BE0HN-1 1
I24742
Wiper Motor
Washer Tank
Rear Washer Motor
Front Washer Motor Combination Switch
Wiper and Washer Switch
Rear Wiper and Washer Switch
Cowl SIde J/B LH
RR WIPER FuseIgnition Switch
Rear Wiper Relay
Rear Wiper Motor
Cowl SIde J/B RH
WASHER Fuse
WIPER Fuse
- BODY ELECTRICALWIPER AND WASHER SYSTEM
BE-51
2424 Author: Date:
2004 LAND CRUISER (RM1071U)
WIPER AND WASHER SYSTEM
LOCATION
Page 352 of 3115
BE2F2-01
I20790
Key Plate Inserted
ON
OFFWithin. 5secs.
1 Key Plate Not Inserted
23 910Within. 30secs.
Once 9 times BE-100
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2473 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. CHARACTERS OF WIRELESS DOOR LOCK
(a) The operation distance changes according to how cus-
tomers hold the transmitter or where it is used.
(b) Because of using the very weak radio wave, if there is a
strong wave or noise on the frequency being used, the op-
eration distance may become shorter.
2. WIRELESS DOOR LOCK BASIC FUNCTION
(a) Stand on the driver's side. Stay 1 m away from the ve-
hicle.
(b) Turn the transmitter toward the vehicle and press any one
of the transmission switched for 1 sec.
3. INSPECT WIRELESS DOOR LOCK DIAGNOSIS MODE
(a) Start up diagnosis mode.
HINT:
Follow the method below.
(1) Insert the ignition key into the ignition key cylinder.
(2) Remove the ignition key from the ignition key cylin-
der.
(3) Insert the key into the ignition switch.
(4) Turn the ignition switch ON once within 5 sec.
(5) Repeat turnning the ignition switch OFF " ON 9
times within 30 sec.
(6) Enter the diagnosis mode, and make sure that the
taillight lights up.
(b) Finishing the Diagnosis Mode.
During the Diagnosis mode, turn the ignition switch OFF
" ON to go back to the normal mode.
At this time make sure that the taillight lights up.
Page 353 of 3115
I20456
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or
rolling code.
0.13secs.
0.5secs.
0.13secs. 0.25secs. 0.5secs.
0.5secs. 0.5secs.
OFF ON
OFF ON
OFF ON
OFF ON
While receiving
I04149
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-101
2474 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Diagnosis Mode Check.
HINT:
Check how the taillight lights up when pressing each transmitter
switch.
(1) LOCK switch
(2) UNLOCK switch
(3) Luggage door switch
(4) Disagreement of recognition code or rolling code.
HINT:
If (4) is detected in the Diagnosis Check, conduct the recogni-
tion code registration.
(5) No response from the taillight.
HINT:
Conduct the following checks.
Wireless door lock transmitter.
Wireless door lock receiver.
4. INSPECT WIRELESS DOOR LOCK TRANSMITTER
OPERATION
HINT:
Refer to ºWireless door lock control receiver and transmitter re-
placementº.
(a) Using a screwdriver, remove the screw and cover.
(b) Remove the battery (lithium battery).
(c) Install a new or normal battery (lithium battery).
HINT:
When a new or normal battery can not be obtained, connect 2
new 1.5 V batteries in series, connect the battery (+) to the bat-
tery receptacle side terminal and battery (-) to the bottom termi-
nal, then apply 3 V voltage to the transmitter.
(d) In the location where is approx. 1 M away from driver's
outside handle in the right direction, face the key plate of
the transmitter to the vehicle, and check the transmitter
operation when pressing transmission switch on the side
of the transmitter body.
(e) Install the battery (lithium battery).
(f) Install a cover so that O-ring is not distorted or slipped off.
(g) Using a screwdriver, tighten the screw.
Standard:
Remote control of vehicle door lock can be operated.
LED lights up more than once.
