display TOYOTA PRIUS 2020 Accessories, Audio & Navigation (in English)

1486-3. What to do if...
Phonebook data cannot be edited.
■When using the Bluetooth®
message function
Messages cannot be viewed.
New message notifications are
not displayed.
Likely causeSolution
The profile ver-
sion of the con-
nected cellular
phone may not
be compatible
with transferring
phonebook data.
For a list of spe-
cific devices
which operation
has been con-
firmed on this
system, check
with your Toyota
dealer or the fol-
lowing website:
https://www.
toyotapr.com/
audio-multimedia
in the United
States,
https://www.
toyota.ca/
connected in
Canada, and
http://www.
toyotapr.com/
audio-multimedia
in Puerto Rico
Automatic con-
tact transfer
function on this
system is set to
off.Set automatic
contact transfer
function on this
system to on.
(  P.139)
Passcode has
not been entered
on the cellular
phone.
Enter the pass-
code on the cel-
lular phone if
requested
(default pass-
code: 1234).
Transfer opera-
tion on the cellu-
lar phone has
not completed.
Complete trans-
fer operation on
the cellular
phone (approve
transfer opera-
tion on the
phone).
Likely causeSolution
Automatic con-
tact transfer
function on this
system is set to
on.Set automatic
contact transfer
function on this
system to off.
( P.139)
Likely causeSolution
Message trans-
f e r i s n o t e n a b l e d
on the cellular
phone.
Enable mes-
sage transfer on
the cellular
phone (approve
message trans-
fer on the
phone).
Automatic trans-
fer function on
this system is set
to off.Set automatic
transfer function
on this system to
on. ( P.139)
Likely causeSolution
Notification of
SMS/MMS/E-
mail reception on
this system is set
to off.Set notification
of SMS/MMS/E-
mail reception on
this system to
on. ( P.137)
Automatic mes-
sage transfer
function is not
enabled on the
cellular phone.Enable auto-
matic transfer
function on the
cellular phone.

1496-3. What to do if...
6
Phone
■In other situations
The Bluetooth
® connection sta-
tus is displayed at the top of the
screen each time the power
switch is in ACCESSORY or ON
mode.
Even though all conceivable
measures have been taken, the
symptom status does not
change.
●For details, refer to the owner’s
manual that came with the cellular
phone.
Likely causeSolution
Connection con-
firmation display
on this system is
set to on.
To turn off the
display, set con-
nection confir-
mation display
on this system to
off. ( P. 3 5 )
Likely causeSolution
The cellular
phone is not
close enough to
this system.Bring the cellu-
lar phone closer
to this system.
Radio interfer-
ence has
occurred.
Turn off Wi-Fi®
devices or other
devices that may
emit radio
waves.
The cellular
phone is the
most likely cause
of the symptom.
Turn the cellular
phone off,
remove and rein-
stall the battery
pack, and then
restart the cellu-
lar phone.
Enable the cellu-
lar phone’s Blue-
tooth
®
connection.
Disable the
Wi-Fi
® connec-
tion of the cellu-
lar phone.
Stop the cellular
phone’s security
software and
close all applica-
tions.
Before using an
application
installed on the
cellular phone,
carefully check
its source and
how its opera-
tion might affect
this system.
Likely causeSolution

1537-1. Connected Services overview
7
Connected Services
Content provider
Provides contents to the application server.
Application server
Type A: Function achieved by using a smar tphone
or DCM
Of the functions included with connected services, the Toyota
apps rely on the use of a smartphone or DCM.
Using a smartphone
• Toyota audio multimedia system enables applicable apps installed on a smartphone to be displayed on and operated from
the screen via Bluetooth
®.
 Via DCM
• Toyota audio multimedia system enables applicable apps installed on the system to be displayed on and operated from th e
screen.
A few settings must be performed before Toyota apps can be
used. ( P.155)
By using a smartphone or DCM
A
B

1547-1. Connected Services overview
Provides applications to the system or a smartphone.
Smartphone
*
Using the Toyota mobile application, communication is relayed
between the system, application server and contents provider.
Applications
Display usable content from the content providers on the screen
using the data connection of the connected smartphone or DCM.
System
Content received, via a smartphone or DCM, from content pro-
vider servers is displayed on the screen. The system is equippe d
with an application player to run applications.
Via DCM
*: For known compatible phones, refer to https://ww w.toyota.com/
connected-services in the United States, https://www.toyota.ca/connected
in Canada, and http://www.toyo tapr.com/connected-services
in Puerto
Rico.
The required operations to acti-
vate applications and connect a
smartphone to the system, and
the registration steps for the
connected services are
explained in this section.
■Subscription
 Toyota apps do not require an
activation fee or monthly
recurring fees.
 Services requiring a separate
contract can also be used.
*
*: For details, refer to
https://www.toyota.com/
connected-services or call 1-800-
331-4331 in the United States,
https://www.toyota.ca/connected

or call 1-888-869-6828 in Can-
ada, and http://www.
toyotapr.com/connected-services
or call 1-877-855-8377 in Puerto
Rico.
■Availability of function
 Toyota apps is available in the
contiguous United States,
Washington D.C., Alaska,
Hawaii, the United States Vir-
gin Islands, Puerto Rico and
Canada.
●Data usage fees may apply while
using Toyota apps. Confirm data
usage fees before using this func-
tion.
●For details regarding operation of
the Toyota apps, refer to
https://www.toyota.com/
connected-services in the United
States, https://www.toyota.ca/
connected in Canada, and
http://www.toyotapr.com/
connected-services in Puerto
Rico.
C
D
E
F
Before using the function

