TOYOTA LAND CRUISER 2015 J200 Owners Manual

5
When trouble arises
631
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle. Indicates that all main-
tenance according to
the driven distance on
the maintenance
schedule
* should be
performed soon. If necessary, perform
maintenance.
Comes on approxi-
mately 4500 miles
(7200 km) after the
message has been
reset.
Indicates that all main-
tenance is required to
correspond to the
driven distance on the
maintenance sched-
ule
*. Perform the necessary
maintenance.
Please reset the mes-
sage after the mainte-
nance is performed
(
P. 523)
Comes on approxi-
mately 5000 miles
(8000 km) after the
message has been
reset. (The indicator
will not work properly
unless the message
has been reset.)
Warning messageDetailsCorrection procedure

632 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Warning messageDetailsCorrection procedure
(Flashes)
(If equipped) Indicates that the pre-
collision system is not
currently functional
because the grille or
the sensor is dirty
• Check the grille and the
sensor and clean them
if they are dirty.
• In case of overheating, the system will become
functional once the sys-
tem cools down.
Indicates that the pre-
collision system is not
currently functional
due to overheating.
Indicates that intui-
tive parking assist is
dirty or covered with
ice
Clean the sensor.
Indicates that remain-
ing fuel is about 4.0
gal. (15.0 L, 3.3 Imp.
gal.) or less Refuel the vehicle.

5
When trouble arises
633
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
(If equipped)
Indicates that the
dynamic radar cruise
control sensor is dirty
or covered with ice
Clean the sensor.
(If equipped) Indicates that the
dynamic radar cruise
control system is
unable to judge vehi-
cle-to-vehicle distance
• Switch driving mode to
either normal or power.
• If the windshield wipers are on, turn them off or
set them to either inter-
mittent or slow mode.
(Flashes)
(If equipped) Indicates that your
vehicle is nearing the
vehicle ahead (in vehi-
cle-to-vehicle dis-
tance control mode)
A buzzer also sounds. Slow the vehicle by
applying the brakes.
Warning messageDetailsCorrection procedure

634 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Have the malfunction repaired immediately.After taking the specified steps to correct the suspected problem,
check that the warning message and light go off.
Interior buzzerExterior buzzerWarning messageDetailsCorrection procedure
Once3 times
(Flashes) The electronic key
was carried out-
side the vehicle
and a door other
than the driver’s
door was opened
and closed while
the “ENGINE
START STOP”
switch was in a
mode other than
off.
Bring the
electronic
key back
into the
vehicle.
The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
in “P” and the
“ENGINE START
STOP” switch was
not turned off. Turn the
“ENGINE
START
STOP”
switch off
or bring the
electronic
key back
into the
vehicle.

5
When trouble arises
635
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
*: If the engine does not start when the electronic key is inside the vehicle, the
electronic key battery may be depleted or there may be difficulty receiving
signal from the key. ( P. 659)
Once
(Flashes) An attempt was
made to start the
engine without the
electronic key
being present, or
the electronic key
was not function-
ing normally.
An attempt was
made to drive
when the regular
key was not inside
the vehicle.
Start the
engine with
the elec-
tronic key
present
*.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

636 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Interior buzzerExterior buzzerWarning messageDetailsCorrection procedure
Contin-
uous
(Flashes) The driver’s door
was opened when
the shift lever was
not in “P” and the
“ENGINE START
STOP” switch was
not turned off.
Shift the
shift lever
to “P”.
Contin-
uous
Contin-
uous
(Displayed alternately)
(Flashes) The driver’s door
was opened and
closed while the
electronic key was
not in the vehicle,
the shift lever was
not in “P” and the
“ENGINE START
STOP” switch was
not turned off.
• Shift the
shift lever
to “P”.
• Bring the electronic
key back
into the
vehicle.

5
When trouble arises
637
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Once
(Flashes) • When the doors
were unlocked with
the mechanical
key and then the
“ENGINE START
STOP” switch was
pressed, the elec-
tronic key could
not be detected in
the vehicle.
• The electronic key could not be
detected in the
vehicle even after
the “ENGINE
START STOP”
switch was
pressed two con-
secutive times. Touch the
electronic
key to the
“ENGINE
START
STOP”
switch
while
depressing
the brake
pedal.
Once
The electronic key
has a low battery.Replace
the elec-
tronic key
battery.
(
P. 567)
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

638 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Once(Flashes) A door was
opened and closed
with the “ENGINE
START STOP”
switch turned off
and then the
“ENGINE START
STOP” switch was
put in ACCES-
SORY mode twice
without the engine
being started. Press the
“ENGINE
START
STOP”
switch
while
depressing
the brake
pedal.
Once
(Flashes) The steering lock
could not be
released within 3
seconds of the
“ENGINE START
STOP” switch
being pressed. Press the
“ENGINE
START
STOP”
switch
while
depressing
the brake
pedal and
moving the
steering
wheel left
and right.
Interior
buzzerExterior buzzerWarning messageDetailsCorrection procedure

5
When trouble arises
639
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Other messages
If the following message is disp layed, take appropriate action and
confirm that the message has disappeared. ( P. 249)
MessageCorrection procedure
Select the four-wheel drive control switch in L4
and shift the shift lever to “D” or “R”.
Confirm the operating conditions.
Confirm the operating conditions to operate
Turn Assist function.
Turn on the Crawl Control switch to operate
Turn Assist function.

640 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
■Warning message in vehicle-to-vehicle distance control mode of
the dynamic radar cruise control (if equipped)
In the following cases, the warning message may not be displayed even
if vehicle-to-vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same
speed or the vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
■Resetting the tire pressure warning data
After adjusting the tire inflation pres sure, be sure to initialize the data.
(  P. 549)
If the message remains on, the system may have malfunctioned. Have
the vehicle inspected by your Toyota dealer as soon as possible.
