TOYOTA PRIUS 2009 2.G Navigation Manual

SECTION 4
ADVANCED FUNCTIONS
79
ADVANCED FUNCTIONS

\f  \b \b\f  \b


 \b\b\f
Quick reference (“Menu” screen) 80 . . . . . . . . . . . . . . . . . . . . . . . . .
 Quick reference (“Setup” screen) 81 . . . . . . . . . . . . . . . . . . . . . . . . .
 Suspending and resuming guidance 82 . . . . . . . . . . . . . . . . . . . . . .
 Volume 83 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . .
 User selection 84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . .
 My places 87
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . .
Registering memory points 88 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing memory points 89 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting memory points 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Registering home 94 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\

Deleting home 95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. .
Registering area to avoid 95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Editing area to avoid 96 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting area to avoid 99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Deleting previous points 99 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 Setup 100 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . . . . . . . . . . .
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
80
The “Menu” screen allows effective use of the navigation system. To display the “Menu”
screen, push the “MENU” button.
0U5041
1“Suspend Guidance” and “Re-
sume Guidance”
Suspends or resumes guidance. 82 . . . .
2“Volume”
Sets the volume for voice guidance. 83
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3“?”
Function help for the “Menu” screen can be
viewed on this screen. 25 . . . . . . . . . . . .
4“Map DVD”
Displays information regarding the disc
version or covered area. 134 . . . . . . . . . .
5“Select User”
Up to 3 different settings for dif ferent users
can be memorized. 84 . . . . . . . . . . . . . . .
6“Setup”
Enables various settings for the navigation
system. 81, 100 . . . . . . . . . . . . . . . . . . . . .
7“My Places”
Enables changes to “Memory points”,
“Home” and “Areas to avoid”. Enables
deletion of the previous point. 87 . . . . . .
08/06/25 Prius_Navi_U
OM47615U
Quick reference (“Menu” screen)

ADVANCED FUNCTIONS
81
The items shown on the “Setup” screen can be set. To display the “Setup” screen, push
the “MENU” button and touch “Setup” .
0U5042
1“Distance”
The distance units “km” or “miles” can be
selected. 100 . . . . . . . . . . . . . . . . . . . . . . .
2“Estimated Travel Time”
The system to display the travel time and
the arrival time to the destination on the
route guidance screen can be set. 101 .
3“Keyboard Layout”
Key layout can be changed. 102 . . . . . . .
4“Time Zone”
The desired time zone can be selected. 102
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5“ Function”
The choice whether to display each touch −
screen button and current street name on
the map screen can be set. 103 . . . . . . .
6“Display POI Icons”
A selection of 6 icons displayed on the
“Display POI Icons” top screen is possible.
103
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7“Display Building Shapes”
Selection of either “ON” or “OFF” to dis-
play the building shape on the map screen
is possible. 104 . . . . . . . . . . . . . . . . . . . . .
8“Traffic Restrict. Notification”
Notification of seasonal restrictions can be
selected. 105
. . . . . . . . . . . . . . . . . . . . . . .
9“Voice Recognition Guidance”
Voice recognition guidance can be set. 105
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10“Voice Guidance in All Modes”
Voice guidance can be set in all modes. 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
08/06/25 Prius_Navi_U
OM47615U
Quick reference (“Setup” screen)

ADVANCED FUNCTIONS
82
11“Auto Voice Guidance”
Automatic voice guidance can be set. 106
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12“Popup Message”
Selection of either “ON” or “OFF” to dis-
play the pop −up message is possible.
107
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13“Calibration”
Adjustment of the current vehicle position
mark can be done manually. 108 . . . . . .
14“Default”
This touch−screen button initializes all of
the settings. 100
. . . . . . . . . . . . . . . . . . . .
15“?”
Function help for the “Setup” screen can
be viewed. 25 . . . . . . . . . . . . . . . . . . . . . .
To suspend guidance
1. Push the “MENU” button.
4U5550T
2. Touch “Suspend Guidance”.
INFORMATION
Without route guidance, “Suspend
Guidance” cannot be used.
The screen will return to the current posi-
tion map without route guidance.
08/06/25 Prius_Navi_U
OM47615U
Suspending and resuming
guidance

