TOYOTA MATRIX 2010 E140 / 2.G Owners Manual

241 3-4. Using the interior lights
3
Interior features
Personal lights (vehicles without moon roof)
On/off
Personal lights

242
3-5. Using the storage features
List of storage features
Auxiliary boxes
Glove box
Bottle holders
Cup holders
Console box

243 3-5. Using the storage features
3
Interior features
Glove box
Pull up the lever.
Console box
Type A
Lift the lid while pulling the lever.
CAUTION
■Caution while driving
Keep the glove box closed.
Injuries may result in the event of an accident or sudden braking.
Glove box and console box

244 3-5. Using the storage features
Type B (upper)
Lift the lid while pulling the lever.
Type B (lower)
Lift the lid and tray while pulling
the lever.
CAUTION
■Caution while driving
Keep the console box closed.
Injuries may result in the event of an accident or sudden braking.
Console box

245 3-5. Using the storage features
3
Interior features
Cup holders
Front
Rear
Pull the lid to open.
■Using the cup holder (front) to store small items
Remove the holders.
Cup holders

246 3-5. Using the storage features
■Adjusting the cup holder to the size of the cups or drink-cans
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
■When not in use
Keep the rear cup holders closed.
Injuries may result in the event of an accident or sudden braking.
Remove the holder and change the
holder position.
Small size
Middle size
Large size
Cup holders

247 3-5. Using the storage features
3
Interior features
Bottle holders
Front
Rear
CAUTION
■Items unsuitable for the bottle holder
Do not place anything other than pet bottles in the bottle holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
Bottle holders

248 3-5. Using the storage features
Auxiliary boxes
Front
Pull up the lever.
Overhead console (vehicles with moon roof)
Push the lid.
NOTICE
■When a pet bottle is in the front bottle holder (vehicles with manual
window)
As there is a possibility of interfering with
a manual window regulator handle, pre-
vent the window from opening and clos-
ing, do not place a pet bottle in the holder
when turning the handle.
Bottle holders and auxiliary boxes

249 3-5. Using the storage features
3
Interior features
CAUTION
■Caution while driving
Keep the auxiliary boxes closed.
Injuries may result in the event of an accident or sudden braking.
■Items that should not be left in the overhead console
Do not leave glasses or lighters in the console.
If the interior of the vehicle becomes hot, lighters may explode and glasses
may warp or become cracked.
■Items unsuitable for storing (overhead console only)
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items inside may fall
out, resulting in an accident.
Auxiliary boxes

250
3-6. Other interior features
Sun visors
Forward position:
Flip down.
Side position:
Flip down, unhook, and
swing to the side.
