TOYOTA MIRAI 2023 Owners Manual

3616-3. Using the storage features
Owners Manual_USA_M62064_en
6
Interior features
 Side covers
Lift the side covers and remove it.
Ty p e A
Type B
 Luggage mat
1 Pull the strap upwards and lift
up the luggage mat. 2
Lift the luggage mat until it
engages with the hook.
Type A
The warning reflector can be
stowed underneath the luggage
mat.
Trunk features
Luggage mats
NOTICE
■To prevent damage to the
hook for the luggage mat
Do not hang a grocery bag or any
other object from the hook.
Warning reflector

3626-3. Using the storage features
Owners Manual_USA_M62064_en
Ty p e B
Using a belt to hold a warning
reflector on the luggage mat.

3636-4. Using the other interior features
Owners Manual_USA_M62064_en
6
Interior features
6-4.Using the other interior features
*: If equipped
1 Open*
2Close*
*: To stop the electronic sunshade
partway, lightly p ress the either
end of the switch.
■The electronic sunshade can be
operated when
The power swit ch is in ON.
■Jam protection function for the
electronic sunshade
●If an object becomes jammed
between the electronic sunshade
and the sunshade frame while the
electronic sunshade is closing, the
electronic sunshade movement is
stopped and the electronic sun-
shade is opened slightly.
●When the jam protection function
has operated, even if the
“CLOSE” side of the switch is
pressed again, the electronic sun-
shade will not m ove in the close
direction until the reverse opera- tion has stopped completely.
●The electronic sunshade may
operate in reverse if the electronic
sunshade is subject to an impact
due to the surro
undings or the
driving conditions.
■When the electronic sunshade
does not close normally
Perform the following initialization
procedure.
1 Turn the power switch to ON.
2 Press and hold the “CLOSE”
side of the switch.
It closes until it is near the fully
closed position and then stops. After
that, it operates in the opening
direction then closes to the fully
closed position.
If the switch is released at the incor-
rect time, the proc edure will have to
be performed again from the begin-
ning.
If the automatic opening and closing
function does not work normally
even after performing the operations
above, have the vehicle inspected
by your Toyota dealer.
Electronic sunshade*
Use the overhead switches
to operate the electronic
sunshade.
Operating the electronic
sunshade
WARNING
Observe the following precau-
tions.
Failure to do so may result in
death or serious injury.

3646-4. Using the other interior features
Owners Manual_USA_M62064_en
The USB Type-C charging ports
are used to supply 3 A of elec-
tricity at 5 V to external devices.
The USB Type-C charging ports
are for charging only. They are
not designed for data transfer or
other purposes.
Depending on the external
device, it may not charge prop-
erly. Refer to the manual
included with the device before
using a USB charging port.
Refer to “MULTIMEDIA
OWNER’S MANUAL” for USB
Type-A information.
■Using the USB Type-C
charging ports
In the console box
Open the console box.
Rear of the console box
Open the lid.
WARNING
■Opening and closing the elec-
tronic sunshade
●Check to make sure that all pas-
sengers do not have any part of
their body in a position where it
could be caught when the elec-
tronic sunshade is being oper-
ated.
●Do not let a child operate the
electronic sunshade. Closing
the electronic sunshade on
someone can cause death or
serious injury.
■Jam protection function
●Never use any part of your body
to intentionally a ctivate the jam
protection function.
●The jam protection function may
not work if something gets
caught just before the electronic
sunshade is fully closed. Also,
the jam protecti on function is
not designed to operate while
the switch is being pressed.
Take care so that your fingers,
etc., do not get caught.
■To prevent burns or injuries
Do not touch the area between
the underside of the panoramic
moon roof and the electronic sun-
shade. Your hand may get caught
and you could injure yourself.
Also, if the vehicle is left in direct
sunlight for a long time, the under-
side of the panoramic moon roof
could become very hot and could
cause burns.
Other interior features
USB Type-C charging
ports