1597-2. Connected Services operation
7
Connected Services
7-2.Connected Services operation
From the “MENU” button
1 Press the “MENU” button.
2 Select “Apps”. 3
Follow the steps in “From the
“APPS” button” from step 3.
( P.159)
From the “APPS” button
1 Press the “APPS” button.
2 Select “Apps”.
 If a specific application screen
is displayed, select “Apps”
again.
3 Select the desired application
screen button.
: Select to activate an applica-
tion.
“Update”: Select to update the
applications. ( P.159)
“App Catalog”: Select to change the
order of the applications. ( P.160)
: Displays the number of new
notifications for the application
When the Toyota apps are acti-
vated, an application may need
to be updated. To update an
application, it is necessary to
download update data and
install it.
■Downloading update
If an update is available,
Toyota Apps
Toyota apps is a function
that enables certain apps
installed on a smartphone
or the system to be dis-
played on and operated
from the system screen.
Before the Toyota apps can
be used, some setup needs
to be performed. ( P.155)
For details about the func-
tions and services provided
by each application, refer to
https://www.toyota.com/
connected-services in the
United States,
https://www.toyota.ca/
connected in Canada, and
http://www.toyotapr.com/
connected-services in
Puerto Rico.
Using Toyota Apps
Updating an application

1607-2. Connected Services operation
“Update” can be selected.
1Select “Update” on the appli-
cation screen. ( P.159)
2 Check that downloading
starts.
“Download in Background”: Select
to operate other functions while
downloading.
“Cancel”: Select to cancel updating.
3Check that downloading is
complete.
“Later”: Select to install later. When
this screen button is selected, the
screen will re turn to the last dis-
played screen. To install the update
data: ( P.160)
“See Detail”: Select to display
detailed information on the update
data.
“Install”: Select to install the update
data. Follow the steps “Installing
the update data” from step 2.
(  P.160)
■Installing the update data
After the downloading is com-
plete, “Update” will be changed
to “Install”.
1 Select “Install” on the appli-
cation screen. ( P.159)
2 Select “Continue”.
“Later”: Select to postpone the
installation of the update data and
go back to the previous screen.
3Check that installing is
started.
“Install in Background”: Select to
operate other functions while
installing.
4Select “OK” after the install-
ing is complete.
●The Toyota apps cannot be oper-
ated while installing.
Order of the applications can be
changed.
1Display the application
screen. ( P.159)
2 Select “App Catalog”.
3 Select the desired application
to be moved.
4 Select “<<” or “>>” to move
the application, and then
select the done button.
When problems occur with start-
ing the application player, a
message will appear on the
screen. Referring to the follow-
ing items, identify the problem
and take the suggested correc-
tive action.
 “When it is safe and legal to
do so, please ensure your
Toyota mobile application is
running and logged in on your
phone.”
The Toyota mobile application can-
not be connected to Bluetooth
®
SPP.
Refer to
https://www.toyota.com/
connectedservices in the United
States, https://www.toyota.ca/
Reordering the applica-
tions
If a message appears on
the screen

1627-2. Connected Services operation
https://www.toyota.com/
connected-services in the
United States, https://www.
toyota.ca/connected in Canada,
and http://www.toyotapr.com/
connected-services in Puerto
Rico.
 The keyboard layout can be
changed. ( P. 4 6 )
1 Display the application
screen. ( P.159)
2 Select the desired application
screen button.
3 Select the character entering
space.
4 Enter a search term, and
then select “OK”.
5 Entering characters will be
reflected on the character
entering space.
 For details on operating the
keyboard:  P. 2 0
1 Display the application
screen. ( P.159)
2 Select the desired application
screen button.
3 Press the talk switch.
( P.100)
4 Say the desired keyword. 
Completion of the keyword
will be detected automatically.
5 Search results will be dis-
played on the screen.
Entering a keyword using
the software keyboard
Entering a keyword using
the voice recognition func-
tion