ADVANCED FUNCTIONS
83

To resume guidance
1. Push the “MENU” button.
4U5551T
2. Touch “Resume Guidance”.
The screen will change to the current posi-
tion map with route guidance.
Volume
The voice guidance volume can be ad-
justed or switched off.
1. Push the “MENU” button.
4U5552T
2. Touch “Volume”.
To adjust the volume, select the desired
level by touching the appropriate number.
If voice guidance is not needed, touch
“OFF” to disable the feature.
When selected the number or “OFF” will
be highlighted.
3. Touch “OK” to confirm your selec-
tion.
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
84
INFORMATION
During route guidance, the voice
guidance continues even if the navi-
gation screen is changed to other
screens.
“Adaptive Volume Control”: By turning
“Adaptive V olume Control” on, the volume
is turned up automatically when the ve-
hicle speed exceeds 50 mph (80 km/h).
To turn the “Adaptive Volume Control”
system on, touch the button. The indicator
will be highlighted.
User selection
The system can memorize the following
settings for up to three users.
Map direction
Map scale
Map configuration
Guidance mode
Setup
Volume
Language
Route trace
Travel time/arrival time
Right screen of dual map
Road preference
Maintenance notification
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
85
1. Push the “MENU” button.
4U5553T
2. Touch “Select User”.
To register
1. Touch “Memorize”.
The confirmation screen will be displayed.
2. To register, touch “Yes”. To return to
the previous screen, touch “No” or
.
When a button that is already registered is
touched, the following screen appears.
To replace, touch “Yes” . To cancel the re-
placement, touch “No” or
.
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
86

To change user
Touch “User number”.
The above message appears, then the
map screen will be displayed.
To delete user
1. Touch “Delete”.
The confirmation screen will be displayed.
2. To delete, touch “Yes”. To return to
the previous screen, touch “No” or
.
08/06/25
Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
87
My places —
Points or areas on the map can be regis-
tered.
The registered points can be used on the
“Destination” screen. (See “ — Destination
search by Home” on page 40, “ — Destina-
tion search by Quick access” on page 40
and “ — Destination search by Memory” on
page 51.)
Registered areas are avoided at the time of
route search.
1. Push the “MENU” button.
4U5554T
2. Touch “My Places”.
On this screen, the following operations
can be performed.
1Registers memory points
(See “ — Registering memory points”
on page 88.)
2Edits memory points
(See “ — Editing memory points” on
page 89.)
3Deletes memory points
(See “ — Deleting memory points” on
page 93.)
4Registers or deletes home
(See “ — Registering home” on page
94 or “ — Deleting home” on page 95.)
5Registers areas to avoid
(See “ — Registering area to avoid”
on page 95.)
6Edits areas to avoid
(See “ — Editing area to avoid” on
page 96.)
7Deletes areas to avoid
(See “ — Deleting area to avoid” on
page 99.)
8Deletes previous points
(See “ — Del eting previous points” on
page 99.)
9Number of remaining memory
points
10Number of remaining areas to
avoid
08/06/25 Prius_Navi_U
OM47615U

ADVANCED FUNCTIONS
88
1. Push the “MENU” button.
2. Touch “My Places” on the “Menu”
screen.
3. Touch “Register”.
4. Enter the location in the same way
as for a destination search. (See “Des-
tination search” on page 37.)
After memory point registration is com-
pleted, the “Memory Point” screen will be
displayed.
5. Touch “OK”.
To edit registered information, see “ —
Editing memory Points” on page 89.
INFORMATION
Up to 106 memory points can be reg-
istered.
08/06/25 Prius_Navi_U
OM47615U
— Registering memory
points