3656-4. Using the other interior features
Owners Manual_USA_M62064_en
6
Interior features
■The USB Type-C charging ports
can be used when
The power switch i s in ACC or ON.
■Situations in which the USB
Type-C charging ports may not
operate correctly
●If a device which consumes more
than 3 A at 5 V is connected
●If a device designed to communi-
cate with a personal computer,
such as a USB memory device, is
connected
●If the connected external device is
turned off (depending on device)
●If the temperature inside the vehi-
cle is high, such as after the vehi-
cle has been parked in the sun
■About connected external
devices
Depending on the connected exter-
nal device, charging may occasion-
ally be suspended and then start
again. This is not a malfunction.
A portable device can be
charged by just placing Qi stan-
dard wireless charge compatible
portable devices according to
the Wireless Power Consortium,
such as smartphones and
mobile batteries, etc., on the
charge area.
This function cannot be used
with portable devices that are
larger than the charging area.
NOTICE
■To prevent damage to the
USB Type-C charging ports
●Do not insert foreign objects into
the ports.
●Do not spill water or other liq-
uids into the ports.
●When the USB Type-C charging
ports are not in use, close the
lids. If a foreign object or liquid
enters a port may cause a short
circuit.
●Do not apply excessive force to
or impact the USB Type-C
charging ports.
●Do not disassemble or modify
the USB Type-C charging ports.
■To prevent damage to exter-
nal devices
●Do not leave external devices in
the vehicle. The temperature
inside the vehicle may become
high, resulting in damage to an
external device.
●Do not push down on or apply
unnecessary force to an exter-
nal device or the cable of an
external device while it is con-
nected.
■To prevent 12-volt battery dis-
charge
Do not use the USB Type-C
charging ports for a long period of
time with the fuel cell system
stopped.
Wireless charger (if
equipped)

3666-4. Using the other interior features
Owners Manual_USA_M62064_en
Also, depending on the portable
device, it may not operate as
normal. Please read the opera-
tion manual for portable devices
to be used.
■The “Qi” symbol
The “Qi” symbol is a trademark
of the Wireless Power Consor-
tium.
■Name for all parts
Power supply switch
Operation indicator light
Charging tray
Charge area
*
*: Compatible portable devices and the wireless charger contain
charging coils. The charging coil
inside the wireless charger can move within the area around the
center of the charging tray.
When the charging coil inside a
portable device is detected within
the charging area, the charging
coil in the wirel
ess charger will
move near the other coil and
charging will begin. If the
charging coil inside the portable
device is moved out of the
charging area, charging will be
stopped automatically.
Additionally, if 2 or more portable
devices are placed on the
charging tray at t he same time,
each charging coil may not be
detected correctly and charging
may not be possible.
■Using the wireless charger
1 Press the power supply
switch of the wireless char-
ger.
Switches on and off with each
press of the power supply switch.
When turned on, the operation indi-
cator light (green) comes on.
Even with the fuel cell system off,
the on/off state of the power supply
switch is memorized.
2Place the charging side of
the portable device down.
Place the portable device so that it
is centered in the charging area
with its charging surface facing the

3676-4. Using the other interior features
Owners Manual_USA_M62064_en
6
Interior features
wireless charger.
Depending on the portable device,
its charging coil may not be in the
center of the device. In this case,
place the portable device so that its
charging coil is centered in the
charging area.
While charging, the operation indi-
cator light (orang e) will be illumi-
nated.
If charging does not begin, move
the portable device as close to the
center of the charging area as pos-
sible.
If charging is not performed, the
operation indicator light will slowly
illuminate in gr een and orange
alternatively and a sound of
charging coil operation may be
heard repeatedly.
When charging is complete, the
operation indicator light (green)
comes on.
■Recharging function
 When charging is complete
and after a fixed time in the
charge suspension state,
charging restarts.
 If a portable device is moved
significantly within the
charging area, the charging
coil may disconnect and
charging may temporarily be
stopped. However, if a
charging coil is detected within the charging area, the
charging coil inside the wire-
less charger will move near
the other coil and charging
will resume.
■Lighting conditions of oper-
ation indicator light
*1: While in standby, charging power
is not output. If a metal object is
placed on the charging tray in
this state, the object will not heat
up.
*2: Depending on the portable device, there are cases where
the operation indicator light will
continue being lit up orange even
after the charging is complete.
 When the operation indicator
light flashes
When an error occurs, the opera-
tion indicator light flashes an
orange color.
Handle the error based on the fol-
Operation
indicator light
Conditions
Turning off
When the Wireless
charger power supply
is off
Green
(comes
on)
On Standby (charging
possible state)
*1
When charging is com-
plete
*2
Orange
(comes
on)
When placing the por-
table device on the
charging area (detect-
ing the portable device)
Charging

