TOYOTA PRIUS 2009 2.G Navigation Manual

1
Introduction
Thank you for your purchase of the Navigation System. Please read
this manual carefully to ensure proper use. Keep this manual in your
vehicle at all times.
The Navigation System is one of the most technologically advanced
vehicle accessories ever developed. The system receives satellite sig-
nals from the Global Positioning System (GPS) operated by the U.S.
Department of Defense. Using these signals and other vehicle sen-
sors, the system indicates your present position and assists in locating
a desired destination.
The navigation system is designed to select efficient routes from your
present starting location to your destination. The system is also designed
to direct you to a destination that is unfamiliar to you in an ef ficient manner.
The system uses DENSO maps. The calculated routes may not be the
shortest nor the least traffic congested. Your own personal local knowl-
edge or “short cut” may at times be faster than the calculated rou\
tes.
The navigation system’s database includes about 75 Point of Interest
categories to allow you to easily select destinations such as restaurant\
s
and banks. If a destination is not in the database, you can enter the stre\
et
address or a major intersection close to it and the system will guide yo\
u
there.
The system will provide both a visual map and audio instructions. The au-
dio instructions will announce the distance remaining and the direction to
turn in approaching an intersection. These voice instructions will help you
keep your eyes on the road and are timed to provide enough time to allow
you to maneuver, change lanes or slow down.
08/06/25 Prius_Navi_U
OM47615U

2
Please be aware that all current vehicle navigation systems have
certain limitations that may affect their ability to perform properly.
The accuracy of the vehicle’s position depends on the satellite con-
dition, road configuration, vehicle condition or other circumstan-
ces. For more information on the limitations of the system, refer to
pages 132 through 133.
08/06/25 Prius_Navi_U
OM47615U

3
For safety reasons, this manual indicates
items requiring particular attention with the
following marks.
CAUTION
This is a warning against anything
which may cause injury to people if
the warning is ignored. You are in-
formed about what you must or must
not do in order to reduce the risk of
injury to yourself and others.
NOTICE
This is a warning against anything
which may cause damage to the ve-
hicle or its equipment if the warning
is ignored. You are informed about
what you must or must not do in or-
der to avoid or reduce the risk of dam-
age to your vehicle and its equip-
ment.
INFORMATION
This provides additional information.
Safety Instruction
To use this system in the safest possible
manner, follow all the safety tips shown be-
low.
This system is intended to assist in reach-
ing the destination and, if used properly,
can do so. The driver is solely responsible
for the safe operation of your vehicle and
the safety of your passengers.
Do not use any feature of this system to the
extent it becomes a distraction and pre-
vents safe driving. The first priority while
driving should always be the safe opera-
tion of the vehicle. While driving, be sure
to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly famil-
iar with it. Read the entire Navigation Sys-
tem Owner’s Manual to make sure you un-
derstand the system. Do not allow other
people to use this system until they have
read and understood the instructions in
this manual.
For your safety, some functions may be-
come inoperable when driving. Unavail-
able touch −screen buttons are dimmed.
Only when the vehicle is not moving, can
the destination be set and route be se-
lected.
08/06/25 Prius_Navi_U
OM47615U
Important information about
this manual

4
CAUTION
For safety, the driver should not
operate the navigation system
while he/she is driving.
Insufficient attention to the road
and traffic may cause an accident.
 While driving, be sure to obey the
traffic regulations and maintain
awareness of the road conditions.
If a traffic sign on the road has
been changed, route guidance
may provide incorrect information
such as the direction of a one way
street.
While driving, listen to the voice instruc-
tions as much as possible and glance at
the screen briefly and only when it is safe.
However, do not totally rely on voice guid-
ance. Use it just for reference. If the sys-
tem cannot determine the current vehicle
position correctly, there is a possibility of
incorrect, late, or non −voice guidance.
The data in the system may occasionally
be incomplete. Road conditions, including
driving restrictions (no left turns, street clo-
sures, etc.) frequently change. Therefore,
before following any instruction from the
system, look to see whether the instruction
can be done safely and legally.
This system cannot warn about such
things as the safety of an area, condition of
streets, and availability of emergency ser-
vices. If unsure about the safety of an
area, do not drive into it. Under no cir-
cumstances is this system a substitute
for the driver’s personal judgement.
Use this system only in locations where it
is legal to do so. Some states/provinces
may have laws prohibiting the use of video
and navigation screens next to the driver.
08/06/25 Prius_Navi_U
OM47615U

5
Table of Contents
Quick guide —
— Overview buttons and guidance screen 8. . . . . . . .
— Registering home 10 . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Registering preset memory point (Quick access) 12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
— Operation flow: guiding the route 14 . . . . . . . . . . . . .
— Setting home as the destination 15 . . . . . . . . . . . . . .
Navigation system function index 16 . . . . . . . . . . . . . . .
1 Basic Functions
〈 Basic information before operation 〉
Initial screen 20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
Touch screen operation 21 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Inputting letters and numbers/List screen operation 22 . . . . . . . . . . . . .
Function help 25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Map screen operation 26
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Current position display 26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Screen scroll operation 26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Switching the screens 30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Map scale 32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Foot print map 33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Orientation of the map 34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
08/06/25 Prius_Navi_U
OM47615U
Quick
Guide

