(d) Continue to apply voltage, check that the current changes
from approximately 14 A to less than 1 A within 4 to 90 se-
conds.
(e) Disconnect the leads from terminals.
(f) Approximately 90 seconds later, connect the positive (+)
lead from the battery to terminal 1 and the negative (±)
lead to terminal 2, check that the window begins to de-
scend.
If operation is not as specified, replace the motor.
11. INSPECT JAM PROTECTION FUNCTION
NOTICE:
Never, ever be caught any part of your body when check-
ing.
HINT:
In case of performing resetting of the limit switch, do checking
after repeating up and down of the glass with automatic opera-
tion.
(a) Confirmation of AUTO up operation:
Confirm that the window will be fully close with AUTO up
operation.
(b) Checking of the operation of the jam protection function:
(1) Move up the window with AUTO up operation and
check that the window will go down when it touches
the handle of the hammer stetted.
(2) Confirm that the window will then stop going down
about 200 mm.
HINT:
In case of removing the glass, glass guide, regulator and etc.
be sure to perform checking of the jam protection function.
If the jam protection is not function properly, adjust power win-
dow motor reset switch and pulse switch.

BE1W7±01
I03147
I11689
LOCK
UNLOCK
I11690
LOCK
UNLOCK
I11689UNLOCKLOCK
I11690UNLOCK LOCK BE±62
± BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
INSPECTION
1. INSPECT DOOR LOCK CONTROL SWITCH CONTINU-
ITY
Switch positionTester connectionSpecified condition
LOCK3 ± 6Continuity
OFF±No continuity
UNLOCK3 ± 5Continuity
If continuity is not as specified, replace the switch.
2. Driver 's door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK3 ± 5Continuity
OFF±No continuity
UNLOCK3 ± 6Continuity
If continuity is not as specified, replace the switch.
3. Passenger 's door:
INSPECT DOOR KEY LOCK AND UNLOCK SWITCH
CONTINUITY
Switch positionTester connectionSpecified condition
LOCK2 ± 4Continuity
OFF±No continuity
UNLOCK1 ± 4Continuity
If continuity is not as specified, replace the switch.
4. Driver 's door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)±No continuity
ON (Door Lock set to
UNLOCK)3 ± 4Continuity
If continuity is not as specified, replace the switch.
5. Passenger 's door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF (Door Lock set to
LOCK)±No continuity
ON (Door Lock set to
UNLOCK)3 ± 4Continuity
If continuity is not as specified, replace the switch.

I07301
LOCK
I07302
LOCK
I14313
UNLOCKLOCK
UNLOCK LOCK
22
11
± BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE±63
2001 PRIUS (RM778U)
6. Rear left door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF±No continuity
ON1 ± 2Continuity
If continuity is not as specified, replace the switch.
7. Rear right door:
INSPECT DOOR UNLOCK DETECTION SWITCH CON-
TINUITY
Switch positionTester connectionSpecified condition
OFF±No continuity
ON3 ± 4Continuity
If continuity is not as specified, replace the switch.
8. Driver 's door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (±) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.

I14314
UNLOCKLOCK
UNLOCK LOCK
6565
I07299
LOCK
UNLOCK
UNLOCKLOCK
2
11
2 BE±64
± BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
2001 PRIUS (RM778U)
9. Passenger 's door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
5 and the negative (±) lead to terminal 6, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.
10. Rear left door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (±) lead to terminal 2, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.

I07300
LOCK
UNLOCK
UNLOCKLOCK
4
343
± BODY ELECTRICALPOWER DOOR LOCK CONTROL SYSTEM
BE±65
2001 PRIUS (RM778U)
11. Rear right door:
INSPECT DOOR LOCK MOTOR OPERATION
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (±) lead to terminal 4, and check that
the door lock link moves to UNLOCK position.
(b) Reverse the polarity and check that the door lock link
moves to LOCK position.
If operation is not as specified, replace the door lock assembly.

DI7T9±01
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
BE±67
2001 PRIUS (RM778U)
PRE±CHECK
1. OUT LINE OF THEFT DETERRENT SYSTEM
When the theft deterrent system detects any theft, it informs
people around with flashing lights and sound.
This system is designed to be upgraded by featuring an option-
al glass break sensor.
All initial setting are performed in active mode. It can be
switched to passive mode by specified operation. (See step 3.
CHANGING METHOD OF PASSIVE MODE)
HINT:
There are 4 conditions in this system which are disarmed state,
arming preparation, armed state and alarm sounding.
(1) Disarmed state
When the alarming function does not oper-
ate.
When theft deterrent function is not per-
formed.
(2) Arming preparation
Time until transferring to armed state.
Theft deterrent function is not performed.
(3) Armed state
When theft deterrent function is possible.
(4) Alarm sounding:
In this condition, once theft is detected, it is in-
formed using light and sound to people around the
vehicle.
Refer to the table for alarming method or time.
Horn
Security horn
Al i th dHeadlightAlarming methodTaillight
Hazard
Interior light
Alarming time60 seconds
Alarming outputContinuous 0.4 secs. (ON)
0.4 secs. (OFF)
HINT:
Alarming output for hazard is same as the one for the hazard
on the vehicle.
In the arming condition when either of doors is unlocked with
key not in the key cylinder, force lock signal is output.