3686-4. Using the other interior features
Owners Manual_USA_M62064_enlowing tables.
• Flashing repeatedly once every
second (Orange)
• Repeatedly flashes 3 times con- tinuously (Orange) • Repeatedly flashes 4 times con-
tinuously (Orange)
■The wireless charger can be
operated when
The power switch is in ACC or ON.
■Usable portable devices
●Qi standard wirel ess charge stan-
dard can be used on compatible
devices. However, not all Qi stan-
dard devices and compatibility are
guaranteed.
●Starting with mobile phones and
smartphones, it is aimed for low
power electrically supplied porta-
ble devices of no more than 5W.
■Using the smart key system
During charging, when the smart
key system searches for an elec-
tronic key, charging may be tempo-
rarily suspected.
■When covers and accessories
are attached to portable devices
Do not charge in situations where
cover and accessories not able to
handle Qi are attached to the porta-
ble device. Depending on the type
of cover (including the certain genu-
ine manufacture parts) and acces-
sory, it may not be possible to
charge. When charging is not per-
formed even with the portable
device placed on the charge area,
Suspected
causesHandling method
Vehicle to char-
ger communica-
tion failure.
If the fuel cell
system is operat-
ing, stop the fuel
cell system and
then restart it. If
the power switch
is in ACC, start
the fuel cell sys-
tem.
Suspected causesHandling method
A foreign sub-
stance is
between the por-
table device and
charge area.Remove the for-
eign substance
from between
portable device
and the charge
area.
The portable
device is out of
sync due to the
device being
shifted from the
center of the
charge area.
Place the porta-
ble device near
the center of the
charge area.
Also, if a case or
cover is installed
to the portable
device, remove
it.
Suspected causesHandling method
Temperature ris-
ing within the
wireless charger.
Stop charging,
remove the por-
table device from
the charging tray,
and wait for the
temperature to
decrease before
attempting to
begin charging
again.

3696-4. Using the other interior features
Owners Manual_USA_M62064_en
6
Interior features
remove the cover and accessories.
■While charging, noise enters
the AM radio
Turn off the wireless charger and
confirm that the noise has
decreased. If the noise decreases,
continuously pushing the power
supply switch of the wireless char-
ger for 2 seconds, the frequency of
the charger can be changed and the
noise can be reduced. Also, on that
occasion, the operation indicator
light will flash orange 2 times.
■Important points of the wire-
less charger
When charging, the wireless
charging device and portable device
will get warmer, however this is not
a malfunction.
When a portable device gets warm
while charging, charging may stop
due to the protection function on the
portable device side. In this case,
when the temperature of the porta-
ble device drops significantly,
charge again.
■Operation sounds
Operation sounds may be heard
when the power switch is pressed to
change to ACC or ON, or when a
portable device is being detected.
This does not indicate a malfunc-
tion.
■Certification
 P. 5 6 6
WARNING
■Caution while driving
When charging a portable device,
for safety reasons, the driver
should not operate the main part
of the portable device while driv-
ing.
■Precautions for when driving
Do not charge sma ll, lightweight
portable devices, such as wireless
earbuds, while driving. Light-
weight devices may fly off of the
charging tray, possibly leading to
an accident.
■Caution regarding interfer-
ence with electronic devices
People with implantable cardiac
pacemakers, cardiac resynchroni-
zation therapy-pacemakers or
implantable cardioverter def ibrilla-
tors, as well as any other electri-
cal medical device, should consult
their physician about the usage of
the wireless charger. The opera-
tions of the wireless charger may
have an affect on medical
devices.
■To prevent damage or burns
Observe the following precau-
tions.
Failure to do so may result in a
possibility of equipment failure
and damage, catch fire, burns due
to overheat.
●Do not insert any metallic
objects between the charging
area and the portable device
while charging
●Do not place containers with liq-
uid such as water on the wire-
less charger.
●Do not attach sti ckers, metallic
objects, etc., to the charger area
or portable device
●Do not hit or apply a strong
force
●Do not attempt to dismantle for
disassembly or modifications
●Do not charge portable devices
other than designated

3706-4. Using the other interior features
Owners Manual_USA_M62064_en
WARNING
●Do not allow magnetic objects
to come near the wireless char-
ger
●Do not perform charging if the
charging area is dirty
●Do not cover with cloth, etc.,
and charge
NOTICE
■Conditions in which the func-
tion may not operate cor-
rectly
In the following conditions, it may
not operate correctly
●The portable device is fully
charged
●When a portable device is being
charged by a wired connection
●There is foreign matter between
the charge area and portable
device
●When the temperature near the
charging tray is 95°F (35°C) or
more due to being in direct sun-
light, etc.
●The temperature of the portable
device gets higher from
charging
●The charging surface of the por-
table device is facing up
●When a portable device is larger
than the charging tray
●The small portable device such
as foldable type is placed in an
area misaligned from the
charge area
●The camera lens protrudes 0.12
in. (3 mm) or more from the sur-
face of the portable device
●Near a TV tower, electric power
plant, gas station, radio station,
large display, a irport or other
facility that gen erates strong
radio waves or electrical noise
●The electronic key is not inside
the vehicle
●When any of the following
objects are caug ht between the
device and charging surface,
resulting in a gap of 0.08 in. (2
mm) or more between the
charging surface of a portable
device and the charging area:
• Thick cases or covers
• Thick decorations
• A case or cover with convex shape around the camera lens
• Accessories, such as finger rings, straps, etc.
●When the portable device is in
contact with, or is covered by
the following metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have alu- minum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
• Metallic decorations
• Metallic cases or covers
• A case which has magnet in it on the charging side of the por-
table device
●When other wireless keys (that
emit radio waves) are being
used nearby