1637-3. Setup
7
Connected Services
7-3.Setup
1Press the “MENU” button.
2 Select “Setup”.
3 Select “Toyota Apps”.
4 Select the desired items to
be set.
Select to set the pop up
reminder for smartphone
data usage. ( P.163)
Select to detect if an iPhone
app is automatically turned on/off.
Select to turn on/off the
enhanced USB connection
mode
• When an iPhone is connected
while this setting is set to “On”,
communication with devices con-
nected to other USB ports may
not be possible. Also, depending
on the device, charging may not
be possible.
Select to configure the Apps
menu layout (e.g. app order,
which applications are acti-
vated, etc.). This updates a
setting file stored on the Toy-
ota response center, this set-
tings file can also be updated
from the system, smartphone
app and by web portal.
Select to install the Apps via
a USB memory device. For
details, contact your Toyota
dealer.
Select to reset all setup items
to default setting.
The data usage notification pop-
up, which indicates that the sys-
tem will use an internet connec-
tion, can be enabled/disabled.
1 Display the Toyota apps set-
tings screen. ( P.163)
2 Select “Data Usage Mes-
sage”.
Toyota Apps settings
Toyota apps settings can be
changed.
Displaying the Toyota
Apps settings screen
Toyota Apps settings
screen
A
B
'DWDXVDJHQRWLILFDWLRQ
SRSXSVHWWLQJV
C
D
E
F

166Alphabetical Index
Alphabetical Index
A
AM/FM/SiriusXM (SXM) radio .. 61
Available HD Radio™ technol- ogy ....................................... 65
Caching a radio program........ 62
Displaying the radio ID ........... 67
HOW TO SUBSCRIBE TO Siri- usXM Radio Services ........... 66
Overview ................................ 61
Presetting a station ................ 62
Radio broadcast data system. 64
Radio options ......................... 63
Refer to the table below to iden- tify the problem and take the
suggested corrective action . 68
Selecting a station from the list ............................................. 63
Smart favorites ....................... 68
Troubleshooting guide ............ 65
Using HD Radio™ technology 64
“Apple CarPlay” button (“Menu” screen) .............................. 10, 41
Apple CarPlay™ ....................... 41 Establishing an Apple CarPlay connection ............................ 41
Troubleshooting...................... 43
“Apps” button (“Menu” screen) ......................................... 10, 159
“APPS” button ........ ............8, 159
Audio/visual remote controls .. 82
“Audio” button (“Menu” screen) ........................................... 10, 54
“Audio” button (“Setup” screen) ........................................... 13, 84
“AUDIO” button .............. 8, 54, 56
Audio settings .......................... 84 Audio settings screen ............. 84
Displaying the audio settings screen .................................. 84
AUX ............................................ 80 Overview ................................ 80
B
Basic function .............................8
Basic information before opera-tion ...........................................16
Basic operation.........................54
Bluetooth
® audio ......................77
Overview ................................77
Registering/Connecting a Blue-
tooth
® device ........................79
Bluetooth
® phone message func-
tion .........................................131 Calling the message sender .134
Checking received messages ...........................................132
Displaying the message screen
...........................................131
Receiving a mess age ...........132
Replying to a message (dicta- tion reply)............................133
Replying to a message (quick reply) ..................................134
“Bluetooth” button (“Setup” screen) ...............................13, 29
Buttons overview........................8 Operations of each part ............8
C
CD ..............................................70Overview ................................70
Command list ..........................103 Command list overview ........103
Connected Services operation ...............................................159
Connected Services overview ...............................................152
Connectivity settings ...............25

Alphabetical Index167
D
“Display” button (“Menu” screen) .............................. 10, 23
E
“ECO” button (“Information” screen) .................................... 14
Eject button .......................... 8, 57
Entering letters and numbers/list screen operation .................... 20Entering letters and numbers . 20
List screen .............................. 21
F
Functional overview ............... 152
G
“General” button (“Setup”
screen) .............................. 13, 46
General settings ....................... 46 Displaying the general settings screen .................................. 46
General settings screen ......... 46
H
“HOME” button ..................... 8, 19
Home screen ............................. 19 Home screen operation .......... 19
I
“Info” button (“ Menu” screen)10,
14
“Information” screen ............... 14
Initial screen ............................. 16 Caution screen ....................... 16
Restarting the system ............ 16
Internet radio ............................ 69 Listening to internet radio ....... 69 iPod/iPhone ...............................74
Overview ................................74
L
Linking multi-information display and the system .......................24
M
“MAP” button ..............................8
Media operation ........................70
“MENU” button .....................8, 10
“Menu” screen ..........................10 “Menu” screen operation ........10
Mobile Assistant .....................107 Connectable devices and avail-able functions .....................107
Mobile Assistant operation ...107
O
Operating information ..............86 CD player and disc .................87
Error messages ......................96
File information .......................90
High-resolution sound source.90
iPod ........................................89
Radio ......................................86
Terms......................................94
Other settings ...........................46
P
“Phone” button (“Menu” screen) .........................................10, 120
“Phone” button (“Setup” screen) .........................................13, 136
“PHONE” button .................8, 120
Phone operation (Hands-free system for cellular phones) .120
Phone settings ...... ..................136
Contacts/Call history settings screen.................................138