Disarmed state
Perform any of the following and the system will go no to ºArming preparationº:

With all the doors, engine hood and luggage compartment door closed, lock all doors with the key.

With all the doors, engine hood and luggage compartment door closed, lock all doors with the
wireless remote.

With all the doors, engine hood and luggage compartment door closed, open and close any of doors,
engine hood or luggage compartment door, then close and lock all doors, engine hood and luggage
compartment door.
Arming preparation
Perform the following and the system will
go on to ºArmed stateº:

Let 30 seconds elapse with all the doors,
engine hood and luggage compartment door
closed and locked.
Perform any of the following and the system
will return to ºDisarmed stateº:

Open any of the doors, engine hood or luggage
compartment door.

Unlock any of the doors.

Put the key in the ignition.

Reconnect the battery.
Armed state
Perform any of the following and the system
will return to ºDisarmed stateº:

Unlock any of the doors or open the luggage
compartment door with the wireless remote.

Unlock the doors with the wireless remote.

Put the key in the ignition and turn it to ON.
Perform any of the following and the system
will go on to ºAlarm soundingº:

Open any of the doors.

Unlock any of the doors in any way other than
with a key or the wireless remote.

Open the luggage compartment door in any way
other than with a key.

Open the engine hood.

Reconnect the battery.

When input from optional glass break sensor is
detected (Dealer option)(Key not inserted in ignition.)
Alarm sounding
The vehicle's horn and security horn will sound,
and the hazard, interior, tail and head lights flash
for 60 seconds.
After the alarm has ended, the system will
return to ºArmed stateº. Perform any of the following and the system
will return to ºDisarmed stateº:

Unlock any of the doors or open the luggage
compartment door with the wireless remote.

Unlock the doors with the wireless remote.

Put the key in the ignition and turn it to ON.
BE±68
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
2001 PRIUS (RM778U)
2. ACTIVE ARMING MODE

± BODY ELECTRICALTHEFT DETERRENT SYSTEM
BE±69
2001 PRIUS (RM778U)
Indicator light output:
ConditionIndicator light
Disarmed stateOFF
Arming preparationON
Armed stateOFF
Alarm soundingON
HINT:
Even in disarmed state, the indicator light flash. (Due to the sig-
nal output form immobilizer system). The indicator always
flashes receiving the signal from the immobilizer system at any
time in the armed state.
Flashing frequency:
0.2 seconds (ON)
1.8 seconds (OFF)
Answer back:
The hazard lights flush as answer back under the following
conditions.
(1) When the system is set.
When arming preparation is set from disarmed state
using the wireless door lock, the hazard lights flush
once.
(2) When the system is released.
When disarmed state is set from either arming prep-
aration, armed state or alarm sounding using the
wireless door lock, the hazard lights flush twice.

Perform any of the following and the system will go to Disarmed state (B):

Remove the key from the ignition, close the driver's door, then the ignition OFF.
Disarmed state (A)
Perform any of the following and the system
will return to Disarmed state (A):

Push the unlock switch on the wireless
remote.

Put the key in the lock on the driver's or the
passenger door and turn it towards unlock.

Put the key in the ignition.

Reconnect the battery.

Turn the ignition from OFF to ON.Disarmed state (B)Perform any of the following and the system
will go to Arming preparation:

Close all the doors, hood and
luggage compartment door.
Perform any of the following
and the system
will return to Disarmed state
(B):

Open any of the doors, the
hood or the
luggage compartment door.
Arming preparation
Perform any of the following
and the system
will go to Armed state:

Allow 30 seconds to elapse
with all the doors,
hood and luggage compart-
ment door closed.
Perform any of the following and
the system
will return to Disarmed state (A):

Push the unlock switch on the
wireless
remote.

Put the key in the lock on the
driver's or the
passenger door and turn it to-
wards unlock.

Put the key in the ignition.

Reconnect the battery.

Turn the ignition from OFF to
ON.
BE±70
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
2001 PRIUS (RM778U)
3. PASSIVE ARMING MODE
This mode can be switched according to the specified op-
eration.
All initially set modes (when shipped from factory) are ac-
tive mode. (No passive mode)

Perform any of the following
and the system will return to
Armed state:

The alarm sounding
period passes.
Alarm sounding
Perform any of the following
and the system will return to
Disarmed state (A):

Push the unlock switch on
the wireless remote.

Put the key in the lock on
the driver's or the passenger
door and turn it towards
unlock.

Put the key in the ignition
and turn it ON.Perform any of the following
and the system will return to
Disarmed state (B):

Open the luggage
compartment door with the
wireless remote.

Open the luggage
compartment door with the
Key.
Perform any of the following
and the system will return to
Disarmed state (A):

Push the unlock switch on
the wireless remote.

Put the key in the lock on
the driver's or the
passenger door and turn
it towards unlock.

Put the key in the
ignition and turn it ON.
Armed state
Perform any of the following
and the system will go on to
Alarm sounding:

Open any of the doors and
allow the entry delay time
to pass.

Open the hood.

Open the luggage
compartment door with
something other than the
key or wireless remote.

Reconnect the battery.

Ignition switch is connected
directly.Perform any of the following
and the system will return to
Disarmed state (B):

Open the luggage
compartment door with the
wireless remote.

Open the luggage
compartment door with the
Key.
± BODY ELECTRICALTHEFT DETERRENT SYSTEM
BE±71
2001 PRIUS (RM778U)
