TOYOTA LAND CRUISER 2008 J200 Owners Manual

315
3−3. Using the rear seat entertainment system
3
Interior features
nDVD video discs
l
The DVD player conforms to NTSC color TV formats.
l
Region code: Some DVD video discs have a region code indi−
cating the region in which you c
an use the DVD video disc. If the
DVD video disc is not labeled as “ALL” or “1”, you cannot use it
on this DVD player. If you attemp
t to play an inappropriate DVD
video disc on this player, “Region Code Error” appears on the
screen. Even if the DVD video di
sc does not have a region code,
you may not be able to use it.
l
The front DVD player supports multi−channel surround sound.
The rear DVD player does not support multi−channel surround
sound. (only 2−channel sound is output.)

316 3−3. Using the rear seat entertainment system
nSymbols shown on DVD video discs
Symbol Meaning
Indicates NTSC format.
Indicates the number of audio tracks.
Indicates the number of language subtitles.
Indicates the number of angles.
Indicates the screen display ratios available.
Wide screen: 16:9
Standard: 4:3
Indicates the disc’s region code.
ALL: in all countries
Number: region code

317
3−3. Using the rear seat entertainment system
3
Interior features
nDiscs that can be used
Discs with the marks shown below can be used.
Playback may not be possible depending on recording format or disc fea−
tures, or due to scratches, dirt or deterioration.
nDVD video disc information
l
DVD video discs
Digital Versatile Disc that holds video. DVD video discs have adopted
“MPEG2”, one of the world standards of digital compression technolo−
gies. The picture data is compressed by 1/40 on average and stored.
Variable rate encoding technology in which the volume of data assigned
to the picture is changed depending on the picture format has also been
adopted. Audio data is stored using PCM and Dolby digital, which
enables higher quality of sound. Furthermore, multi−angle and multi−lan−
guage features will also help you enjoy the more advanced technology of
DVD video.

318 3−3. Using the rear seat entertainment system
lViewer restrictions
This feature limits what can be viewed in conformity with the level of
restrictions of the country. The level of restrictions varies depending on
the DVD video disc. Some DVD video discs cannot be played at all, or
violent scenes are skipped or replaced with other scenes.
Level 1: DVD video discs for children can be played.
Level 2−7: DVD video discs for children and G−rated movies can be
played.
Level 8: All types of DVD video discs can be played.
lMulti−angle option
You can enjoy the same scene from different angles.
lMulti−language option
You can select the subtitle and audio languages.
lRegion codes
The region codes are found on DVD players and DVD discs. If a DVD
video disc does not have the same region code as the DVD player, you
cannot play the disc on that DVD player. (
P. 315)
lAudio
This DVD player can play linear PCM, Dolby Digital and MPEG audio for−
mat DVD. Other decoded types cannot be played.
lTitle and chapter
Video and audio programs stored in DVD video discs are divided into
parts by title and chapter.
Title: The largest unit of the video and audio programs stored on DVD
video discs. Usually, one movie, one album, or one audio program is
assigned as a title.
Chapter: A title is comprised of one or more chapters.

319
3−3. Using the rear seat entertainment system
3
Interior features
nSound
lDolby Digital
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double−D symbol are trademarks of Dolby
Laboratories. Confidential unpublished works.
©1992−1997 Dolby Laboratories. All rights reserved.
This product incorporates copyright protection technology that is pro−
tected by method claims of certain U. S. patents and other intellectual
property rights owned by Macrovision Corporation and other rights own−
ers. Use of this copyright protection technology must be authorized by
Macrovision Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision Corpora−
tion.
Reverse engineering or disassembly is prohibited.
lDTS
“DTS” and “DTS Digita l Surround” are registered trademarks of Digital
Theater System, Inc.
n
P. 277
CAUTION
nDVD video precaution
Conversational speech on some DVDs is recorded at a low volume to
emphasize the impact of sound effects. If you adjust the volume assuming
that the conversations represent the maximum volume level that the DVD
will play, you may be startled by louder sound effects or when you change to
a different audio source.
Loud sounds may have a significant impact on the human body or pose a
driving hazard. Keep this in mind when you adjust the volume.

320 3−3. Using the rear seat entertainment system
NOTICE
n
P. 271
nPlayer precautions
Failure to follow the precautions below may result in damage to the discs or
the player itself.
lDo not insert anything other than discs into the disc slot.
lDo not apply oil to the player.
lStore discs away from direct sunlight.
l
Never try to disassemble any part of the player.

321
3−3. Using the rear seat entertainment system
3
Interior features
Using the video mode
Using the adapter
Open the cover.
The A/V input adapter is com−
posed of 3 input adapters.
Yellow: Image input adapter
White: Left channel audio input
adapter
Red: Right channel audio input
adapter
Press to select the
video mode.
Before switching to the video
mode, connect the audio−video
equipment to the A/V input
adapter.

322 3−3. Using the rear seat entertainment system
Changing to PAL format
Press .
If the video does not appear, turn
on.
will be displayed
when the audio−video equipment
is connected to the A/V input
adapter.
nA/V input adapter
The rear seat entertainment system plays videos and sound when audio−
video equipment is connected to the A/V input adapter. For details, refer to
the manufacturer ’s instructions.
nPower outlet
The power outlet is used to connect the audio−video equipment. (
P. 344)
NOTICE
nWhen the A/V input adapter is not in use
Keep the A/V input adapter cover closed.
Inserting anything other than an appropriate plug may cause electrical fail−
ure or a short circuit.

323
3−3. Using the rear seat entertainment system
3
Interior features
Changing other settings
Setting the display mode
Pressing changes the dis−
play modes sequentially as fol−
lows:
Normal Wide 1
Wide 2
Adjusting the screen
Press .
Select the brightness, contrast,
tone or color, and make adjust−
ments. Press or to
input it.
“Color” Red Green
“Tone” Lighter Darker
“Contrast” Weaker Stronger
“Brightness” Darker Brighter

324 3−3. Using the rear seat entertainment system
Automatic closing of the rear display
Press .
If is on, the display
will automatically close when the
“ENGINE START STOP” switch is
turned to OFF mode.
The display will automatically
open when the “ENGINE START
STOP” switch is turned to
ACCESSORY or IGNITION ON
mode.
Displaying the map screen
Press .
The map screen will appear.