HINT:
The minimum operation distance differs according to op-
erator, the way of holding, and location.
Page 354 of 3115
I04150
I07522
BE-102
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2475 Author: Date:
2004 LAND CRUISER (RM1071U)
As weak wave is used, operation distance might be short-
ened when noise is detected in strong wave or used fre-
quency.
5. CHECK BATTERY CAPACITY
HINT:
Make sure to use the TOYOTA electrical tester.
With the battery unloaded, judge can not be made wheth-
er the battery is available or not on the test.
When the transmitter is faulty, the energy amount left in
the battery might not be checked correctly.
On the lithium battery used for the transmitter, the voltage
more than 2.5 V with the battery unloaded is shown on the
tester until the energy is completely consumed.
Accordingly when inspecting the energy amount left in the
battery, it is necessary to measure the voltage when the
battery is loaded. (1.2 kW).
(a) Remove the 2 screws and cover using a (-) driver.
(b) Remove the battery (lithium battery) from the transmitter.
(c) Connect the lead to the (-) terminal of the transmitter and
install the battery.
(d) Connect the (+) tester to the (+) battery (lithium battery),
and (-) tester to the lead respectively.
(e) Press one of the transmitting switches on the transmitter
for approx. 1 second.
(f) Press the transmitting switch on the transmitter again to
check the voltage.
Standard: 2.1 V or more
HINT:
When the temperature of the battery is low, the judge can
not be made correctly.
When the outcome of the test is less than 2.1 V, conduct
the test again after leaving the battery in the place at 18
°C for more than 30 minutes.
By auto power off function, the voltage becomes no load
voltage (more than 2.5 V) condition 20 seconds after the
switch was pressed.
Make sure to read the voltage before of it.
Page 355 of 3115
I25814
Wire Harness Side
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-103
2476 Author: Date:
2004 LAND CRUISER (RM1071U)
High voltage might be shown 1 to 2 times after leaving the
battery, judge should be made with the voltage shown at
the 3rd time or later.
(g) Disconnect the lead.
(h) Set the battery (lithium battery) in the transmitter.
(i) Install the cover, so that the O-ring is not distorted or
slipped off.
(j) Using a screwdriver, tighten the 2 screws.
6. INSPECT WIRELESS DOOR LOCK CONTROL TUNER
CIRCUIT
Disconnect the connector from the tuner and inspect the con-
nector on the wire harness side, as shown.
Tester connectionConditionSpecified condition
1 (E) - GroundConstantContinuity
2 (RDA) - GroundIgnition switch OFF, without key, all doors
closed,, and transmitter switch OFF " ONBelow 1 V e 6 V
5 (+B) - Ground-Repeatedly chage 0 - 5V
If the circuit is not as specified, inspect the circuit connected to
other parts.
Page 356 of 3115
BE0CH-09
I25815
Transmitter:Door Key Lock and
Unlock Switch Front Door Lock Assembly
Front Door Lock Motor
Front Door Unlock Detection SwitchRear Door Lock Assembly
Rear Door Lock Motor
Rear Door Unlock Detection Switch
Front Door Lock Assembly
Front Door Lock Motor
Front Door Unlock
Detection Switch
Rear Door Lock Assembly
Rear Door Lock Motor
Rear Door Unlock
Detection Switch
Ignition Switch
Wireless Door Lock ECU
BE-98
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2471 Author: Date:
2004 LAND CRUISER (RM1071U)
LOCATION
Page 357 of 3115
BE0CI-07
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-99
2472 Author: Date:
2004 LAND CRUISER (RM1071U)
PRE-CHECK
1. CHARACTERS OF WIRELESS DOOR LOCK
(a) The operation distance changes according to how customers hold the transmitter or where it is used.
(b) Because of using the very weak radio wave, if there is a strong wave or noise on the frequency being
used, the operation distance may become shorter.
2. WIRELESS DOOR LOCK BASIC FUNCTION
(a) Stand on the driver's side. Stay 1 m away from the vehicle.