6
2 Destination Search
Quick reference (“Destination” screen)36
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search 37
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Selecting the search area 38
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Home 40
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by Quick access 40
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Address” 41
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI* Name” 44
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “POI* Category” 47
. . . . . . . . . . . . . . . . . . . . .
Destination search by “Emergency” 50
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Memory” 51
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Previous” 51
. . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Map” 52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Intersection” 52
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Freeway Ent./Exit” 53
. . . . . . . . . . . . . . . . . . .
Destination search by “Coordinates” 54
. . . . . . . . . . . . . . . . . . . . . . . .
Destination search by “Phone #” 55
. . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting route guidance 55
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
3 Route Guidance
Route guidance screen 60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Typical voice guidance prompts 63
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Distance and time to destination 65
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setting and deleting destination 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding destinations 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Reordering destinations 66
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting destinations 67
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Setting route 68
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Search condition 68
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Detour setting 69
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Route preference 71
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Starting route from adjacent road 71
. . . . . . . . . . . . . . . . . . . . . . . . . .
Map view 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Display POI* icons 72
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Route overview 74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Route preview 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Route trace 76
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
*: Point of Interest
08/06/25 Prius_Navi_U
OM47615U

7
4 Advanced Functions
〈Descriptions of functions for more effective use 〉
Quick reference (“Menu” screen) 80
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Quick reference (“Setup” screen) 81
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspending and resuming guidance 82
. . . . . . . . . . . . . . . . . . . . . . . . . .
Volume 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
User selection 84
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
My places 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
Registering memory points 88
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing memory points 89
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting memory points 93
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Registering home 94
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Deleting home 95
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . .
Registering area to avoid 95
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing area to avoid 96
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Deleting area to avoid 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting previous points 99
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup 100
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . .
5 Other Functions
Maintenance information 11 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance information setting 112 . . . . . . . . . . . . . . . . . . . . . . . . . .
Dealer setting 114 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
Calendar with memo 11 6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
Adding a memo 118 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Editing a memo 119 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
Memo list 119 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . .
Speech command system 121 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Help screen 124 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Screen adjustment 125
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Screen setting 126
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . .
Beep setting 129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Selecting a language 129
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
6 Appendix
Limitations of the navigation system 132
. . . . . . . . . . . . . . . . . . . . . . . . .
Map database information and updates 134
. . . . . . . . . . . . . . . . . . . . . .
Index145
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . . . . . . . . .
08/06/25 Prius_Navi_U
OM47615U

8
0UPS01
No.NameFunctionPage
1
Northup or
headingup
symbolThis symbol indicates a map view with
north−up or heading−up. Touching this
symbol changes the map orientation.
34
2Scale indicatorThis figure indicates the map scale.32
3“MENU” buttonPush this button to display the “Menu”
screen.10, 12, 80, 82,
83, 84, 87, 100, 143
4“DEST” buttonPush this button to display the “Destina-
tion” screen.14, 15, 36, 37
5“MAP/VOICE”
buttonPush this button to repeat a voice guid-
ance, cancel one touch scroll, start
guidance, and display the current posi-
tion.
26, 64
08/06/25 Prius_Navi_U
OM47615U
Quick
guide —
— Overview buttons and guidance screen

9
No.NameFunctionPage
6
Zoom out
touchscreen
buttonTouch this button to reduce the map
scale.32
7“Mark”
Touch this button to register the current
position or the cursor position as a
memory point.
27
8“Route”Touch this button to change the route.66, 68
9“Map View”
Touch this button to browse information
about guidance route, to set the Points
of Interest to be displayed on the
screen, or to record the route.
72, 74, 75, 76
10“ OFF”
Touch this button to obtain a broader
view. Some of the buttons on the screen
are not displayed. They are displayed
again by touching “ON”.
103
11
Zoom in
touchscreen
buttonTouch this button to magnify the map
scale.32
12
Foot print map
touchscreen
buttonTouch this button to display the foot print
map and the building information.33
13
Screen
configuration
touchscreen
button
Touch this button to change the screen
mode.30
14Distance and time
to destinationDisplays the distance, the estimated
travel time to the destination, and the
estimated arrival time at the destination.
65
15“INFO” buttonPush this button to display the “Informa-
tion” screen.11 2 , 11 6 , 1 2 6 ,
129
16“DISPLAY”
buttonPush this button to display the “Display”
screen.125
17
“GPS” mark
(Global
Positioning
System)Whenever the vehicle is receiving sig-
nals from the GPS, this mark is dis-
played.
132
18
Speech
command system
indicatorThe microphone is shown by pushing
the speech command switch. The
speech command system can be oper-
ated while this indicator is shown.
121
08/06/25 Prius_Navi_U
OM47615U

10
1Push “MENU” button.
2Touch “My Places”.
3Touch “Register” of the home.
4There are 12 different methods to
search your home.
See “Destination search” on page 37.
08/06/25 Prius_Navi_U
OM47615U
— Registering home
