This manual explains the opera-
tion of the system. Please read
this manual carefully to ensure
proper use. Keep this manual in
your vehicle at all times.
The screens shown in this man-
ual may differ from the actual
screen of the system depending
on availability of functions, and
Connected Services subscrip-
tion status.
The screens in this manual will
also differ if the screen theme
settings have been changed.
(Theme setting: P. 4 6 )
In some situations when chang-
ing between screens, it may
take longer than normal for the
screen to change, the screen
may be blank momentarily or
noise may be displayed.
Please be aware that the con-
tent of this manual may be dif-
ferent from the system in some
cases, such as when the sys-
tem’s software is updated.
The company names and prod-
uct names appearing on this
manual are the trademarks and
registered trademarks of their
respective companies.
TOYOTA MOTOR CORPORA-
TION
Introduction
Multimedia system own-
er’s manual

81-1. Basic function
1-1.Basic function
Press to eject a disc.*1 ( P. 5 7 )
By touching the screen with y our finger, you can control the
selected functions. ( P.17)
Insert a disc into this slot. The CD player turns on immediatel y.
*1
( P. 5 7 )
Press to play/pause. Press to turn mute on/off.
*1
Press to seek up or down for a radio station or to access a
desired track/file. ( P.61, 70, 72, 74, 77)
Press to access the Bluetooth
® hands-free system. ( P.120)
When an Apple CarPlay connection is established, press to dis-
play the phone app screen.
*2, 3
Press to display the Toyota apps screen.*3, 4 (  P.159)
Turn to change the radio station or skip to the next or previou s
track/file. ( P.61, 70, 72, 74, 77)
Press to turn the audio/visual system on and off, and turn it t o
adjust the volume. Press and hold to restart the system. ( P.16,
Buttons over view
Operations of each part
A
B
C
D
E
F
G
H
I

91-1. Basic function
1
Quick guide
56)
If a turn-by-turn navigation application has been downloaded to a
connected smartphone, the application will be displayed and can
be used.
*5
When an Apple CarPlay connection is established, press to dis-
play the Maps app screen.
*2, 3
Press to display the audio/visual system screen. ( P.54, 56)
Press to display the “Menu” screen. ( P. 1 0 )
Press to display the home screen. ( P. 1 9 )
*1: Audio Plus only
*2: For details about Apple CarPlay: P. 4 1
*3: This function is not made available in some countries or areas .
*4: The Toyota apps screen may not be displayed when an Apple CarPlay
connection is established.
*5: For details about a turn-by-turn navigation application, refer to
https://www.toyota.com/audio-multimedia
in the United States,
https://www.toyota.ca/connected
in Canada, and
http://www.toyotapr.com/audio-multimedia
in Puerto Rico.
J
K
L
M

101-1. Basic function
Press the “MENU” button to display the “Menu” screen.
Select to display the audio control screen. ( P.54)
Select to display the hands-free operation screen. ( P.120)
When an Apple CarPlay connection is established, select to dis-
play the phone app screen.
*2 (  P.41)
Select to display the Toyota apps screen.
*2 (  P.159)
When an Apple CarPlay connection is established and this button
displays “Apple CarPlay”, select to display the home screen of
Apple CarPlay.
*2 (  P. 4 1 )
Select to display the information screen ( P.14) or fuel consump-
tion/energy monitor screen.
*3
Select to display the “Setup” screen. ( P.13)
Select to adjust the contrast, brightness, etc. of the display.
( P. 2 3 )
*1: The clock is not displayed on the screen for this vehicle. The clock is dis-
played on the combination meter.
*2: This function is not made available in some countries or areas .
*3: Refer to the “OWNER’S MANUAL”
“Menu” screen
“Menu” screen operation
A
B
C
D
E
F
G

111-1. Basic function
1
Quick guide
Indicate during data commu-
nication performed via Data
Communication Module
(DCM)
*1
The reception level of Data
Communication Module
(DCM) display
*1 ( P. 1 1 )
The reception level of the
connected phone display
( P. 1 1 )
Remaining battery charge
display ( P. 1 2 )
Bluetooth
® phone connection
condition display ( P.12)
Wi-Fi
® connection condition
display
*1, 2 (  P. 3 6 )
*1: Vehicles with DCM
*2: This function is not made avail-
able in some countries or areas.
●The number of status icons that
can be displayed differs depend-
ing on the displayed screen.
The level of reception does not
always correspond with the level
displayed on the cellular phone.
The level of reception may not
be displayed depending on the
phone you have.
When the cellular phone is out
of the service area or in a place
inaccessible by radio waves,
/ is displayed.
“Rm” is displayed when receiv-
ing in a roaming area. While
roaming, display “Rm” top-left
on the icon.
The receiving area may not be
displayed depending on the type
of Bluetooth
® phone you have.
While connected with cellular
phone
Status icon
Status icons are displayed
at the top of the screen.
Status icon explanation
A
B
C
D
E
F
5HFHSWLRQOHYHOGLVSOD\
Reception LevelIndicators
Poor
Excellent