(b) Turn the transmitter toward the vehicle and press any one of the transmission switched for 1 sec.
Page 358 of 3115
BE226-04
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-93
2466 Author: Date:
2004 LAND CRUISER (RM1071U)
WIRELESS DOOR LOCK CONTROL SYSTEM
REGISTRATION PROCEDURE
HOW TO CODE REGISTRATION
NOTICE:
When replacing the theft deterrent ECU or transmitter, registration of recognition code is necessary
because they are provided as a single components.
(a) Select the operation mode to perform from the following operation modes.
Add mode
Rewrite mode
Prohibition mode
Confirmation mode
HINT:
The ºAdd modeº is for adding the newly recognized codes for registration while the already registered
codes are retained. This mode is used when the transmitter is added. When the number of the regis-
tered codes exceeds 4 codes, the previously registered codes will be erased in order, staring from the
first registered code.
The ºRewrite modeº is for erasing all the registered codes and registering newly recognized codes only.
This mode is used when the transmitter or the door control receiver is replaced.
The ºProhibition modeº is for erasing all the registered codes to prohibit the wireless door lock opera-
tion. This mode is used when the transmitter is lost.
The ºConfirmation modeº is for confirming the number of recognition codes that are registered. This
mode is used to check the number of registered codes when new codes are added to the registration,
etc.
(b) Follow the chart on the following page to register the transmitter recognition code to the theft deterrent
ECU.
HINT:
When procedure is out of the specified, the registration operation is cancelled.
Maximum 4 recognition codes can be registered.
Page 359 of 3115
START
The vehicle should be in the following conditions:
Ignition switch ON
Hand-held tester operation:
1. Select ºL/C 100º from the menu.
2. Select ºTDSº (Theft Deterrent System).
3. Select ºWIRELESS REGISTRATIONº.
After the above operations, proceed to the succeeding operations
according to the prompts on the tester screen.
Transmitter SW Operation:
HINT: Perform this operation during the countdown screen.
Press both lock and unlock SW. (Between 1 and 1.5 sec.)
Press any one of SW. (For more than 1 sec.)
This wireless buzzer sounds when the registration is completed
normally.
Continue the registration.Register other transmitters?
Or
Finish the registration?
Finish the registration.
ENDHINT: Select the next step
on the tester screen.
Within 3 sec. BE-94
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
2467 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) By TOYOTA Hand-Held Tester
HINT:
This page is to show briefly the registration procedure using the hand-held tester.
For detailed procedures, please refer to the prompts on the tester screen.
The number of currently registered codes can be checked out on the first screen of the WIRELESS REG-
ISTRATION.
Page 360 of 3115
Close"open"close"open
START
The vehicle should be in the following conditions:
Driver door open (Other doors are closed).
Insert and remove the key into/from the ignition cylinder twice.
Insert"remove "insert"remove
HINT: If the IG switch operation is
not performed with the specified
number of times (If it is 4 times, 6
times or more), this operation is
finished with no response.
HINT: The registration operation is
cancelled if each operation is not
completed within the specified
time.
No key inserted in the IG key cylinder.
Close and open the driver door twice.
Close"open"close"open
Insert and remove the key into/from the ignition cylinder once.
Insert"remove
Insert the key into the ignition key cylinder.
Close all the doors.
Mode Selection
Turn the IG SW ON
u"LOCK once.Add modeTurn the IG SW ON
u"LOCK twice.Rewrite modeTurn the IG SW ON
u"LOCK 3 times. Confirmation modeTurn the IG SW ON
u"LOCK 5 times. Prohibition mode
Remove the key from the IG key cylinder.
Within 5 sec.
Within 40 sec.
Within 40 sec.
Within 40 sec.
Close and open the driver door twice.
- BODY ELECTRICALWIRELESS DOOR LOCK CONTROL SYSTEM
BE-95
2468 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) By Switch Operation:
