TOYOTA LAND CRUISER 2008 J200 Navigation Manual

OTHER FUNCTIONS
181
Beep setting
You can set a beep sound off.
1. Push the “INFO” button.
2. Touch “Beep Off”.
“Beep Off” is highlighted.
To switch the beep sound on, touch “Beep
Off” again.
Selecting a language
The language of the touch−screen but-
tons, pop−up messages and the voice
guidance can be changed.
1. Push the “INFO” button.
2. Touch “Language”.

OTHER FUNCTIONS
182
3. Touch “English”, “Français” or “Es-
pañol” to select a language.
If a screen other than for the navigation
system is displayed, the current screen
would change to the “CAUTION” screen by
pushing the “MAP/VOICE”, “DEST” or
“MENU” button.
4. Touch “OK”.
The language is changed and the screen
returns to the map display.

SECTION 6
AUDIO/VIDEO SYSTEM
183
AUDIO/VIDEO SYSTEM
Audio/video system
Quick reference 184. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using your audio/video system 185. . . . . . . . . . . . . . . . . . . . . . . . . .
Some basics185 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio operation191 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DVD changer operation203 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video remote controls 233. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio/video system operating hints 234. . . . . . . . . . . . . . . . . . . . . .

AUDIO/VIDEO SYSTEM
184
1Function button display screen
Touch the buttons displayed on the
screen to control the radio and DVD
changer. For details, see page 188.
2“DISC·AUX” button
Push this button to turn the DVD
changer or DVD player on. For de-
tails, see pages 187, 206.
3“SCAN” button
Push this button to scan radio sta-
tions or scan the tracks,discs, files or
folders. For details, see pages 193,
199, 209, 214.
4“LOAD” button
Push this button to insert the discs.
For details, see page 203.
5“AUDIO CONTROL”/“TUNE·FILE”
knob
Push this knob to adjust the audio
sounds. Turn this knob to move up or
down the station band or file. For de-
tails, see page 191 and 212.
6“CH·DISC” button
Push “” or “” button to select a
preset radio channel or a selected
disc. For details, see pages 193, 205
and 207.
Quick reference

AUDIO/VIDEO SYSTEM
185
7Disc slot
Insert discs into the slot after pushing
“COAD” button. For details, see page
203.
8“SEEK·TRACK” button
Push “” or “” button to seek up
or down for a station, or to access a
desired program, track, file or chap-
ter. For details, see pages 193, 199,
208, 212, 220 and 230.
9“PWR·VOL” knob
Push this knob to turn the audio sys-
tem on and off, and turn it to adjust the
volume. For details, see page 186.
10 button for the discs
Push this button to stop and eject the
discs. For details, see page 205.
11“AM·SAT” button
Push this button to choose either an
AM or SAT station. For details, see
pages 187, 191 and 197.
12“FM” button
Push this button to choose an FM sta-
tion. For details, see pages 187 and
191.
13“AUDIO” button
Push this button to display the audio
control screen. For details, see page
186, 208, 210, 217 and 228.This section describes some of the basic
features on Toyota audio/video systems.
Some information may not pertain to your
system.
Your audio/video system works when the
“ENGINE START STOP” switch is in the
ACCESSORY or IGNITION ON mode.
NOTICE
To prevent the battery from being dis-
charged, do not leave the audio/video
system on longer than necessary
when the engine is not running.
Using your audio/video
system —
— Some basics

AUDIO/VIDEO SYSTEM
186
CAUTION
For vehicles sold in U.S.A. and
Canada:
Part 15 of the FCC Rules
FCC Warning:
Any unauthorized changes or
modifications to this equipment
will void the user’s authority to op-
erate this device.
Laser products
Do not take this unit apart or at-
tempt to make any changes
yourself. This is an intricate unit
that uses a laser pickup to re-
trieve information from the sur-
face of compact discs. The laser
is carefully shielded so that its
rays remain inside the cabinet.
Therefore, never try to disas-
semble the player or alter any of
its parts since you may be ex-
posed to laser rays and danger-
ous voltages.
This product utilizes a laser. Use
of controls or adjustments or
performance of procedures oth-
er than those specified herein
may result in hazardous radi-
ation exposure.
Turning the system on and off
“PWR·VOL”: Push this knob to turn the
audio system on and off. Turn this knob to
adjust the volume. The system turns on in
the last mode used.
“AUDIO”: Push this button to display
touch−screen buttons for audio system
(audio control mode).
You can select the function that enables
automatic return to the previous screen
from the audio screen. See “(a) Automatic
transition” on page 178 for details.