121-1. Basic function
While using Data Communi-
cation Module (DCM)
While using Wi-Fi®hotspot
●When Wi-Fi® hotspot is off, no
item is displayed.
The amount displayed does not
always correspond with the
amount displayed on the Blue-
tooth
® device.
The amount of battery charge
left may not be displayed
depending on the type of the
Bluetooth
® device connected.
This system does not have a
charging function. An antenna for the Bluetooth
®
connection is built into the
instrument panel.
The condition of the Bluetooth
®
connection may deteriorate and
the system may not function
when a Bluetooth
® phone is
used in the following conditions
and/or places:
The cellular phone is obstructed
by certain objects (such as
when it is behind the seat or in
the glove box or console box).
The cellular phone is touching or
is covered with metal materials.
Leave the Bluetooth
® phone in a
place where the condition of the
Bluetooth
® connection is good.
Reception LevelIndicators
Poor
Excellent
Reception LevelIndicators
No connection
Connected
Remaining battery charge
display
Remaining chargeIndicators
Empty
Full
Bluetooth® connection
condition display
IndicatorsConditions
(Blue)
Indicates that the con-
dition of the Blue-
tooth
® connection is
good.
(Gray)
While in this condition,
sound quality during
phone calls may dete-
riorate.
Indicates that the cel-
lular phone is not con-
nected via Bluetooth
®.

131-1. Basic function
1
Quick guide
Press the “MENU” button, then
select “Setup” to display the
“Setup” screen. The items
shown on the “Setup” screen
can be set.Select to change the selected
language, operation sound
settings, etc. ( P. 4 6 )
Select to set Bluetooth
®
device and Bluetooth
® sys-
tem settings. ( P. 2 9 )
Select to set audio settings.
( P. 8 4 )
Select to set the phone
sounds, contacts, message
settings, etc. ( P.136)
Select to set the voice set-
tings. ( P.49) Select to set vehicle informa-
tion. (
P.50)
Select to set Wi-Fi
® connec-
tion settings.
*1, 2 (  P. 3 7 )
Select to set Toyota apps set-
tings.
*2 (  P.163)
*1: Vehicles with DCM
*2: This function is not made avail-
able in some countries or areas.
“Setup” screen
“Setup” screen
A
B
C
D
E
F
G
H

141-1. Basic function
Useful information, such as the
fuel consumption, weather, etc.,
is available on the information
screen.
The information screen can be
reached by the following meth-
ods:
1Press the “MENU” button.
2 Select “Info”.
3 Select the desired item.
Select to display the fuel con-
sumption and energy monitor
screen.
*2
Select to display the vehicle
alert history.
*1: Vehicles with DCM
*2: Refer to the “OWNER’S MAN-
UAL”
“Infor mation” screen
“Information” screen*1
A
B

15
2
2
Basic function
Basic function
2-1. Basic information before operation
Initial screen ................... 16
Touch screen.................. 17
Home screen.................. 19
Entering letters and num- bers/list screen operation..................................... 20
Screen adjustment ......... 23
Linking multi-information display and the system. 24
2-2. Connectivity settings Registering/Connecting a Bluetooth
® device ........ 25
Setting Bluetooth
® details
..................................... 29
Wi-Fi
® Hotspot ............... 36
Apple CarPlay™ ............ 41
2-3. Other settings General settings ............. 46
Voice settings ................. 49
Vehicle settings .............. 50

162-1. Basic information before operation
2-1.Basic information before operation
After a few seconds, the caution
screen will be displayed.
After about 5 seconds or select-
ing “Continue”, the caution
screen automatically switches to
the next screen.
When system response is
extremely slow, the system can
be restarted.
1Press and hold the “POWER
VOLUME” knob for 3 sec-
onds or more.
Initial screen
When the power switch is in
ACCESSORY or ON mode,
the initial screen will be dis-
played and the system will
begin operating.
Caution screen
WARNING
●When the vehicle is stopped
with the hybrid system operat-
ing, always apply the parking
brake for safety.
Restarting the system
