air condition TOYOTA LAND CRUISER 2013 J200 Owners Manual

TABLE OF CONTENTS
1
LC200_OM_OM60F57U_(U)
1Before drivingAdjusting and operating features such as door locks,
mirrors, and steering column
2When drivingDriving, stopping and safe-driving information
3Interior
featuresAir conditioning and audio systems, as well as other in-
terior features for a comfortable driving experience
4Maintenance
and careCleaning and protecting your vehicle, performing do-it-
yourself maintenance, and maintenance information
5When trouble
arisesWhat to do if the vehicle needs to be towed, gets a flat
tire, or is involved in an accident
6Vehicle
specificationsDetailed vehicle information
7For U.S.
ownersReporting safety defects for U.S. owners
IndexAlphabetical listing of information contained in this
manual

TABLE OF CONTENTSIndex
2
LC200_OM_OM60F57U_(U)
1-1. Key information
Keys ..................................... 30
1-2. Opening, closing and
locking the doors
Smart key system................. 32
Wireless remote control ....... 44
Side doors ............................ 46
Back door ............................. 51
1-3. Adjustable components
(seats, mirrors,
steering wheel)
Front seats ........................... 57
Rear seats ............................ 59
Driving position memory
system ................................ 68
Head restraints ..................... 72
Seat belts ............................. 76
Steering wheel ..................... 86
Inside rear view mirror.......... 88
Outside rear view mirrors ..... 901-4. Opening and closing the
windows and moon roof
Power windows..................... 93
Moon roof ............................. 97
1-5. Refueling
Opening the fuel tank
cap .................................... 101
1-6. Theft deterrent system
Engine immobilizer
system .............................. 105
Alarm .................................. 107
1-7. Safety information
Correct driving posture ....... 111
SRS airbags ....................... 113
Front passenger occupant
classification system ......... 129
Child restraint systems ....... 135
Installing child restraints ..... 140
1Before driving
For vehicles with a navigation system, refer to the “Navigation System Owner’s
Manual” for information regarding the equipment listed below.
• Navigation system
• Air conditioning
• Climate control• Audio/video system
• Rear view monitor system

TABLE OF CONTENTSIndex
4
LC200_OM_OM60F57U_(U)
3-1. Using the air conditioning
system and defogger
Front air conditioning
system .............................. 336
Rear air conditioning
system .............................. 347
Rear window
and outside rear view
mirror defoggers............... 351
Windshield wiper de-icer .... 352
3-2. Using the audio system
Audio system type .............. 353
Using the radio ................... 356
Using the CD player ........... 365
Playing back MP3 and
WMA discs ....................... 373
Operating an iPod .............. 380
Operating a
USB memory.................... 387
Optimal use of the
audio system .................... 395
Using the AUX port ............ 397
Using the steering
switches ........................... 3983-3. Using the Bluetooth
®
audio system
Bluetooth
® audio system .... 402
Using the Bluetooth®
audio system .................... 406
Operating a Bluetooth
®
enabled portable player .... 412
Setting up a Bluetooth
®
enabled portable player .... 415
Bluetooth
® audio system
setup ................................. 422
3-4. Using the hands-free system
(for cellular phone)
Hands-free system
(for cellular phone) ........... 423
Using the hands-free
system .............................. 428
Making a phone call............ 436
Setting a cellular phone ...... 441
Security and system
setup ................................. 447
Using the phone book......... 453
3-5. Using the interior lights
Interior lights list.................. 462
• Interior lights ..................... 463
• Personal lights .................. 464
3-6. Using the storage features
List of storage features ....... 466
• Glove box ......................... 467
• Console box ..................... 468
• Overhead console ............ 469
• Cup holders ...................... 470
• Bottle holders ................... 472
• Card holders ..................... 474
• Auxiliary boxes ................. 474
3Interior features

1
2
3
4
5
6
7
5
LC200_OM_OM60F57U_(U)
3-7. Other interior features
Cool box .............................. 475
Sun visors ........................... 477
Vanity mirror........................ 478
Clock ................................... 479
Outside temperature
display............................... 480
Ashtrays .............................. 482
Cigarette lighter................... 484
Power outlets ...................... 485
Heated steering wheel ........ 487
Seat heaters
and ventilators .................. 489
Armrest ............................... 491
Assist grips.......................... 492
Floor mats ........................... 493
Luggage compartment
features ............................. 495
Garage door opener............ 497
Safety Connect ................... 5044-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ........... 512
Cleaning and protecting
the vehicle interior ............ 515
4-2. Maintenance
Maintenance
requirements .................... 518
General maintenance ......... 520
Emission inspection
and maintenance (I/M)
programs .......................... 523
4-3. Do-it-yourself maintenance
Do-it-yourself service
precautions....................... 524
Hood ................................... 527
Engine compartment .......... 528
Tires ................................... 544
Tire inflation pressure ......... 553
Wheels ............................... 557
Air conditioning filter ........... 560
Electronic key battery ......... 563
Checking and
replacing fuses ................. 566
Headlight aim ..................... 579
Light bulbs .......................... 581
4Maintenance and care

