SR1IK-01
F17215SST
F17216
F17218
- STEERINGPOWER STEERING VANE PUMP
SR-41
2250 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. FIX VANE PUMP ASSEMBLY
Using SST, hold the vane assembly in a vise.
SST 09630-00014 (09631-00132)
2. MEASURE PS VANE PUMP ROTATING TORQUE
(a) Check that the pump rotates smoothly without abnormal
noise.
(b) Temporarily install the bolt to the shaft.
(c) Using a torque wrench, check the pump rotating torque.
Rotating torque:
0.3 N´m (2.8 kgf´cm, 2.4 in.´lbf) or less
3. REMOVE SUCTION PORT UNION
(a) Remove the bolt.
(b) Remove the O-ring from the union.
4. REMOVE PRESSURE PORT UNION, FLOW CONTROL
VALVE AND SPRING
Remove the O-ring from the union.
5. REMOVE REAR HOUSING
(a) Loosen the 4 bolts.
(b) Remove the vane pump assembly from the SST.
(c) Remove the 4 bolts and rear housing.
(d) Remove the gasket from the housing.
6. REMOVE CAM RING, 10 VANE PLATES AND VANE
PUMP ROTOR
Using a screwdriver, remove the snap ring from the vane pump
shaft.
NOTICE:
Be careful not to drop the plate.
7. REMOVE SIDE PLATE
8. REMOVE VANE PUMP SHAFT WITH PUMP PULLEY
Page 2842 of 3115
SR1IL-01
F17217
Vane Pump Shaft
Front HousingBushing
Bushing
F17573
Thickness
R10282
Feeler Gauge
F17219
SR-42
- STEERINGPOWER STEERING VANE PUMP
2251 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. CHECK OIL CLEARANCE BETWEEN VANE PUMP
SHAFT AND BUSHING OF FRONT HOUSING AND
REAR HOUSING
Using a micrometer and caliper gauge, measure the oil clear-
ance.
Standard clearance:
Front housing and shaft
0.020 - 0.077 mm (0.00079 - 0.00303 in.)
Rear housing and shaft
0.020 - 0.077 mm (0.00079 - 0.00303 in.)
Maximum clearance:
Front housing and shaft
0.070 mm (0.00276 in.)
Rear housing and shaft
0.080 mm (0.00315 in.)
If it is more than the maximum, replace a new vane pump as-
sembly.
2. INSPECT VANE PUMP ROTOR AND VANE PLATES
(a) Using a micrometer, measure the height, thickness and
length of the 10 plates.
Minimum thickness: 1.405 mm (0.05531 in.)
(b) Using a feeler gauge, measure the clearance between
the rotor groove and plate.
Maximum clearance: 0.03 mm (0.0012 in.)
If it is more than the maximum, replace a new vane pump as-
sembly.
3. INSPECT FLOW CONTROL VALVE
(a) Coat the valve with power steering fluid and check that it
falls smoothly into the valve hole by its own weight.
Page 2843 of 3115
F04865
Compressed Air
R08702
Calipers
- STEERINGPOWER STEERING VANE PUMP
SR-43
2252 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Check the flow control valve for leakage.
Close one of the holes and apply compressed air
392-490 kPa (4-5 kgf/cm
2, 57-71 psi) into the opposite
side hole, and confirm that air does not come out from the
end holes.
If necessary, replace a new vane pump assembly.
4. INSPECT SPRING
Using calipers, measure the free length of the spring.
Minimum free length: 31.3 mm (1.2323 in.)
If it is not within the specification, replace a new vane pump as-
sembly.
Page 2844 of 3115
SR0MI-10
F17225
Stopper
EM6656
- STEERINGPOWER STEERING VANE PUMP
SR-47
2256 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL PS VANE PUMP ASSEMBLY
Torque the 3 bolts.
Torque: 17 N´m (175 kgf´cm, 13 ft´lbf)
2. INSTALL PRESSURE FEED TUBE
Install new gaskets on each side of the tube and torque the
union bolt.
