Page 44 of 306

44
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
2. Bluetooth® SETTINGS
1. REGISTERING/CONNECTING Bluetooth® DEVICE
1Turn the Bluetooth® connection setting
of your cellular phone on.
 This function is not available when
Bluetooth®  connection  setting  of  your  cel-
lular phone is set to off.
2Press the  “APPS” button.
3Select “Phone” .
Operations  up  to  this  point  can  also  be
performed by pressing the   switch on
the  steering  wheel  or    switch  on  the
control panel.
4Select  “Yes” to register a phone.
5When this screen is displayed, search
for  the  device  name  displayed  on  this
screen  on  the  screen  of  your
Bluetooth
® device.
For details about operating the Bluetooth®
device, see the manual that comes with it.
 To  cancel  the  registration,  select  “Can-
cel”.
6Register  the  Bluetooth®  device  using
your Bluetooth
® device.
 A  PIN-code  is  not  required  for  SSP
(Secure  Simple  Pairing)  compatible
Bluetooth
®  devices.  Depending  on  the
type  of  Bluetooth®  device  being  con-
nected,  a  message  confirming  registra-
tion  may  be  displayed  on  the  Bluetooth
®
device’s screen. Respond and operate the
Bluetooth® device according  to the confir-
mation message.
REGISTERING A Bluetooth®
PHONE FOR THE FIRST TIME
To  use  the  hands-free  system,  it  is
necessary  to  register  a  Bluetooth
®
phone with the system.
Once the phone has been registered, it
is  possible  to  use  the  hands-free  sys-
tem.
This  operation  cannot  be  performed
while driving.
For  details  about  registering  a
Bluetooth
® device:  P.51
PS081IO
Page 52 of 306

52
2. Bluetooth® SETTINGS
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
For details about operating the Bluetooth®
device, see the manual that comes with it.
 To  cancel  the  registration,  select  “Can-
cel”.
4Register  the  Bluetooth®  device  using
your Bluetooth
® device.
 A  PIN-code  is  not  required  for  SSP
(Secure  Simple  Pairing)  compatible
Bluetooth
®  devices.  Depending  on  the
type  of  Bluetooth®  device  being  con-
nected,  a  message  confirming  registra-
tion  may  be  displayed  on  the  Bluetooth
®
device’s screen. Respond and operate the
Bluetooth®  device according to the  confir-
mation message.
5Check  that  the  screen  is  displayed
when registration is complete.
 The  system  waits  for  connection  requests
coming from the registered device.
 At this stage, the Bluetooth
® functions are
not yet available.
6Select  “OK” when the connection sta-
tus  changes  from  “Connection  wait-
ing...” to “Connected”.
 If  an  error  message  is  displayed,  follow
the guidance on the screen to try again.
1Display the “Bluetooth* Setup” screen.
( P.50)
2Select  “Remove” .
3Select the desired device.
4Select “Yes”  when  the  confirmation
screen appears.
5Check  that  a  confirmation  screen  is
displayed  when  the  operation  is  com-
plete.
*: Bluetooth  is  a  registered  trademark  of Bluetooth SIG, Inc.
DELETING A Bluetooth®
DEVICE
INFORMATION
● When  deleting  a  Bluetooth®  phone,  the
contact data will be deleted at the same
time.
Page 97 of 306

