Page 391 of 632

LC200_OM_OM60T03U_(U)
3914-6. Driving tips
4
Driving
WARNING
■Driving with snow tires
Observe the following precautions to reduce the risk of acciden ts.
Failure to do so may result in a loss of vehicle control and ca use death or
serious injury.
● Use tires of the specified size.
● Maintain the recommended level of air pressure.
● Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.
● Use snow tires on all, not just some wheels.
■ Driving with tire chains
Observe the following precautions to reduce the risk of acciden ts.
Failing to do so may result in the vehicle being unable to be d riven safely,
and may cause death or serious injury.
● Do not drive in excess of the speed limit specified for the tir e chains being
used, or 30 mph (50 km/h), whichever is lower.
● Avoid driving on bumpy road surfaces or over potholes.
● Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.
● Slow down sufficiently before entering a curve to ensure that v ehicle con-
trol is maintained.
● Do not use LDA (Lane Departure Alert) system. (if equipped)
NOTICE
■Repairing or replacing snow tires
Request repairs or replacement of snow tires from Toyota dealer s or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affect s the opera-
tion of the tire pressure warning valves and transmitters.
■ Fitting tire chains
The tire pressure warning valves and transmitters may not funct ion correctly
when tire chains are fitted.
Page 392 of 632

392
LC200_OM_OM60T03U_(U)
4-6. Driving tips
Page 393 of 632

393
LC200_OM_OM60T03U_(U)
5Interior features
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system ........ 394
Rear air conditioning system............................. 406
Heated steering wheel/ seat heaters/
seat ventilators ................ 410 5-2. Using the interior lights
Interior lights list ................ 414• Interior lights ................. 415
• Personal lights .............. 416
5-3. Using the storage features List of storage features ..... 417• Glove box...................... 418
• Console box .................. 419
• Overhead console......... 420
• Cup holders .................. 421
• Bottle holders ................ 423
• Card holders ................. 424
• Auxiliary boxes.............. 424
Luggage compartment features ........................... 425
5-4. Using the other interior features
Other interior features ....... 428 • Cool box........................ 428
• Sun visors ..................... 430
• Vanity mirror ................. 430
• Clock ............................. 431
• Outside temperature display........................... 431
• Power outlets ................ 432
• Wireless charger ........... 434
• Armrest ......................... 442
• Coat hooks.................... 442
• Assist grips ................... 443
Garage door opener.......... 444
Page 394 of 632

394
LC200_OM_OM60T03U_(U)
5-1. Using the air conditioning system and defogger
Front automatic air conditioning system
■Adjusting the temperature setting
Press to increase the temperature and to decrease the
temperature.
If the “A/C” indicator is turned off, the system will blow ambi ent tempera-
ture air or heated air.
Air outlets and fan speed are automatically adjusted according
to the temperature setting.
Press to display the air conditioning control screen.
Control panel
Page 395 of 632

LC200_OM_OM60T03U_(U)
3955-1. Using the air conditioning system and defogger
5
Interior features
■Changing the air flow mode
Press .
The air flow mode switches
each time the button is pressed.
Air flows to the upper body
Air flows to the upper body
and feet
Air flows to the feet
Air flows to the feet and the
windshield defogger oper-
ates
Select the air flow mode
* (left-
hand side)
Air flows to the feet and the
windshield defogger operates
Select the air flow mode
* (right-
hand side)
Display the option control
screen ( P. 396)
Adjust the fan speed setting
Display the rear air conditioning control screen ( P. 3 9 8 )
To adjust or select settings, touch the screen button.
*: Air flows to the upper body
Air flows to the upper body and feet
Air flows to the feet
1
2
3
4
Control screen
1
2
3
4
5
6
Page 396 of 632

3965-1. Using the air conditioning system and defogger
LC200_OM_OM60T03U_(U)
Select to set cooling and dehu-
midification function on/off
Adjust the temperature for
driver, front passenger and rear
seats separately (Individual
mode) (P. 3 9 7 )
Prevent ice from building up on
the windshield and wiper
blades (if equipped) ( P. 400)
Remove pollen from the air (Mi cro dust and pollen filter) (P. 400)
■Using the automatic mode
Press .
Adjust the temperature setting.
To stop the operation, press .
■
Automatic mode indicator
If the fan speed setting or air flow modes are operated, the au to-
matic mode indicator goes off. However, automatic mode for func -
tions other than that o perated is maintained.
Option control screen
1
2
3
Air conditioning controls
4
1
2
Page 397 of 632

LC200_OM_OM60T03U_(U)
3975-1. Using the air conditioning system and defogger
5
Interior features
To turn on the individual mode, perform any of the following pr oce-
dures:
● Press “4-ZONE” on the option control screen.
● Adjust the passenger’s side temperature setting.
● Change the rear air conditioning setting
The indicator comes on when the individual mode is on.
To return to the simultaneous mode, press “4-ZONE”.
In the simultaneous mode, only or on the driver’s side can
be used to adjust the temperature for all seats.
Adjusting the temperature for driver and passenger seats sepa-
rately (Individual mode)
Page 398 of 632

3985-1. Using the air conditioning system and defogger
LC200_OM_OM60T03U_(U)
Press on the control
screen to display the rear air con-
ditioning control screen.
Adjust the temperature set-
ting (left-hand rear seat)
Adjust the fan speed setting
Adjust the temperature set-
ting (right-hand rear seat)
Select to set automatic mode
Turn the fan off
■Using the automatic modePress “REAR AUTO”.
The air conditioning system will operate, and air outlets and s peed will
be set automatically.
Press “ ” to increase the temperature and “ ” to decrease the
temperature.
Air outlets for the right-hand and left-hand may be set separat ely
depending on the temperature setting.
■
Adjusting the temperature setting
Press “ ” (increase) “ ” or (decrease).
Operating the switch will enter the individual mode. ( P. 397)
■
Adjusting the fan speed setting
Press (increase) or (decrease).
The fan speed is shown on the display. (7 levels)
Press “REAR OFF” to turn the fan off.
■
Turning the rear air conditioning system off
Press “REAR OFF”.
Changing the rear seat settings
1
2
3
4
5
1
2
Page 399 of 632

LC200_OM_OM60T03U_(U)
3995-1. Using the air conditioning system and defogger
5
Interior features
■Switching between outside air and recirculated air modes
Press .
The mode switches between (recirculated air mode) and
(outside air mode) modes each time the button is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Press .
Set the outside/recirculated air mode button to outside air mod e if the
recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the side windows early, turn the ai r flow and
temperature up.
To return to the previous mode, press again when the wind-
shield is defogged.
Other functions
Page 400 of 632

4005-1. Using the air conditioning system and defogger
LC200_OM_OM60T03U_(U)■
Defogging the rear window and
outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain -
drops, dew and frost from the outside rear view mirrors.
Press .
Press the switch again to turn the defogger off.
■
Micro dust and pollen filter
Press on the control screen.
Press .
Outside air mode switches to recirculated air mode. Pollen is removed
from the air and the air flows to the upper part of the body.
Usually the system will turn off automatically approximately 1 to 3 min-
utes.
To stop the operation, press again.
■
Windshield wiper de -icer (if equipped)
This feature is used to prevent ice from building up on the win d-
shield and wiper blades.
Press on the control screen.
Press .
Press again to turn the de-icer off.
1
2
1
2
