinuity
T19-1 T19-14
(+B
GND)L-W e W-BConstant10 - 14 V
T19-2 T19-14
(IG
GND)B-R e W-BIgnition switch OFF "ON0 V " 10 - 14 V
T19-10 T19-14
(KSW
GND)R-B e W-BNo key in the ignition key cylinder " With keyNo Continuity " Continuity
T19-4 T19-14
(CTY
GND)R-Y eW-BDriver's door close " openNo Continuity " Continuity
T19-10 T19-14
(KSW
GND)R-B e W-BNo key in the ignition key cylinder " With key10 - 14 V " 0 V
T19-8 T19-14
(VC5
GND)Y e W-BIgnition switch OFF "ON0 V " 5 V
T19-12 T19-14
(TXCT
GND)V-G e W-BIgnition switch OFF "ONWaveform 1
T19-1 1 T19-14
(CODE
GND)L-B e W-BIgnition switch OFF "ONWaveform 2
T19-6 T19-14
(EFIO
GND)W e W-BIgnition switch OFF "ONWaveform 3
T19-7 T19-14
(EFII
GND)Y e W-BIgnition switch OFF "ONWaveform 4
T19-3 T19-14
(IND
GND)G-R e W-BImmobiliser system unset " set0 V "
10 - 14 V e 0 V
T19-4 T19-14
(CTY
GND)R-Y e W-BDriver's door close " open10 - 14 V " 0 V
Page 1455 of 3115
I25610
5 V20 ms
I25611
10 V20 ms
I25613
5 V5 ms
I25614
5 V5 ms DI-1010
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1203 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Inspection using osilloscope.
Referece:
(c) Waveform 1
ItemCondition
TerminalTXCT - GND
Tool setting5 V/DIV, 20 ms/DIV
Vehicle conditionIgnition switch ON
Referece:
(d) Waveform 2
ItemCondition
TerminalCODE - GND
Tool setting10 V/DIV, 20 ms/DIV
Vehicle conditionIgnition switch ON
Referece:
(e) Waveform 3
ItemCondition
TerminalEFIO - GND
Tool setting5 V/DIV, 5 ms/DIV
Vehicle conditionIgnition switch ON
Referece:
(f) Waveform 4
ItemCondition
TerminalEFII - GND
Tool setting5 V/DIV, 5 ms/DIV
Vehicle conditionConstant
Page 1456 of 3115
I25615
E5E6
E7E8
E9
I25613
5 V5 ms
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
DI-101 1
1204 Author: Date:
2004 LAND CRUISER (RM1071U)
2. ECM
Symbols (Terminal No.)Wiring ColorConditionSpecified condition
E9-3 e E7-1
(BATT e E1)B-R e BRConstant9 - 14 V
E9-1 e E7-1
(+B e E1)B-Y e BRIgnition switch OFF "ON9 - 14 V
E9-2 e E7-1
(+B2 e E1)B-Y e BRIgnition switch OFF "ON9 - 14 V
E9-9 e E7-1
(IGSW e E1)B-R e BRIgnition switch OFF "ON9 - 14 V
E8-27 e E7-1
(IMI e E1)W e BRNo key in the ignition key cylinder " With keyWaveform 1
E8-26 e E7-1
(IMO e E1)Y e BRNo key in the ignition key cylinder " With keyWaveform 2
E7-1 e Body ground
(E1 e Body ground)BR e Body groundConstantContinuity
(a) Inspection using osilloscope.
Referece:
(b) Waveform 1
ItemCondition
TerminalIMI - GND
Tool setting5 V/DIV, 5 ms/DIV
Vehicle conditionIgnition switch ON
Page 1457 of 3115
I25614
5 V5 ms DI-1012
- DIAGNOSTICSENGINE IMMOBILISER SYSTEM
1205 Author: Date:
2004 LAND CRUISER (RM1071U)
Referece:
(c) Waveform 2
ItemCondition
TerminalIMO - GND
Tool setting5 V/DIV, 5 ms/DIV
Vehicle conditionConstant
Page 1458 of 3115
F17299
Tilt & Telescopic ECU
BatteryALTJ/B No.3
F17B-G
3D
GND W-B J1
J/C
T7 TIL&TEL
+B T8 38
3C14
6
IICowl Side J/B RH
Cowl Side J/B RH1 FL Block
3D 42
W-BG-B
A
A DI-676
- DIAGNOSTICSPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
869 Author: Date:
2004 LAND CRUISER (RM1071U)
Actuator Power Source Circuit
CIRCUIT DESCRIPTION
This is the power source for the motors.
WIRING DIAGRAM
DI23L-17
Page 1459 of 3115
F05350
LOCK
GND+B
(+) (-)
F05349
LOCK
GND
(-)(+)
- DIAGNOSTICSPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNDI-677
870 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check voltage between terminals +B and GND of ECU connector.
PREPARATION:
Remove ECU with connectors still connected.
CHECK:
Measure voltage between terminals +B and GND of ECU con-
nector.
OK:
Voltage: 8 - 16 V
OK Proceed to next circuit inspection shown on the
problem symptoms table (See page DI-663).
NG
2 Check continuity between terminal GND of ECU connector and body ground.
CHECK:
Measure resistance between terminal GND of ECU connector
and body ground.
OK:
Resistance: 1 kW or less
NG Repair or replace harness or connector.
OK
Page 1460 of 3115
DI-678- DIAGNOSTICSPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
871 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check POWER fuse.
PREPARATION:
Remove POWER fuse from passenger side J/B.
CHECK:
Check continuity of POWER fuse.
OK:
Continuity
NG Check for short circuit in harness and all com-
ponents connected to POWER fuse.
OK
Check for open circuit in harness and con-
nector between ECU and battery
(See page IN-36).
