TOYOTA PRIUS 2003 1.G Navigation Manual

241. Push the
“MENU” switch to display
the Menu screen.
1UE040
2. Touch the “Edit route” switch.
1UE041
3. Touch the “Add” switch of Destina-
tion. 4. Input an additional destination in the
same way as the destination input.
(See page 22.)
1UE042
5. The Add destination screen appears.Touch the “Add” switch that you
want to add a destination. 1. Push the
“MENU” switch to display
the Menu screen and touch the “Edit
route” switch.
1UE041
2. Touch the “Reorder” switch of Des-
tination.
(b) Adding destinations(c) Reordering destinations

25
1UE043
3. Select the destinations in the order ofarrival by touching the
switch.
After you finished selecting the destinations,
touch the
“OK” switch. The previous
screen returns.
1UE041
1. Touch the “Delete” switch of Des-
tination.
1UE044
2. Touch the switch of destination
where you want to delete. Touch the
“Delete all” switch if you want to de-
lete all destinations.
3. The message appears to confirm your request to delete. To delete the
point(s), touch the
“Yes” switch.
If you touch the
“Yes” switch, the data can-
not be recovered.
If you touch the
“No” switch. The previous
screen will return.
(d) Deleting destination

26
(a) Adding a preferred road
1UE040
Touch the “Edit route” switch on the
Menu screen.
1UE041
Touch the “Add” switch of Set preferred
road. The following screen appears.
1UE045
Move the cursor to your desired loca-
tion and touch the
“Preferred road”
switch.
Messages appear to confirm your request on
the screen. Touch the
“Enter” switch to
register the road. Touch the
“Next” switch when you
change the road.
1UE046
The Add preferred road screen appears.
Touch the
“Add” switch where you want
to add a preferred road.
Setting and deleting preferred
r
oad

27
1UE041
Touch the “Modify” switch of Set pre-
ferred road. The modify preferred road
screen appears.
1UE047
Select the preferred road which you want
to modify and touch the
switch.
1UE048
Do the same procedure as adding a pre-
ferred road (see page 26). 1. Touch
the
“Delete” switch of Set pre-
ferred road. The Delete preferred road
screen appears.
1UE049
2. Select the preferred road which you want to delete. Touch the “Delete
all” switch if you want to delete all
preferred roads.
3. Messages appear to confirm your re- quest to delete the preferred road. To
delete the point(s), touch the
“Yes”switch.
If you touch the
“Yes” switch, the data can-
not be recovered.
If you want to try again or cancel deletion,
touch the
“No” switch. The previous
screen will return.
(b) Modifying a preferred road(c) Deleting a preferred road

28The route guidance system displays two
different screen modes.
1UE050a
Single map: Map is shown in a screen.
1UE051a
Dual
map: Two different maps are shown in
a screen.
1UE052a
Split screen: Map and guidance screen are
shown in a screen mode. (For detail about
Guidance screen, see page 45.)
The two route guidance screens have a
number of indicators and switches with
which you should be familiar.
Map/guidance:
To change the screen mode.
Upon reception of signals from
the GPS (Global Positioning
System), this mark appears.
(For details, see page 49.)
These switches magnify or re-
duce the map scale. (For de-
tails, see page 47.)
Touch this switch, and sym-
bols of points of interest are
shown on the screen. (For de-
tails, see page 43.)
Touch this switch for one −touch
registration of the marked point.
(For details, see page 71.)
Route guidance screen

29
INFORMATION
The distance to your destination ap-
pears on the left of the screen.
 The time to your destination can also
be displayed. (For the setting steps,
see page 82.)
The Change route screen
appears and the following
settings are available.
1UE053
Search condition: To change the condition
for Reroute.
Detour: To change the condition for Detour.
(For details, see page 42.)
Del. next dest.: To delete and skip the next
destination.
INFORMATION
If the calculated route includes a trip by
ferry, the route guidance shows a sea
route. After you travel by ferry, the cur-
rent vehicle position may be incorrect.
Upon reception of GPS signals, it is au-
tomatically corrected.

30Push
the
“MENU” switch to display the
Menu screen and touch the
“Edit
route”
switch.
1UE041
Touch the “Search Condition”
switch. The search condition screen ap-
pears.
1UE041
Touch the “Quick” or “Short” switch
and then the
“OK” switch.
1UE055
Search condition

31
Route overview
1UE040
Touch the “Route overview” switch
on the Menu screen.
1UE056
The entire route from the starting point to the
destination is displayed. You can change from the Map screen to a
Turn list screen that displays the list of
the roads up to your destination. This list
can be used for a route guidance.
1UE040
1. Push the “MENU” switch to display
the “Menu” screen and touch the
“Route overview” switch.
1UE076
2. The screen will change to the Entire route map screen where you can touch
the
“Turn list” switch.
Tu r n l i s t

32
1UE077
You can scroll through the list of roads by
touching
or switch. However,
not all road names in the route may appear
on the list. If a road changes its name without
requiring a turn (such as on a street that runs
through two or more cities), the name
change will not appear on the list. The street
name closest to the starting point will be dis-
played with the distance to the next turn.
These marks indicate the di-
rection which you should turn
at an intersection. Touch
the
“Map” switch of your desired
point. The point which you choose is dis-
played on the Map screen.
1UE078
INFORMATION
 The current vehicle position mark
appears at the bottom of the screen
next to the name of the street you are
driving on. The mark does not move.
 If you leave the guidance route, the
name of the street you are on is not
shown on the list next to the current
vehicle position mark.
 If the road type you are on changes
between a highway, a main street or
a residential street (at an inter-
change or fork), it will appear on the
turn list.
 If a long route has been selected, it
may take a long time to display the
turn list.
 Push the
“MAP” switch to return to
the map display with a route guid-
ance.

33
Touch the
“Route preview”. The
route preview screen appears.
1UE057
To indicate the next destination
or selected POI
To preview the route to the next
destination or selected POI
To preview the route to the next
destination in fast− forward
mode
To stop the preview
To review the route to the cur-
rent position
To review the route to the cur-
rent position in fast− forward mo-
de
To indicate the current position
1UE058
Touch the “Edit” switch, the Edit route
preview screen appears.
To next POI: Preview the Next POI
To next
: Preview the Next destination
Delete: To delete the POI icon.
Select POI: To select the POI icon.
Touch the
“OK” switch after the selection.
Route Preview
