TOYOTA LAND CRUISER 2008 J200 Owners Manual

245
3−1. Using the air conditioning system and defogger
3
Interior features
nChanging the air outlets
Press .
For driver ’s seat
For front passenger ’s seat
The air outlets switch each time
the button is pressed.
Different air outlets for the driver ’s
and front passenger ’s seats can
be chosen.
*: Driver side only
Air flows to the upper body.
: Only in the automatic mode
Air flows to the upper body and
feet.
*

246 3−1. Using the air conditioning system and defogger
Air flows to the feet.
Air flows to the feet and the
windshield defogger operates.
nSwitching between outside air and recirculated air modes
Vehicles with windshield wiper de−icer
Press .
The mode switches between outside air mode (indicator off) and
recirculated air mode (indicator on) each time the button is pressed.
Vehicles without windshield wiper de−icer
Press to switch to recirculated air mode and press
to switch to outside air mode.
ITY31C013
ITY31C014

247
3−1. Using the air conditioning system and defogger
3
Interior features
Changing the rear seat settings from the front seat
nAdjusting the temperature setting
Press .
Press “ ” to increase the temperature and “ ” to decrease the
temperature on (for left−hand rear seat) and
(for right−hand rear seat).
The temperature for the right−hand and left−hand rear seats can be
adjusted separately. Operating the switch will enter individual mode.
The air conditioning system switches between individual and simul−
taneous modes each time is pressed.
nAdjusting the fan speed
Press .
Press “
” (increase) or “ ” (decrease) on .
The fan speed is shown on the display. (7 levels)
Press to turn the fan off.
STEP1
STEP 2
STEP1
STEP 2

248 3−1. Using the air conditioning system and defogger
nChanging the air outlets
Press .
Press .
The air outlets switch each time the button is pressed. (P. 245)
Defogging the windshield
Press .
The air conditioning system con−
trol operates automatically.
Recirculated air mode will auto−
matically switch to outside air
mode.
Micro dust and pollen filter
Press .
Outside air mode switches to recirculated air mode. Pollen is removed
from the air and the air flows to the upper part of the body.
Usually the system will turn off automatically approximately 3 minutes
later.
To stop the operation, press again.
STEP1
STEP 2
FRONTREARA/C
ITY31C023

249
3−1. Using the air conditioning system and defogger
3
Interior features
Adjusting the position and opening and closing the air outlets
Front center outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Front side outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
Rear center outlets
Direct air flow to the left or
right, up or down.
Turn the knob to open or close
the vent.
ITY31C030

250 3−1. Using the air conditioning system and defogger
nUsing the automatic mode
Fan speed is adjusted automatically in accordance with the temperature set−
ting and ambient conditions. As a result, the following may occur.
lThe system may switch automatically to recirculated air mode when the
coolest temperature setting is selected in summer.
lImmediately after is pressed, the fan may stop for a while until
warm or cool air is ready to flow.
lCool air may flow to the area around the upper body when the heater is
on.
nUsing the system in recirculated air mode
The windows will fog up more easily if the recirculated air mode is used for
an extended period.
nWindow defogger feature
Recirculated air mode may automatically switch to outside air mode in situa−
tions where the windows need to be defogged.
nWhen outside temperature approaches 32F (0C).
The air conditioning system may not operate even when is
pressed.
nMicro dust and pollen filter
lIn order to prevent the windows from fogging up when the outside air is
cold, the following may occur.
Outside air mode does not switch to recirculated air mode.
The air conditioning system operates automatically.
The operation cancels after 1 minute.
l
In rainy weather, the windows may fog up. press .

251
3−1. Using the air conditioning system and defogger
3
Interior features
CAUTION
nTo prevent the windshield from fogging up
Do not use during cool air operation in extremely humid weather.
The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, blocking
your vision.
NOTICE
nTo prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

252
3−1. Using the air conditioning system and defogger
Rear air conditioning system
Using the automatic mode
Press .
The air conditioning system will begin to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set−
ting.
Press “ ” to increase the temperature and “ ” to decrease the
temperature on .
The temperature for the right−hand and left−hand rear seats can be
set separately.
Airflow and outlets are automatical ly adjusted according to the tem
perature setting.
Left side temperature controlLeft side temperature setting displayFan speed display Airflow display
Right side temperature setting display
Right side temperature control
Off Changes
the air
outlets used
Fan speed
Automatic mode
STEP1
STEP 2

253
3−1. Using the air conditioning system and defogger
3
Interior features
Adjusting the settings
nAdjusting the temperature setting
Press “
” to increase the temperature and “ ” to decrease the tem−
perature on .
The temperature for the right−hand and left−hand rear seats can be
set separately.
nAdjusting the fan speed
Press “
” (increase) or “ ” (decrease) on .
The fan speed is shown on the display. (7 levels)
Press to turn the fan off.
nChanging the air outlets
Press .
The air outlets switch each time the button is pressed.

254 3−1. Using the air conditioning system and defogger
Air flows to the upper body.
Air flows to the upper body and
feet.
Air flows to the feet.
ITY31C020
ITY31C021
ITY31C022
