key TOYOTA LAND CRUISER 2002 J100 Navigation Manual

41


The automatic air conditioning auto-
matically maintains the set tempera-
ture.
This air conditioning features automatic
fan speed and air flow control which auto-
matically selects the most suitable fan
speed and air flow to control the tempera-
ture. The ignition key must be in the ºONº
position.
CLIMATE: Push this button to display
switches for automatic air conditioning con-
trols.
NOTICE
To prevent the battery from being dis- charged, do not leave the air condition-
ing on longer than necessary when the
engine is not running.
SETTING OPERATION - automatic con-
trol
UNC501
1. Push the ºAUTOº button.
Air flow quantity, switching of the diffusers,
on-of f of the air conditioning, and switching
of the air intake between RECIRCULATED
AIR and OUTSIDE AIR are automatically ad-
justed. The operation status is shown by
each indicator.
When one of the manual control buttons is
depressed while operating in automatic
mode, the mode relevant to the depressed
button is set. Other conditions continue to be
adjusted automatically. Push
the ºOFFº button to turn the air condi-
tioning off.
It is recommended that you close the lower
vent. For details about this, see page 46.
(a) Climate control

3
This
section describes some of the basic fea-
tures of the audio system. Some information
may not pertain to your system.
Your audio system works when the ignition
key is in the ºACCº or ºONº position.
NOTICE
To prevent the battery from being
discharged, do not leave the car audioon longer than necessary when the
engine is not running.
POWER-VOL: Push this knob to turn the
audio system on and off. Turn this knob to
adjust the volume. The system turns on in
the last mode used.
AUDIO: Push this button to display switches
for audio system.
UNC608
Push the ºAMº, ºFMº, ºTAPEº or ºDISCº
button to turn on that mode. The selected
mode turns on directly.
Push th ese buttons if you want to switch from
one mode to another.
If the tape or disc is not set, the cassette play-
er or compact disc player does not turn on.
You can turn off the cassette player by eject-
ing the cassette tape. If the audio system
was previously off, then the entire audio sys-
tem will be turned off when you eject the cas-
sette tape. If another function was previously
playing, it will come on again.
Using your audio system:
some basics (a) Turning the system on and
off

23

Second Pageº switch: Use this switch to
display the operation switches on the sec-
ond page.
Top Pageº switch:Use this switch to dis-
play the operation switches on the top page.
Hide Keysº switch: Use this switch to turn
off the operation switches from the display.
If
º appears on the display when you
touch a switch, the operation relevant to the
switch is not permitted. (vi) Description of each switch
 Switches on top page
SET UPº switch: The initial set up screen
appears. (See page 25.)

º, Menuº and Top Menuº switches:
If you touch any of the above switches, the
menu screen for DVD video appears. (For
the operation, see the manual for the DVD
video disc provided separately.)
Angleº switch: T h e a n g le s e le c tio n
screen appears. (See page 25.)
Sub Titleº switch: The subtitle changing
screen appears. (See page 24.)
Audioº switch: The audio changing
screen appears. (See page 24.)
 Switches on second page
Searchº switch: The title search screen
appears. (See page 24.)

º switch: Use this switch to pause the
video screen. When you touch this switch
again, the video screen advances frame by
frame.

º switch: Use this switch to stop play-
ing video.
 º switch: Touch this switch to fast re-
verse during the playback and reverse slow-
ly during the pause.
  º switch: Use this switch to cancel the
stop and pause to normal playing.
  º switch: Touch this switch to fast for-
ward du ring the playback and forward slowly
during the pause.

º switch: Use this switch to display the
predetermined scene and start playing from
there.

30If you touch the part where switches are not
located while you are watching video on the
video CD, video CD operation switches will
appear.

Second Pageº switch: Use this switch to
display the operation switches on the sec-
ond page.
Top Pageº switch:Use this switch to dis-
play the operation switches on the top page.
Hide Keysº switch: Use this switch to turn
off the operation switches from the display.
If
º appears on the display when you
touch the switch, the operation is not per-
mitted. (iii) Description of each switch
 Switches on top page
D. Menu Nextº switch: When you touch
this switch while the disc menu is displayed,
the next page appears on the display. If you
touch this switch while the player is playing
video, the next track is searched and played.
D. Menu Prev.º switch: When you touch
this switch while the disc menu is displayed,
the previous page appears on the screen. If
you touch this switch while the player is play-
ing video, the previous track is searched and
played.
Sel. Numberº switch: The track or num-
ber search screen appears. (See Searching
by trackº on the next page.)
Main/Subº switch: A multiplex transmis-
sion changing switch. The mode changes
from Main/Sub to Main, to Sub and back to
Main/Sub by touching this switch.

º switch: The video CD menu ap-
pears. (For the operation, see the instruction
manual for the video CD provided separate-
ly.)
Switches on second page

º switch: Use this switch to pause the
video screen. When you touch this switch
again, the video screen advances by frame
by frame.
  º switch: Touch this switch during the
pause to resume playing.
  º switch: Touch this switch to fast re-
verse during the playback.
  º switch: Touch this switch to fast for-
ward during the playback and start playing
slowly during the pause.
PBCº switch: Use this switch to turn off
playback control.
