TOYOTA PRIUS 2001 Service Repair Manual

PP3AO±01
± PREPARATIONHYBRID TRANSAXLE
PP±27
2001 PRIUS (RM778U)
EQUIPMENT
Dial indicator
Pin punch
Straight edge
Torque wrench

PP3AP±01
PP±28
± PREPARATIONHYBRID TRANSAXLE
2001 PRIUS (RM778U)
LUBRICANT
ItemCapacityClassification
Hybrid transaxle oil4.6 liters (4.9 US qts, 4.0 lmp. qts)ATF Type T±IV

PP3AQ±01
± PREPARATIONHYBRID TRANSAXLE
PP±29
2001 PRIUS (RM778U)
SSM (Special Service Materials)
08826±00080Seal Packing Black or equivalent
(FIPG)
08826±00090Seal Packing 1281,
THREE BOND 1281 or equivalent
(FIPG)
08833±00070Adhesive 1324,
THREE BOND 1324 or equivalent
08833±00080Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalent

PP3A9±01
PP±30
± PREPARATIONSUSPENSION AND AXLE
91 Author: Date:
2001 PRIUS (RM778U)
SUSPENSION AND AXLE
SST (Special Service Tools)
09214±76011Crankshaft Pulley ReplacerRear axle
09240±00020Wire Gauge SetFront drive shaft
09520±00031Rear Axle Shaft Puller
(09520±00040)ShockerFront axle
Rear axle
(09521±00010)AttachmentFront axle
(09521±00020)Rod with GripFront axle
Rear axle
09520±01010Drive Shaft Remover AttachmentFront drive shaft
09520±24010Differential Side Gear Shaft
PullerFront drive shaft
(09520±32040)Shocker Set
09521±24010Drive Shaft Boot Clamping ToolFront drive shaft
09527±17011Rear Axle Shaft Bearing RemoverFront axle
09608±16042Front Hub Bearing Adjusting ToolFront drive shaft

± PREPARATIONSUSPENSION AND AXLE
PP±31
92 Author: Date:
2001 PRIUS (RM778U)
(09608±02021)Bolt & Nut
(09608±02041)Retainer
09608±32010Steering Knuckle Oil Seal
ReplacerFront axle
09628±10011Ball Joint PullerFront axle
Rear axle
09628±62011Ball Joint PullerFront axle
Front drive shaft
Front suspension
09710±40010Toe Control Link Replacer ArmRear suspension
(09711±40010)Toe Control Link Replacer
Arm No.1
(09712±40010)Toe Control Link Replacer
Arm No.2
09727±30021Coil Spring CompressorFront suspension
Rear suspension
(09727±00010)Bolt Set
(09727±00021)Arm Set
(09727±00031)Compressor
09729±22031Front Spring Upper Seat HolderFront suspension

PP±32
± PREPARATIONSUSPENSION AND AXLE
93 Author: Date:
2001 PRIUS (RM778U)
09751±36011Brake Line Union Nut 10 x 12 mm
WrenchRear suspension
09930±00010Drive Shaft Nut ChiselFront axle
Front drive shaft
09950±00020Bearing RemoverFront drive shaft
Rear axle
09950±40011Puller B SetFront axle
(09951±04020)Hanger 200
(09952±04010)Slide Arm
(09953±04020)Center Bolt 150
(09954±04010)Arm 25
(09955±04011)Claw No.1
(09957±04010)Attachment
(09958±04011)Holder
09950±60010Replacer SetFront axle
(09951±00370)Replacer 37

± PREPARATIONSUSPENSION AND AXLE
PP±33
94 Author: Date:
2001 PRIUS (RM778U)
(09951±00550)Replacer 55
(09951±00650)Replacer 65
09950±60020Replacer Set No.2Front axle
(09951±00730)Replacer 73
09950±70010Handle SetFront axle
(09951±07150)Handle 150

PP3A0±01
PP±34
± PREPARATIONSUSPENSION AND AXLE
2001 PRIUS (RM778U)
RECOMMENDED TOOLS
09025±00010Torque Wrench (30 kgf±cm)
09042±00010Torx Socket T30 .
09905±00012Snap Ring No.1 Expander .
09905±00013Snap Ring Pliers .

PP0AM±01
± PREPARATIONSUSPENSION AND AXLE
PP±35
2001 PRIUS (RM778U)
EQUIPMENT
Dial indicator with magnetic base
Drill
Torque wrench

PP26B±05
PP±36
± PREPARATIONSUSPENSION AND AXLE
2001 PRIUS (RM778U)
LUBRICANT
ItemCapacityApplication
Front drive shaft
Inboard joint grease
Color=Yellow ocher
Outboard joint grease
Color=Yellow ocher
180 ± 190 g (6.3 ± 6.7 oz.)
110 ± 120 g (3.9 ± 4.2 oz.)
