TOYOTA LAND CRUISER 2008 J200 Owners Manual

275
3−2. Using the audio system
3
Interior features
Random playback
nTo play files from a particular folder in random order
Press (RAND).
n
To play all of the files on a disc in random order
Press and hold (RAND) until you hear a beep.
Repeating a file or a folder
nRepeating a file
Press (RPT).
n
Repeating a folder
Press and hold (RPT) until you hear a beep.
Switching the display
Press .
Each time the switch is pressed, the display changes in the order of
Folder no./File no./Elapsed time
Folder name File name Album title
(MP3 only) Track title
Artist name.

276 3−2. Using the audio system
nDisplay
Up to 12 characters can be displayed at a time.
If there are 13 characters or more, pressing and holding for 1
second or more will display the remaining characters.
A maximum of 24 characters can be displayed.
If is pressed for 1 second or more again or has not been pressed
for 6 seconds or more, the display will return to the first 12 characters.
Depending on the contents recorded, the characters may not be displayed
properly or may not be displayed at all.
nCanceling random, repeat and scan playback
Press
(RAND),
(RPT) or again.
nError messages
“ERROR”: This indicates a trouble either in the CD or inside the player.
The CD may be dirty, damaged or inserted up−side down.
“NO MUSIC”: This indicates that the MP3/WMA file is not included in the
CD.
nDiscs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea−
tures, or due to scratches, dirt or deterioration.
nCD player protection feature
To protect the internal components, playback is automatically stopped when
a problem is detected.
n
If CDs are left inside the CD pla yer or in the ejected position for
extended periods
CDs may be damaged and may not play properly.

277
3−2. Using the audio system
3
Interior features
nLens cleaners
Do not use lens cleaners. Doing so may damage the CD player.
nMP3 and WMA files
MP3 (MPEG Audio LAYER3) is a standard audio compression format.
Files can be compressed to approximately 1/10 of their original size by using
MP3 compression.
WMA (Windows Media
TM Audio) is a Microsoft audio compression format.
This format compresses audio data to a size smaller than that of the MP3
format.
There is a limit to the MP3 and WMA file standards and to the media/formats
recorded by them that can be used.
lMP3 file compatibility
Compatible standards
MP3 (MPEG1 LAYER3, MPEG2 LSF LAYER3)
Compatible sampling frequencies
MPEG1 LAYER3: 32, 44.1, 48 (kHz)
MPEG2 LSF LAYER3: 16, 22.05, 24 (kHz)
Compatible bit rates
MPEG1 LAYER3: 64, 80, 96, 112, 128, 160, 192, 224, 256, 320 (kbps)
MPEG2 LSF LAYER3: 64, 80, 96, 112, 128, 144, 160 (kbps)
* Compatible with VBR
Compatible channel modes: stereo, joint stereo, dual channel and
monaural
lWMA file compatibility
Compatible standards
WMA Ver. 7, 8, 9
Compatible sampling frequencies
32, 44.1, 48 (kHz)
Compatible bit rates
Ver. 7, 8: CBR 48, 64, 80, 96, 128, 160, 192 (kbps)
Ver. 9: CBR 48, 64, 80, 96, 128, 160, 192, 256, 320 (kbps)
* Only compatible with 2−channel playback

278 3−2. Using the audio system
lCompatible media
Media that can be used for MP3 and WMA playback are CD−Rs and CD−
RWs.
Playback in some instances may not be possible, depending on the status
of the CD−R or CD−RW. Playback may not be possible or the audio may
jump if the disc is scratched or marked with fingerprints.
lCompatible disc formats
The following disc formats can be used.
Disc formats: CD−ROM Mode 1 and Mode 2
CD−ROM XA Mode 2, Form 1 and Form 2
File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet)
MP3 and WMA files written in any format other than those listed above
may not play correctly, and their file names and folder names may not
be displayed correctly.
Items related to standards and limitations are as follows.
Maximum directory hierarchy: 8 levels
Maximum length of folder names/file names: 32 characters
Maximum number of folders: 192 (including the root)
Maximum number of files per disc: 255
lFile names
The only files that can be recogniz
ed as MP3/WMA and played are those
with the extension .mp3 or .wma.
lMulti−sessions
As the audio system is compatible with multi−sessions, it is possible to play
discs that contain MP3 and WMA files. However, only the first session can
be played.
lID3 and WMA tags
ID3 tags can be added to MP3 files, making it possible to record the track
title and artist name, etc.
The system is compatible with ID3 Ver. 1.0, 1.1, and Ver. 2.2, 2.3 ID3 tags.
(The number of characters is based on ID3 Ver. 1.0 and 1.1.)
WMA tags can be added to WMA files, making it possible to record the
track title and artist name in the same way as with ID3 tags.