AUDIO/VIDEO SYSTEM
187
Switching between functions
Push “AM·SAT”, “FM” or “DISC·AUX”
button to turn on the desired mode. The
selected mode turns on immediately.
Push these buttons if you want to switch
from one mode to another.
If the disc is not set, DVD changer does not
turn on.
You can turn off each player by ejecting the
cassette tape or disc. If the audio system
was previously off, then the entire audio
system will be turned off when you eject
the cassette tape or disc. If another func-
tion was previously playing, it will come on
again.
6U5701T
6U5702T
6U5703T

AUDIO/VIDEO SYSTEM
188
6U5705T
The buttons for radio and DVD changer
operation are displayed on the function
button display screen when the audio con-
trol mode is selected.
Touch them lightly and directly on the
screen.
The selected button is highlighted.
INFORMATION
If the system does not respond to
a touch of a touchscreen button,
move your finger away from the
screen and then touch it again.
You cannot operate dimmed
touchscreen buttons.
Wipe off fingerprints on the sur-
face of the display using a glass
cleaning cloth.

AUDIO/VIDEO SYSTEM
189
Tone and balance
How good an audio program sounds to you
is largely determined by the mix of the
treble, midrange, and bass levels. In fact,
different kinds of music and vocal pro-
grams usually sound better with different
levels of treble, midrange, and bass.
A good balance of the left and right stereo
channels and of the front and rear sound
levels is also important.
Keep in mind that if you are listening to a
stereo recording or broadcast, changing
the right/left balance will increase the vol-
ume of one group of sounds while de-
creasing the volume of another.
1. Push the “AUDIO” button.
2. Touch “SOUND” to display the
sound adjustment screen.
3. Touch the desired button.
“TREB” “+” or “–”: Adjusts high−pitched
tones.
“MID” “+” or “–”: Adjusts mid−pitched
tones.
“BASS” “+” or “–”: Adjusts low−pitched
tones.
“FRONT” or “REAR”: Adjusts sound bal-
ance between the front and rear speakers.
“L” or “R”: Adjusts sound balance be-
tween the left and right speakers.
4. Touch “OK”.
The tone of each mode (for such as AM,
FM and DVD changer) can be adjusted.

AUDIO/VIDEO SYSTEM
190
DSP control
You can change the listening position or
turn on/off the surround function and the
automatic sound levelizer.
1. Push the “AUDIO” button.
2. Touch “DSP” to display the DSP
control mode screen.
Surround function:
Select “ON” of “SURROUND” and touch
“OK”.
The surround function will turn on.
Automatic sound levelizer (ASL):
When the audio sound becomes difficult to
hear due to road noise, wind noise or other
noises while driving, touch “ON”. The
system adjusts to the optimum volume and
tone quality according to the noise level.
When the system is on, the sound adjust-
ment level is displayed on the screen.
Selecting screen size
The video screen can be changed from
normal mode to wide mode.
1. Push the “AUDIO” button.
2. Touch “WIDE”.
Touching “WIDE” displayed on the
screen in the video control mode will
display the wide mode control screen.
“NORMAL”:When a 3  4 screen is dis-
played, the remaining parts
will be in black.
“WIDE 1”:When a 3  4 screen is dis-
played, the screen will be
widened horizontally to fill
the display.
“WIDE 2”:When a 3  4 screen is dis-
played, the screen will be
widened vertically and hori-
zontally, in the same ratio, to
fill the display.
When a 9  16 screen is
displayed, this mode should
be selected.
When you touch
, the previous
screen returns.