10
LC200_OM_OM60F57U_(U)
Power window
switch
P. 93
Pictorial indexInterior
Seat belt P. 76
SRS front passenger
airbag
P. 113
SRS driver airbag P. 113
Head restraint P. 72
Front seats
P. 57
SRS side airbags
P. 113
Console box
Cool box

P. 468
P. 475
Ashtray P. 482
Rear air conditioning
controls
Power outlet
P. 347
P. 485
Armrest P. 491Floor mat
P. 493
Rear seats P. 59

15
LC200_OM_OM60F57U_(U)
A
Windshield wiper
de-icer switch

P. 352
Clock P. 479
Security indicator
light
P. 105, 107
Audio system
P. 353
Front passenger AIR BAG
ON and AIR BAG OFF
indicator
P. 129
Front passenger’s seat belt
reminder light
P. 609
Air conditioning
system
P. 336
Rear air conditioning control
switch
P. 347
Emergency flasher
switch
P. 598
Rear window defogger
switch
P. 351
Without navigation system
: If equipped
Outside temperature
display
P. 480

16
LC200_OM_OM60F57U_(U)
Pictorial indexInstrument panel
A
Audio system*
Front passenger’s seat belt
reminder light
P. 609
Front passenger AIR BAG ON and
AIR BAG OFF indicator
P. 129
Clock*
Outside temperature
display
P. 480
Air conditioning
system
*
Emergency flasher
switch
P. 598
Security indicator
light
P. 105, 107
With navigation system
Rear window
defogger switch

P. 351
Navigation system*

36 1-2. Opening, closing and locking the doors
LC200_OM_OM60F57U_(U)
■Operation signals
A buzzer sounds and the emergency flashers flash to indicate that the doors
have been locked/unlocked. (Locked: Once; Unlocked: Twice)
■Conditions affecting operation
The smart key system uses weak radio waves. In the following situations,
the communication between the electronic key and the vehicle may be
affected, preventing the smart key system and wireless remote control from
operating properly. (Ways of coping P. 651)
●When the electronic key battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electri-
cal noise
●When carrying a portable radio, cellular phone, cordless phone or other
wireless communication devices
●When the electronic key has come into contact with, or is covered by a
metallic object
●When multiple electronic keys are in the vicinity
●When carrying or using the electronic key together with the following
devices that emit radio waves
• Another vehicle’s electronic key
• A wireless key that emits radio waves
• Personal computer
●If window tint with a metallic content or metallic objects are attached to
the rear window

117 1-7. Safety information
1
Before driving
LC200_OM_OM60F57U_(U)
■SRS airbag deployment conditions (SRS front airbags)
●The SRS front airbag will deploy in the event of an impact that exceeds
the set threshold level (the level of force corresponding to an approxi-
mately 12 - 18 mph [20 - 30 km/h] frontal collision with a fixed wall that
does not move or deform).
However, this threshold velocity will be considerably higher in the following
situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole,
which can move or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in
which the front of the vehicle “underrides”, or goes under, the bed of a
truck
●Depending on the type of collision, it is possible that only the seat belt
pretensioners will activate.
●The SRS front airbags for the front passenger will not activate if there is
not passenger sitting in the front passenger seat. However, the front air-
bags for the front passenger may deploy if luggage is put in the seat,
even if the seat is unoccupied.
■SRS airbag deployment conditions (SRS side airbags and SRS curtain
shield airbags)
●The SRS side airbags and SRS curtain shield airbags will deploy in the
event of an impact that exceeds the set threshold level (the level of force
corresponding to the impact force produced by an approximately 3300 lb.
[1500 kg] vehicle colliding with the vehicle cabin from a direction perpen-
dicular to the vehicle orientation at an approximate speed of 12 - 18 mph
[20 - 30 km/h]).
●The SRS curtain shield airbags will deploy in the event of vehicle rollover.

118 1-7. Safety information
LC200_OM_OM60F57U_(U)
■Conditions under which the SRS airbags may deploy (inflate), other
than a collision
The SRS front airbags may also deploy if a serious impact occurs to the
underside of your vehicle. Some examples are shown in the illustration.
The SRS curtain shield airbags may also deploy under the situations shown
in the illustration.
■Types of collisions that may not deploy the SRS airbag (front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a
side or rear collision, if it rolls over, or if it is involved in a low-speed frontal
collision. But, whenever a collision of any type causes sufficient forward
deceleration of the vehicle, deployment of the SRS front airbags may occur.
●Hitting a curb, edge of pavement or
hard surface
●Falling into or jumping over a deep hole
●Landing hard or falling
●The angle of vehicle tip-up is marginal.
●The vehicle skids and hits a curb stone.
●Collision from the side
●Collision from the rear
●Vehicle rollover
