display TOYOTA LAND CRUISER 2003 J100 Navigation Manual

72
2003 Land Cruiser 100 Navigation (OM60A00U)
You can register up to 100 marked points. If
you attempt to register more than 100, a
message appears for confirmation.
2UE009
If you want to register a new point, delete one
of the marked points. See “(c) Deleting
marked points”.1. Push the
“MENU” switch to display
the Menu screen and touch the
“Marked points” switch.
1UE063
2. Touch the “Delete” switch of the
marked points.
2UE010
3. Touch of the marked point to de-
lete.
(c) Deleting marked points

73
2003 Land Cruiser 100 Navigation (OM60A00U)
The screen for confirmation will appear
with the map of the marked point. If you
want to delete, touch
“Yes”. Touching
“No” or “Back” will return to the pre-
vious screen.
If you want to delete all of the marked
points, touch the
“Delete all” switch.
The screen for confirmation will appear.
Touching
“Yes” will delete all of the
marked points. Touching
“No” or
“Back” will return to the previous
screen.
To delete only specified marked points, use
the
“Icon”, “Date” or “Name” switch
to display the screen, so that you can easily
find the marked points.
2UE011
2UE012
Either of the above messages appears de-
pending on the type of deletion. If you want
to delete, touch the
“Yes” switch. To cancel
the deletion, touch the
“No” or “Back”
switch.
2UE013
You can register your current position or
any points (See “Screen Scrolling”on
page 48.) from the Map screen by touch-
ing the
“Mark” switch.
(d) Onetouch marked point
registration

75
2003 Land Cruiser 100 Navigation (OM60A00U)
Any areas you want to avoid due to traffic
jams, construction work or other reasons
can be registered as an area to avoid.
Push the
“MENU” switch to display
Menu screen and then touch the
“Marked points” switch to display the
following screen.
1UE063
INFORMATION
 Some areas and freeways may not
be able to be set as an avoid point.
 If a destination is input in the area to
avoid or the route calculation cannot
be made without running through
the area to avoid, a route passing
through the area to avoid may be
shown.
1. Touch the “Register” switch of Area
to avoid.
2UE017
Area to avoid(a) Registering area to avoid

76
2003 Land Cruiser 100 Navigation (OM60A00U)
2. Show the map of the area to avoid in
the same way as you input any destina-
tion or display the map of the area you
want to avoid. (See page 8 through 22.)
2UE018
3. Touch the “OK” switch at the center of
the area that you want to avoid.
2UE019
4. Depending on the contents to be
edited, touch either
or switch. When you touch the
“OK” switch, the fol-
lowing message appears.
2UE020
After a few seconds, the Marked points
screen returns.

77
2003 Land Cruiser 100 Navigation (OM60A00U)
1. Touch the “Edit” switch of Area to
avoid to display the Edit area to avoid
screen.
2UE021
2. Touch the point you want to edit from
the list.
2UE022
You can edit the name, location and size of
area to avoid. Touch any change switch that
you want to edit. 3. Edit the name, location or size of the
area to avoid.
2UE023
2UEP691
(b) Editing area to avoid

78
2003 Land Cruiser 100 Navigation (OM60A00U)
2UEP692
When editing is completed, touch the “OK”
switch.
INFORMATION
If you try to change the map to an in-
appropriate scale, a message ap-
pears.
 For magnification or reduction of the
map scale, see page 48.
1. Touch the “Delete” switch of Area to
avoid to display the Delete area to avoid
screen.
2UE024
2. Select the area you want to delete.
Delete all: All areas to avoid which are regis-
tered in the system are deleted.
2UE025
2UE026
3. Either of the above messages appears.
To delete the area(s), touch the
“Yes”
switch.
If you want to try again or cancel the deletion,
touch the
“No” switch. The previous
screen will return.
(c) Deleting area to avoid

79
2003 Land Cruiser 100 Navigation (OM60A00U)
The current vehicle position mark will be
automatically corrected during driving
on reception of GPS signals. If your ve-
hicle cannot receive GPS signals, you
can correct the current position mark
manually.
1UE040
1. Push the “MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
2UE0271
2. Touch the “Calibration” switch.
2UE0272
3. Touch the “Position/Direction”switch.
INFORMATION
For additional information on current
position accuracy, see “Limitations of
the Navigation System” on page 50.
Current position calibration

82
2003 Land Cruiser 100 Navigation (OM60A00U)
You can set the values shown on the Set-
up screen.
1. Push the
“MENU” switch.
1UE040
2. Touch the “Setup” switch to display
the Setup screen. Select your desired
items you want to set. Selected items will
be highlighted in green.
3UE001
3. Touch the “OK” switch on the screen
and the previous screen returns.
To default: Touch the
“Default” switch on
the screen. All of the settings can be de-
faulted.
Map color (day or night): You can select
your desired map color.
Auto reroute: You can set the system will or
will not automatically search for a new route
to the destination.
Estimated travel time: You can set to dis-
play the time required to reach the destina-
tion on the road guidance screen.
Adjust time zone: You can select your de-
sired time zone. Distance:
You can change “km” or “miles” to
display your desired units.
Notify seasonal restrict: You can select to
notify or not to notify a seasonal restriction.
Voice guide in all modes: You can set the
voice guide in all modes or not.
Current street name: You can select to
show or not to show a current street name on
the Map screen.
Setup

83
2003 Land Cruiser 100 Navigation (OM60A00U)
1. Push the “MENU” switch.
2. Touch the
“Setup” switch.
3UE001
3. Select your desired day and/or night
Map color and then touch the ”OK”switch to return to the Map screen. See
“The map color list” below for details.
Touch the
“Normal” switch to default the
Map color.
Touch the
“Auto” switch to select the Map
color automatically. The Map color is
changed in every three months. The Map color list
Switch NO.Map color“Auto” mode
1GreenMar.−May
2BlueJun.−Aug.
3GraySep.−Nov.
4BeigeDec.−Feb.
When the auto reroute feature is turned
on, the system will automatically search
for a new route to the destination if you
leave the guidance route. This feature
does
not operate while you are driving on
roads where the guidance is not avail-
able.
1. Push the
“MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
1UE040
Map colorAuto reroute

84
2003 Land Cruiser 100 Navigation (OM60A00U)
3UE002
2. Touch the “On” switch of the “Auto
reroute”. If you cannot find the item on
the list, touch
or switch to
scroll the list.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new route
may or may not take you back to the
previous route depending on how far
you are off the original guidance route.
When the estimated travel time feature is
turned on, the time required to reach the
destination is displayed on the Route
guidance screen.
1UE040
To turn the Estimated travel time on:
1. Push the
“MENU” switch to display
the Menu screen, and touch the “Set-
up” switch.
3UE003
2. Touch the “On” switch of the Esti-
mated travel time. If you cannot find the
item on the list, touch
or switch
and scroll the list.
Estimated travel time
