2003 Land Cruiser 100 Navigation (OM60A00U)
1UE058
Touch the “Edit” switch, the Edit route
preview screen appears.
To next POI: Preview the Next POI
To next
: Preview the Next destination
Delete: To delete the POI icon.
Select POI: To select the POI icon.
Touch the
“OK” switch after the selection.
1UE059
The current vehicle position mark ap-
pears in the center of the Map screen. You
can return to this map screen showing
your current position at any time from
any screen by pushing the
“MAP/
VOICE”
button.
During driving, the current vehicle position
mark is fixed in the center of the screen and
the map moves.
If you move the map with a “one −touch”
scroll (see page 48 for details), the current
vehicle position mark continues to track your
current location.
INFORMATION
When you use the “onetouch” scroll
feature, the current vehicle position
mark may disappear from the screen.
Move the map with a “onetouch”
scroll again or push the
“MAP/
VOICE” button to return to the current
vehicle position map location display.
The current position is automatically set
as your vehicle receives signals from the
GPS (Global Positioning System). If your
current position is not correct, it is auto-
matically corrected after your vehicle re-
ceives signals from the GPS.
INFORMATION
After the battery disconnection, or on a
new vehicle, the current position may
not be correct. As soon as the system
receives signals from the GPS, the cor-
rect current position is displayed.
If you must correct the current position
manually, follow the steps on page 79.
Current position display

35
2003 Land Cruiser 100 Navigation (OM60A00U)
Voice guidance is offered automatically
during route guidance. Use voice guid-
ance just for your reference.
You can adjust the volume of the voice or turn
off voice guidance.
1UE040
Push the “MENU” switch to display the
Menu screen. Then touch the
“Volume”
switch on the Menu screen.
1UE060
Touch any number to select the desired
volume. Touching the “Off” switch turns
the voice route guidance off. If you turn
the
“Adaptive volume control” on,
the volume is turned up automatically
when the vehicle speed exceeds 80 km/h
(50 mph).
INFORMATION
During route guidance, the voice route
guidance continues even if the naviga-
tion screen is changed to the other
screens, such as the audio screen.
UN301
The voice guidance provides various mes-
sages as you approach an intersection, or
other point where you need to maneuver the
vehicle.
1“Proceed about 5 miles”
2“In a quarter of a mile, right turn”
3“Right turn.”
4(Beep sound only)
Voice guidance
Typical voice guidance
p
rompts

37
2003 Land Cruiser 100 Navigation (OM60A00U)
EMV3115U
The system announces your approach to the
final destination.
1“Your destination is ahead.”
2“You have arrived at your destina-tion. The route guidance is now
finished.”
INFORMATION
 If the system cannot determine the
current vehicle position correctly (in
cases of poor GPS signal reception),
the voice guidance may be made ear-
ly or delayed.
 If you did not hear the voice guid-
ance command, push the
“MAP/
VOICE” button to hear it.
If you register your home address before-
hand, you can easily set the route back to
your home.
1UE040
1. Push the “MENU” button to display
the Menu screen and touch the
“Marked points” switch.
Registering your home

38
2003 Land Cruiser 100 Navigation (OM60A00U)
1UE061
2. Touch the “Reg. home” switch of
Marked points screen for registering
your home.
If your home is registered, the
“Delete
home”
switch will be shown.
1UE062
You may register the location of your
home by some different methods: cur-
rent position, address, map location, etc.
Touch the screen to select your desired
method from the menu.
Input your home in the same way as the des-
tination input. (See page 22.)
Deleting your home
1UE040
1. Push the “MENU” switch to display
the Menu screen and touch the
“Marked points” switch.

39
2003 Land Cruiser 100 Navigation (OM60A00U)
1UE063
2. Touch the “Delete home” switch on
the “Marked points” screen.
1UE064
The screen changes and displays the map
location of home and a message. If you are
sure that you want to delete the point, touch
the
“Yes” switch. If not, touch the “No”
switch. You can register up to 5 preset destina-
tions
1. Push the
“MENU” switch to display
the Menu screen and touch the
“Marked points” switch.
1UE065
Registering preset
d
estinations

40
2003 Land Cruiser 100 Navigation (OM60A00U)
2. Touch the “Register” switch of Pre-
set destinations
1~5.
1UE066
3. Touch any of the switches for
which you want to register the preset des-
tination. If you have already registered the preset
destination,
you can overwrite on the present
registered destination.
1UE067
4. Input the preset destination in the
same way as the destination input. (See
page 22.)
Editing preset destinations
1. Push the “MENU” switch to display
the Menu screen and touch the
“Marked points” switch.
1UE065
2. Touch the “Edit” switch of Preset
destinations
1~5.

