TOYOTA LAND CRUISER 2008 J200 Navigation Manual

OTHER FUNCTIONS
171
The speech command system enables
you to operate the navigation system,
audio system and air conditioning sys-
tem by giving a command.
1. Push the talk switch.
A beep sounds and on screen message is
displayed with an indicator at the top left.
2. Give a command while an indicator
is shown in the display.
If you want to check the command list,
touch “Help” to display the help screen.
(See “Help screen” on page 173.) When
you touch “Cancel”, the previous
screen returns.
If the navigation system does not respond
or the confirmation screen does not disap-
pear, please push the talk switch and try
again.
If no command is given, a beep sounds
and the indicator disappears 6 seconds
later.
If the system does not recognize your
speech, the system will respond with this
message (“System does not recognize
this command, please rephrase your com-
mand.”). Start the operation from the be-
ginning.
Speech command system

OTHER FUNCTIONS
172
Microphone
It is unnecessary to speak directly into
the microphone when giving a com-
mand.Speech command example: Searching
for a route to your home.
1. Push the talk switch.
2. Say “Home”.
If your home is not registered, you will hear
“Home is not registered”.
3. If the system recognized the com-
mand, the recognition result “Home” is
displayed on the top of the screen with
the screen message. (Displayed mes-
sage and the touchscreen buttons on
the screen depend on the situation.)
Touch or say “Cancel”, and the system will
be canceled. Touch or say “Help”, and dis-
plays the “Help” screen.
4. Touch “Enter” or say “Enter des-
tination”, and the system starts search-
ing for a route to your home. (If the des-
tination is already registered, “Add to
” or “Replace ” is displayed on the
screen.)
Touch or say “Cancel”, and the search will
be canceled.

OTHER FUNCTIONS
173
When you search the destination by
“POI Name”, this screen is displayed.
5U5508G
Touch “Enter” or say “Enter destination”.
When you touch “Show List”, you can
search another spot in its category.
INFORMATION
In the following conditions, the sys-
tem may not recognize the command
properly.
The command is not correct or
clear.
There are some noises such as
wind noise, etc.
Help screen
This system has a function which dis-
plays the voice recognition help
screen. You can see the command list
and operating guide on it.
(a) Command list
1. If the “Operating guide” screen is
displayed, touch “Command list” on
the upper side of the screen.
5E5501T
2. Select the desired category by
touching the buttons on the right side of
the “Command list” screen.
3. You can scroll through the list of the
command list by touching
or .
Touch “OK” after you check it.

OTHER FUNCTIONS
174
(b) Operating guide
1. If the “Command list” screen is dis-
played, touch “Operating guide” on the
upper side of the screen.
5E5502T
2. Select the desired category by
touching the buttons on the right side of
the “Operating guide” screen.
3. You can scroll through the list of the
operating guide by touching
or .
Touch “OK” after you check it.
Clock adjustment
The clock in this system can be corrected
manually or by using signals from the GPS.
Daylight Saving Time setting or your de-
sired time setting is available.
1. Push the “INFO” button to display
the “Information” screen.
2. Touch “Adjust Clock”.

OTHER FUNCTIONS
175
Auto Adjust ON: When you touch this
switch, the time is set to the GPS clock, and
this switch is highlighted in green.
Auto Adjust OFF: To reset the hour, touch
the “H” switch. To reset the minute, touch
the “M” switch. To adjust the time to the
nearest hour, touch “:00” switch.
Daylight Saving Time: Daylight saving
time can be set or canceled.
While daylight saving time is set, this
switch is highlighted in green.
Time Zone: You can select the time zone.
Touching this switch changes to the time
zone selection screen.
5U5708T
Touch the switch of your desired area. The
time zone for the area is set and the pre-
vious screen returns.
When you touch “Others”, this screen is
displayed. Touch “” or “ ” to adjust the
time zone.

OTHER FUNCTIONS
176
Screen adjustment
The brightness or contrast of the screen
can be adjusted depending on the bright-
ness of your surroundings. You can also
turn the display off.
1. To display the “Display” screen,
push the “DISP” button.
2. Touch the desired button to adjust
contrast and brightness.
“Contrast” “+”: Strengthens the contrast
of the screen.
“Contrast” “–”: Weakens the contrast of
the screen.
“Brightness” “+”: Brightens the screen.
“Brightness” “–”: Darkens the screen.
3. After adjusting the screen, touch
“OK”.
The screen goes off when “Screen Off” is
touched. To turn the display screen back
on, push any button such as “INFO”, etc.
The selected screen appears.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds,
the previous screen will be displayed.

OTHER FUNCTIONS
177
1. Touch the desired button to adjust
color and tone.
You can adjust the color and the tone while
the DVD video, DVD audio and video CD
are being played.
“Color” “R”: Strengthens the red color of
the screen.
“Color” “G”: Strengthens the green color
of the screen.
“Tone” “+”: Strengthens the tone of the
screen.
“Tone” “”: Weakens the tone of the
screen.
2. After adjusting the screen, touch
“OK”.
If your vehicle is equipped with the rear
seat entertainment system, the rear
screen turns on or off when “Rear” is
touched.
The screen turns off when “Screen Off” is
touched. To turn the screen back on, push
any button such as “INFO”, etc. The se-
lected screen appears.
INFORMATION
When you do not touch any button on
the “Display” screen for 20 seconds,
the previous screen will be displayed.
Depending on the position of the headlight
switch, the screen changes to the day
mode or night mode.
To display the screen in the day mode even
with the headlight switch on, touch “Day
Mode” on the adjustment screen for
brightness and contrast control.
If the screen is set in the day mode with the
headlight switch turned to on, this condi-
tion is memorized in the system even with
the engine turned off.

OTHER FUNCTIONS
178
Screen setting
1. Push the “INFO” button to display
the “Information” screen.
2. Touch “Screen Setting”.(a) Automatic transition
You can select a function that enables au-
tomatic return to the navigation screen
from the audio/air conditioner screen.
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The navigation screen automatical-
ly returns from the audio/air conditioner
screen 20 seconds after the end of audio/
air conditioner screen operation.
“OFF”: The audio/air conditioner screen
remains on.

OTHER FUNCTIONS
179
(b) Switch color
You can select the color of the touch−
screen buttons.
Select “Green” or “Orange” and then
touch “OK”.(c) Rear system lock
(with rear seat entertainment system)
If the vehicle is equipped with the rear seat
entertainment system, the rear seat enter-
tainment system can be locked to prevent
rear passengers from operating the enter-
tainment system.
Select “ON” or “OFF” and then touch
“OK”.
“ON”: The rear passengers cannot oper-
ate the rear seat entertainment system.
Only front passengers can operate the
system.
“OFF”: Both the front and rear passen-
gers can operate the rear seat entertain-
ment system.

OTHER FUNCTIONS
180
(d) Delete personal data
The following personal data can be de-
leted or returned to their default settings:
Maintenance conditions
Maintenance information “off” set-
ting
Memory points
Areas to avoid
Previous points
Route trace
User selection settings
Phone book data
Dialed numbers and received calls
Speed dial
Bluetooth phone data
Security code
This function is available only when the ve-
hicle is not moving.
1. Touch “Delete personal data”.
The “Delete personal data” screen ap-
pears.
5U5535t
2. Touch “Delete”.
The “Confirmation to delete all personal
data” screen appears.
5U5536t
3. Touch “Yes”.