Torque: 50 N´m (510 kgf´cm, 37 ft´lbf)
HINT:
Make sure that the stopper of the tube touches the PS vane
pump body as shown in the illustration, then torque the bolt.
3. CONNECT RETURN HOSE
Install the clip.
4. CONNECT 2 VACUUM HOSES
Install the 2 clips.
5. INSTALL DRIVE BELT
Loosen the drive belt tension by turning the drive belt tensioner
counterclockwise, and install the belt.
6. INSTALL AIR CLEANER ASSEMBLY WITH AIR
CLEANER HOSE
(a) Tighten the 3 bolts.
(b) Tighten the clamp.
(c) Connect the hose.
(d) Connect the MAF meter connector.
7. INSTALL NO. 2 ENGINE UNDER COVER
Tighten the 8 bolts.
8. INSTALL NO. 1 ENGINE UNDER COVER
Tighten the 6 bolts.
9. BLEED POWER STEERING SYSTEM
(See page SR-4)
Page 2845 of 3115
SR1IM-01
F17223
F17224
Inscribed Mark
- STEERINGPOWER STEERING VANE PUMP
SR-45
2254 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
1. COAT WITH POWER STEERING FLUID (See page
SR-38)
2. INSTALL VANE PUMP SHAFT
3. INSTALL SIDE PLATE
(a) Install a new O-ring to the front housing.
(b) Install a new O-ring to side plate.
(c) Install the side plate as shown in the illustrating.
HINT:
Align the hole of the side plate with the hole of the front housing.
4. INSTALL CAM RING
Install the ring with the inscribed mark facing outward.
HINT:
Align the hole of the cam ring with the hole of the front housing.
5. INSTALL VANE PUMP ROTOR
(a) Install the rotor with the inscribed mark facing outward.
(b) Install a new snap ring to the vane pump shaft.
6. INSTALL 10 VANE PLATES
(a) Install the plates with the round end facing outward.
7. INSTALL REAR HOUSING
(a) Coat new gasket with power steering fluid and install it to
the housing.
(b) Temporarily install the 4 bolts.
(c) Using SST, hold the vane pump assembly in a vise.
(d) Torque the 4 bolts.
Torque: 22 N´m (225 kgf´cm, 16 ft´lbf)
8. INSTALL SPRING, FLOW CONTROL VALVE AND
PRESSURE PORT UNION
(a) Install the valve facing the correct direction
(See page SR-38).
(b) Coat a new O-ring with power steering fluid and install it
to the union.
(c) Torque the union.
Torque: 69 N´m (700 kgf´cm, 51 ft´lbf)
9. INSTALL SUCTION PORT UNION
(a) Coat a new O-ring with power steering fluid and install it
to the union.
(b) Torque the bolt.
Torque: 12 N´m (120 kgf´cm, 9 ft´lbf)
Page 2846 of 3115
SR-46
- STEERINGPOWER STEERING VANE PUMP
2255 Author: Date:
2004 LAND CRUISER (RM1071U)
10. MEASURE PS VANE PUMP ROTATING TORQUE
(See page SR-41)
Page 2847 of 3115
SR0ME-09
EM6656
SR-40
- STEERINGPOWER STEERING VANE PUMP
2249 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE NO. 1 ENGINE UNDER COVER
Remove the 6 bolts.
2. REMOVE NO. 2 ENGINE UNDER COVER
Remove the 8 bolts.
3. REMOVE AIR CLEANER ASSEMBLY WITH AIR
CLEANER HOSE
(a) Disconnect the MAF meter connector.
(b) Disconnect the hoses.
(c) Loosen the clamp.
(d) Remove the 3 bolts.
4. REMOVE DRIVE BELT
Loosen the drive belt tension by turning the drive belt tensioner
counterclockwise, and remove the drive belt.
5. DISCONNECT 2 VACUUM HOSES
Remove the 2 clips.
6. DISCONNECT RETURN HOSE
Remove the clip.
7. REMOVE PRESSURE FEED TUBE
Remove the union bolt and 2 gaskets.
8. REMOVE PS VANE PUMP ASSEMBLY
Remove the 3 bolts.