41
2003 Land Cruiser 100 Navigation (OM60A00U)
1UE068
3. Select the preset destination that
you want to edit and touch the
switch.
1UE069
You can change the name, location and
phone number of the preset destination.
Touch the
“Change” switch.
Deleting the preset destinations
1. Push the “MENU” switch to display
the Menu screen and touch the
“Marked points” switch.
1UE065
2. Touch the “Delete” switch of Preset
destinations
1~5.
1UE070
3. Select the preset destination that you
want to delete and touch the
switch.
If you want to delete all the preset des-
tinations, touch the “Delete all” switch.
Messages appear depending on the type of
deletion. If you want to delete, touch the
“Yes” switch. To cancel the deletion, touch
the
“No” switch.

43
2003 Land Cruiser 100 Navigation (OM60A00U)
INFORMATION
When your vehicle is on a freeway,
the detour distance selections are 5,
15, and 25 miles.
 The system may not be able to calcu-
late a detour route depending on the
selected distance and surrounding
road conditions.Points of interest such as gas stations
and restaurants can be displayed on the
Map screen. You can also set their loca-
tion as a destination and use them for
route guidance.
1UE059
To display a particular type of point of in-
terest on the screen, touch the
“POI”
switch on the Map screen.
1UE072
A window with a limited choice of points of in-
terest will be displayed. When you touch
your desired type of point of interest, icons
will appear on the Map screen indicating
where the POI addresses are located.
Displaying POI

44
2003 Land Cruiser 100 Navigation (OM60A00U)
1UE073
More: If you cannot find your desired point of
interest on the limited choice screen, touch
this switch. The screen then displays the
complete POI listing screen. You can display
up to 5 categories of icons on the screen.
1UE074
When you select a point of interest type from
either the limited list or the complete list, the
screen will display icons at those locations
on the Map screen.
Touching the
“Delete” switch will delete
the last selected icon.
Local POI list: If you want to search the
nearest point of interest, touch this switch.
Then choose one of the categories. The sys-
tem will list the points within 20 miles (32 km).
You can sort the local POI list by three differ-
ent ways as follows.
Icon: In the order of the POI icons
Dist.: In the order of distance from your cur-
rent location.
Name: In alphabetical order By turning the
“Route” switch on, you can
search the POI on the route when in the route
guidance mode.
Touch the
of your desired point of inter-
est. Points of interest which you chose are
displayed on the Map screen.
To turn off the icons of the points of inter-
est on the Map screen, touch the
“POI
off”
switch.

45
2003 Land Cruiser 100 Navigation (OM60A00U)
Setting a POI as a destination
You can select one of the points of inter-
est icons on the Map screen as a destina-
tion and use it for a route guidance.
1UE075
Directly touch the icon of the point of in-
terest that you want to set as a destina-
tion.
The map will shift so the icon is centered in
the screen and overlaps with the cursor
.
At this time, the distance from your current
position will be displayed on the screen. The
distance shown is as measured in a straight
line from the current vehicle position to the
POI. The name of the point of interest and the
“Info.” switch on the screen are displayed
at the top of the screen. When you touch the
“Info.” switch on the screen, the informa-
tion such as the name and address, etc. are
displayed.
When your desired point of interest over-
laps with the cursor, touch the
“Enter”
switch. The screen changes and displays
the map location of the selected destina-
tion and the route preference. (See “En-
tering Destination” on page 22.)
You can select the single screen map or
the dual screen map and you can change
the half of the screen to the Guidance
screen by touching the Map/Guidance
switch
while the Map screen is displayed.
You can choose one of two types of guid-
ance screen.
1UE040
1. Push the “MENU” switch to display
the Menu screen and touch the “Map
appearance” switch.
Map appearance