279
3−2. Using the audio system
3
Interior features
lMP3 and WMA playback
When a disc containing MP3 or WMA files is inserted, all files on the disc
are first checked. Once the file check is finished, the first MP3 or WMA file
is played. To make the file check finish more quickly, we recommend you
do not write in any files other than MP3 or WMA files or create any unnec−
essary folders.
If the discs contain a mixture of music data and MP3 or WMA format data,
only music data can be played.
lExtensions
If the file extensions .mp3 and .wma are used for files other than MP3 and
WMA files, they will be mistakenly recognized and played as MP3 and
WMA files. This may result in large amounts of interference and damage
to the speakers.
lPlayback
To play MP3 file with steady sound quality, we recommend a fixed bit
rate of 128 kbps and a sampling frequency of 44.1 kHz.
CD−R or CD−RW playback may not be possible in some instances,
depending on the characteristics of the disc.
There is a wide variety of freeware and other encoding software for
MP3 and WMA files on the market, and depending on the status of the
encoding and the file format, poor sound quality or noise at the start of
playback may result. In some cases, playback may not be possible at
all.
When files other than MP3 or WMA files are recorded on a disc, it may
take more time to recognize the disc and in some cases, playback may
not be possible at all.
Microsoft, Windows, and Windows Media are the registered trade−
marks of Microsoft Corporation in the U.S. and other countries.
NOTICE
nCDs and adapters that cannot be used ( P. 271)
nPlayer precautions (
P. 272)

280
3−2. Using the audio system
Optimal use of the audio system
Using the AUDIO CONTROL function
nChanging modes
Pressing selects the mode to be change in the following
order.
“BAS”
“MID” “TRE” “FAD” “BAL”
“ASL” Displays the current mode
Changes the following set−
tings
Sound quality and vol−
ume balance
The sound quality and bal−
ance setting can be
changed to produce the
best sound.
Automatic Sound Level−
izer on/off
TUNEFILE
PUSHAUDIO CONTROL
TUNEFILE
PUSHAUDIO CONTROL
ITY32C011

281
3−2. Using the audio system
3
Interior features
nAdjusting sound quality
Turning adjusts the level.
*: The sound quality level is adjusted individually in each radio, cassette
tape or CD mode.
nAdjusting the Automatic Sound Levelizer (ASL)
Turning to the right turns on the ASL, and turning to
the left turns off the ASL.
ASL automatically adjusts the volume and tone quality according to the
noise level as you drive your vehicle.
Sound quality
mode
Mode
displayedLevelTurn to theleftTurn to the
right
Low−pitched
tones
*BAS−5 to 5
Low High Mid−pitched
tones
*MID−5 to 5
High pitched
tones
*TRE−5 to 5
Front/rear
volume balanceFAD F7 to R7 Shifts to rearShifts to
front
Left/right volume
balance
BAL L7 to R7 Shifts to left Shifts to right

282
3−2. Using the audio system
Using the AUX adapter
nOperating portable audio devices connected to the audio system
The volume can be adjusted using the vehicle’s audio controls. All other
adjustments must be made on the portable audio device itself. This adapter can be used to connect a portable audio device and lis
ten to it using the vehicle’s speakers.
Connect the portable audio
device.
Press .
AUX
ITY32C015
STEP1
STEP 2

283
3−2. Using the audio system
3
Interior features
Using the steering switches
Turning on the power
Press when the audio system is turned off.
The audio system can be turned off by holding the switch down until you
hear a beep.
Changing the audio source
Press when the audio system is turned on. The audio source
changes as follows each time the button is pressed. If a cassette tape
or CD is not inserted,
that mode will be skipped.
FM (1, 2)
CD player AUX
AM
Some audio features can be contro lled using the switches on the
steering wheel.
Vo l u m e
Radio: Select radio stations
CD: Select tracks, files,
discs and folders
Power on, select audio
source
MODE
ITY32C014

284 3−2. Using the audio system
Adjusting the volume
Press “+” on to increase the volume and “−” to decrease the
volume.
Hold down the button to continue increasing or decreasing the volume.
Selecting a radio station
Press to select the radio mode.
Press “ ” or “ ” on to select a radio station.
To scan for receivable stations, press and hold the switch until you
hear a beep.
To step up or down the frequency, press and hold the switch ever
after you hear a beep.
Selecting a track/file
Press to select the cassette mode, CD or DVD mode.
Press “ ” or “
” on to select the desired track/file.
Selecting a disc in the CD player
Press to select the CD mode.
Press and hold “ ” or “
” on until you hear a beep.
CAUTION
nTo reduce the risk of an accident
Exercise care when operating the audio switches on the steering wheel.
STEP1
STEP 2
STEP 1
STEP 2
STEP 1
STEP 2