97
2. RADIO OPERATION
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
AUDIO SYSTEM
3
IF THE SATELLITE RADIO TUNER MALFUNCTIONS
When problems occur with the XM tuner, a message will appear on the screen. Re-
ferring to the table below to identify the problem, take the suggested corrective ac-
tion.
MessageExplanation
“Check Antenna”
The XM antenna is not connected. Check whether the XM antenna
cable is attached securely.
A short circuit occurs in the antenna or the surrounding antenn a ca-
ble. See a Toyota certified dealer for assistance.
“Ch Unauthorized”
You  have  not  subscribed  to  XM  Satellite  Radio.  The  radio  is  bei ng
updated with the latest encryption code. Contact XM Satellite R adio
for  subscription  information.  When  a  contract  is  canceled,  you  can
choose “Ch 000” and all free-to-air channels.
The premium channel you selected is not authorized. Wait for ab out
2 seconds until the radio returns to the previous channel or “C h 001”.
If it does not change automatically, select another channel. To  listen
to the premium channel, contact XM Satellite Radio.
“No Signal”The XM signal is too weak at the current location. Wait until y our ve-
hicle reaches a location  with a stronger signal.
“Loading”The unit is acquiring audio or program information. Wait until  the unit
has received the information.
“Channel Off Air”The channel you selected is not broadcasting any programming. S e-
lect another channel.
-----There is no song/program title or artist name/feature associate d with
the channel at that time. N o action is required.
“Chan Unavailable”
The  channel  you  selected  is  no  longer  available.  Wait  for  about  2
seconds until the radio returns  to the previous channel or “Ch  001”.
If it does not change automatical ly, select another channel.
INFORMATION
●Contact  the  XM  Listener  Care  C enter  at  1-877-447-0011  (U.S.A.)  or  1-877-209-0079
(Canada).
Page 173 of 306

173
1. PHONE OPERATION (HANDS-FREE SYSTEM FOR CELLULAR PHONES)
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
PHONE
7
1Display  the  phone  top  screen.
(P.171)
2Select  the “Contacts”   tab  and  select
the desired contact.
3Select the desired number.
4Check  that  the  “Call”  screen  is  dis-
played.
INFORMATION
● When making a call to the same number
continuously, only the most recent call is
listed in call history.
● When a phone number registered in the
contact  list  is  received,  the  name  is  dis-
played.
● Number-withheld  calls  are  also  memo-
rized in the system.
● International  phone  calls  may  not  be
made  depending  on  the  type  of  cellular
phone you have.
● The  list  should  group  together  consecu-
tive entries with the same phone number
and  same  call  type.  For  example,  two
calls  from  Kay  Rowles’s  mobile  would
be displayed as follows: Kay Rowles (2)
● By  pressing  the    switch  on  the
steering wheel, a call to the latest history
item can be made.
BY CONTACTS LIST
Calls  can  be  made  by  using  contact
data which is transferred from a regis-
tered cellular phone. ( P.174)
Up  to  2500  contacts  (maximum  of  4
phone  numbers  and  e-mail  addresses
per  contact)  can  be  registered  in  the
contact list.
Page 204 of 306

204
3. WHAT TO DO IF...
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
In other situations
: For details, refer to the owner’s manual that came with the c ellular phone.
SymptomLikely causeSolution
Page
Cellular
phoneThis
system
The  Bluetooth® con-
nection  status  is  dis-
played  at  the  top  of
the  screen  each  time
the power switch is in
ACCESSORY  or  ON
mode.
Connection  confir-
mation  display  on
this system is set to
on.To  turn  off  the  display,
set  connection  confir-
mation  display  on  this
system to off.
56
Even  though  all  con-
ceivable  measures
have  been  taken,  the
symptom  status  does
not change.
The  cellular  phone
is  not  close  enough
to this system.Bring  the  cellular
phone  closer  to  this
system.
The  cellular  phone
is the most likely
cause  of  the  symp-
tom.
Turn the cellular phone
off,  remove  and  rein-
stall  the  battery  pack,
and  then  restart  the
cellular phone.
Enable  the  cellular
phone’s  Bluetooth®
connection.
Stop  the  cellular
phone’s  security  soft-
ware  and  close  all  ap-
plications.
Before  using  an  appli-
cation  installed  on  the
cellular phone, careful-
ly check its source and
how its operation might
affect this system.