Page 2848 of 3115
SR0RG-05
F17221
Oil Seal
F17222
Press
SST
Oil Seal
SR-44
- STEERINGPOWER STEERING VANE PUMP
2253 Author: Date:
2004 LAND CRUISER (RM1071U)
REPLACEMENT
NOTICE:
When using a vise, do not overtighten it.
IF NECESSARY, REPLACE OIL SEAL
(a) Using a screwdriver with vinyl tape wound around its tip,
remove the oil seal.
NOTICE:
Be careful not to damage the front housing.
(b) Coat a new oil seal lip with power steering fluid.
(c) Using SST, press in the oil seal.
SST 09950-60010 (09951-00280),
09950-70010 (09951-07100)
NOTICE:
Make sure to install the oil seal facing the correct direction.
Page 2849 of 3115
SR0M7-04
F05613
Steering Wheel Pad
50 (510, 37)
Steering Wheel Lower
No. 2 Cover
Torx Screw
8.8 (90, 78 in.´lbf)
Combination Switch
(w/ Spiral Cable)
Steering Wheel
Torx Screw
8.8 (90, 78 in.´lbf)
Steering Wheel Lower
No. 3 Cover
Column Upper Cover
Column Lower Cover
Steering Column Assembly
25 (260, 19)
Thrust Stopper
Sliding Yoke
34 (350, 25)Hose Clamp
No. 2 Hole Cover
Hole Cover
No. 2 Intermediate
Shaft AssemblyCluster Finish Panel
Lower No. 1 Panel
34 (350, 25)
LH Lower Panel
Hood Lock Release Lever
Fuel Lid Release Lever
No. 2 Heater to Register
DuctClip
Cowl Trim
Scuff Plate
N´m (kgf´cm, ft´lbf) : Specified torque
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-27
2236 Author: Date:
2004 LAND CRUISER (RM1071U)
POWER TILT AND POWER TELESCOPIC STEERING
COLUMN
COMPONENTS
Page 2850 of 3115
F17600
Transponder Key Coil
with Amplifier
Key Cylinder
Snap Ring
Turn Signal Bracket
Column Upper
Tube Sub-assembly
Tilt Steering Bolt
20 (210, 15)
Key Interlock
Solenoid
Energy Absorbing
Clip
Energy Absorbing
Plate
Energy Absorbing
Guide
Ignition SwitchColumn Upper
Bracket
Column Upper
Tube Assembly
Break Away
Bracket15 (150, 11)
Column Tube
Support
Tube Attachment
Support Stopper
Bolt Bushing
Power Tilt Motor20 (210, 15)
Bushing
Telescopic Steering
Slider
Telescopic Steering
Slider Support
Steering Lock Wedge
Telescopic Steering
Wedge Lock Spring
Power Telescopic
Motor
Steering Column Protector
No. 1
15 (150, 11)
Column Upper
Clamp
Telescopic Steering
Column Cable
Tapered-head Bolt
Telescopic Steering
Bushing
0.8 (8.2, 7.1 in.´lbf)
Telescopic Steering
Screw
Energy Absorber
Cushion
Support Stopper
Bolt
Stopper Spring
Stopper No. 1
Adjusting Nut No. 1
Connector Bracket
E-RIng
Compression
Spring
Bearing Thrust
Collar Bearing
Main Shaft
Assembly
Snap Ring
34 (350, 25)
Thrust Stopper
Intermediate Shaft Assembly
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Molybdenum disulfide lithium base grease
Support Stopper
Bolt Bushing
Tilt Steering Shaft
No. 2 Lower Cover
Bushing
Steering Column
Bracket Spacer
Telesco Lever
Lock Bolt
10 (100, 7)
Bearing
Bearing
No. 2 Lower Cover
11 (110, 8)
9.0 (90, 78 in.´lbf)
25 (260, 19)
Key Unlock Warning
Switch19 (190, 14)
Column Tube
Stopper SR-28
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2237 Author: Date:
2004 LAND CRUISER (RM1071U)