Page 280 of 306

280
1. Entune App Suite OVERVIEW
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
User  registration  is  required  to  start  using
the Entune App Suite service.
 Entune App suite does not require an acti-
vation fee or monthly recurring fees.
 Services requiring a separate contract can
also be used.*
*: For details, refer to
http://www.toy ota.com/entune/
 or call
1-800-331-4331.
 Entune App  Suite  is  available  in  the  con-
tiguous United States, D.C. and Alaska.
The  following  personal  data  can  be
deleted  from  the  system  and  returned  to
their default settings:
• Downloaded applications
• Downloaded application content
BEFORE USING THE
FUNCTION
SUBSCRIPTION
AVAILABILITY OF SERVICE
INFORMATION
●When  using  Entune App  Suite,  depend-
ing  on  the  details  of  your  cellular  phone
contract,  data  usage  fees  may  apply.
Confirm  data  usage  fees  before  using
this service.
● In  this  section,  the  required  actions  to
activate  applications,  connect  a  cellular
phone  to  the  system  and  registration
steps  for  Entune  App  Suite  are
explained.  For  details  regarding  Entune
App  Suite  operations  and  each  of  the
applications, refer to
http://www.toyota.com/entune/
.
● The  actual  service  availability  is  depen-
dent on the network condition.
INITIALIZING PERSONAL
DATA
The personal data used in applications
can  be  removed  from  the  system.
( P.63)
INFORMATION
● Once initialized, data will be erased from
the  system.  Pay  close  attention  when
initializing the data.
Page 300 of 306

300
PRIUS PRIME_Navi_OM47C23U_(U)
17.11.06     14:19
Export Control:
 You agree not to export from anywhere any part of the Data or  any direct product thereof except
in  compliance  with,  and  with  all  licenses  and  approvals  require d  under,  applicable  export  laws,  rules  and
regulations, including but not limited to the laws, rules and r egulations administered by the Office of Foreign Assets
Control of the U.S. Department of Commerce and the Bureau of In dustry and Security of the U.S. Department of
Commerce. To the extent that any such export laws, rules or reg ulations prohibit HERE from complying with any
of its obligations hereunder to deliver or distribute Data, such failure  shall  be excused  and shall not constitute a
breach of this Agreement.
Entire Agreement:  These terms and conditions consti tute the entire agreement between HERE (and its licensors,
including  their  licensors  and  suppliers)  and  you  pertaining  to  the  subject  matter  hereof,  and  supersedes  in  their
entirety any and all written or oral agreements previously exis ting between us with respect to such subject matter.
Severability:   You  and  HERE  agree  that  if  any  portion  of  this  agreement  is  fo und  illegal  or  unenforceable,  that
portion shall be severed and the remainder of the Agreement sha ll be given full force and effect.
Governing Law:  The above terms and conditions s hall be governed by the laws of the State of I llinois (for Data
for  the  Americas  and/or  the  Asia  Pacific  region)  or  The  Netherl ands  (for  Data  for  Europe,  the  Middle  East  and
Africa), without giving effect to (i) its conflict of laws prov isions, or (ii) the United Nations Convention for Contracts
for the International Sale of Goods, which is explicitly exclud ed. For any and all disputes, claims and actions arising
from or in connection with the Data (“Claims”), you agree to su bmit to the personal jurisdiction of (a) the State of
Illinois for Claims related to Dat a for the Americas and/or the Asia Pacific region provided to you hereunder, and
(b) The Netherlands for Data for Europe, the Middle East and/or  Africa provided to you hereunder.
Government  End  Users:   If  the  Data  is  being  acquired  by  or  on  behalf  of  the  United  St ates  government  or  any
other entity seeking or applying rights similar to those custom arily claimed by the United States government, this
Data is a “commercial item” as that term is defined at 48 C.F.R . (“FAR”) 2.101, is licensed in accordance with this
End-User  License  Agreement,  and  each  copy  of  Data  delivered  or  otherwise  furnished  shall  be  marked  and
embedded as appropriate with the following “Notice of Use”, and  be treated in accordance with such Notice:
NOTICE OF USE
CONTRACTOR (MANUFACTURE R/ SUPPLIER) NAME:
HERE
CONTRACTOR (MANUFACTURER/SUPPLIER) ADDRESS:
425 West Randolph Street, Chicago, IL 60606.
This Data is a commercial item as defined in FAR 2.101 and is s ubject to the End-User License
Agreement under which this Data was provided.
© 1987-2015 HERE. All rights reserved. *original publication da te
If  the  Contracting  Officer,  federal  government  agency,  or  any  f ederal  official  refuses  to  use  the  legend  provided
herein,  the  Contracting  Officer,  federal  government  agency,  or  any  federal  official  must  notify  HERE  prior  to
seeking additional or alternative rights in the Data.
© 1987-2015 HERE. All rights reserved. *original publication da te
