TOYOTA PRIUS V 2012 Accessories, Audio & Navigation (in English)
Manufacturer: TOYOTA, Model Year: 2012, Model line: PRIUS V, Model: TOYOTA PRIUS V 2012Pages: 409, PDF Size: 6.88 MB
Page 371 of 409
371
2. ADVANCED PARKING GUIDANCE SYSTEM
9
PRIUS v (US) NAVI 47675U
11.05.17 14:28
PERIPHERAL MONITORING SYSTEM
The distance that appears on the screen
between three-dimensional objects (such
as vehicles) and flat surfaces (such as the
road) and the actual distance differ as fol-
lows.
The distance that appears on the screen
between three-dimensional objects (such
as vehicles) and flat surfaces (such as the
road) differs from the actual distance as
follows.
• In reality, = < ( and are
equally far away; is farther than
and ). However, on the screen, the sit-
uation appears to be < < .
• On the screen, it appears that a truck is parked approximately 3 ft. (1 m) away.
However, in reality if you back up to point
, you will hit the truck.
DISTANCE GUIDE LINE
Approx.
3 ft. (1 m)
SENSOR
Parking spaces are detected by the
sensors on both ends of the front
bumper, thus making parking position
identification easier.
Page 372 of 409
372
2. ADVANCED PARKING GUIDANCE SYSTEM
PRIUS v (US) NAVI 47675U
11.05.17 14:28
SENSOR DETECTION RANGE
WHEN IN PERPENDICULAR
PARKING ASSIST MODE
SENSOR DETECTION RANGE
WHEN IN PARALLEL PARKING
ASSIST MODE
CAUTION
●A sensor may not operate properly in the
following situations:
• There is ice, snow or mud on the sen-
sor. (When it is removed, the normal
operation will return.)
• The sensor is frozen. (When the sen- sor warms up, it will return to normal.)
At low temperatures in particular, sen-
sors that are frozen may not detect a
parked vehicle.
• The sensor is covered in any way.
• When the vehicle is tilted.
• In extreme hot or cold weather.
• When driving on bumpy roads, slopes, gravelled roads or grass.
• Devices issuing ultrasonic waves are operated around your vehicle, such as
a horn from another vehicle, motorcy-
cle engine, air braking sound from
heavy-duty vehicles.
• When rain or water is splashed over the vehicle.
• When a radio antenna or fender pole is mounted on your vehicle.
• The sensor approaches too close to a parked vehicle.
• The bumper or sensor receives a strong impact.
● Do not attach any accessories within the
detection range of the sensors.
Page 373 of 409
373
2. ADVANCED PARKING GUIDANCE SYSTEM
9
PRIUS v (US) NAVI 47675U
11.05.17 14:28
PERIPHERAL MONITORING SYSTEM
When the vehicle is stopped, turn the
steering wheel all the way to the left,
then all the way to the right. (It does not
matter in which direction-right or left-you
turn first.)
When the screen returns to the original
display, correction is complete.
INITIALIZING THE SYSTEM
Make sure to initialize the system in the
following situations.
The 12-volt battery is disconnected and
reconnected.
The system initialization in progress
screen is displayed when the shift posi-
tion is moved to the “R” (due to low bat-
tery etc.).
HOW TO CORRECT
NOTICE
●If the above screen remains, have the
vehicle inspected at your Toyota dealer.
INFORMATION
● The help screen appears when is
touched. Make a correction using the
following method in accordance with the
display.
When the screen returns to the original
display, correction is complete.
If the above screen remains, have the
vehicle inspected at your Toyota dealer.
Page 374 of 409
374
2. ADVANCED PARKING GUIDANCE SYSTEM
PRIUS v (US) NAVI 47675U
11.05.17 14:28
Page 375 of 409
375
1
2
3
4
5
6
7
8
9
PRIUS v (US) NAVI 47675U
11.05.17 11:24
INDEX
Page 376 of 409
376
ALPHABETICAL INDEX
PRIUS v (US) NAVI 47675U
11.05.17 11:24
A
Adding destinations................................... 84
Address book .......................................... 100
Address book entries .............................. 100
Advanced parking guidance system ....... 320
Advanced parking guidance system camera .......... ...................... 367
Area displayed on screen .................... 366
Differences between the display and the actual road .......................... 368
Driving precautions.............................. 364
Easy set function ................................. 329
Example of how to use the system when parallel parking ....................... 363
Example of how to use the system when parking (Perpendicular
parking) ............................................ 358
If a message appears on the screen ................................... 308
Initializing the system .......................... 373
Introduction.......................................... 320
Maneuvering when parking ................. 322
Manual guide line display mode .......... 358
Operating procedure ................... 331, 343
Parallel parking assist mode ............... 342
Parking assist mode (Perpendicular parking) ................... 328
Pre-support function .................... 328, 342
Pre-support switch............................... 321
Sensor ................................................. 371
Tips for setting the target parking position ............. 338, 350
Usage precautions .............................. 364
What to do when this sort of message is displayed ...................... 353
When a red frame is displayed in the assist mode ............................ 357
When a three-dimensional object is nearby .......................................... 370
AM........................................................... 198 Apps ........................................................302
Audio .......................................................190
Audio language code ..............................226
Audio settings..........................................262
HD Radio™ system sett ings................262
iPod settings ........................................263
Audio/video remote controls (Steering switches) ..............................250
Audio/video system .................................190
Audio/video system operating hints ........252 Caring for your DVD player and disc............................................254
CD-R and CD-RW discs ......................258
iPod .....................................................253
MP3/WMA files ....................................256
Radio reception ...................................252
Terms ..................................................258
USB memory .......................................254
Automatic Sound Levelizer (ASL) ...........195
AUX port..................................................197
B
Basic function ............................................26
Bluetooth®...............................................130
Bluetooth® audio .....................................241
Connecting a Bluetooth® audio
player ...............................................244
Playing Bluetooth
® audio.....................245
Bluetooth® phone ....................................137
Bluetooth® phone message function.......152
Checking messages ............................152
New message notification....................154
Replying (Quick reply) .........................153
Bluetooth
® settings .................................177
Detailed Bluetooth® settings................184
Registered devices ..............................177
Selecting a Bluetooth
® phone .............181
Selecting portable player .....................183
Brightness .........................................31, 223
ALPHABETICAL INDEX
Page 377 of 409
377
PRIUS v (US) NAVI 47675U
11.05.17 11:24
C
Call on the Bluetooth® phone ................. 141
By call history ...................................... 143
By dial ................................................. 141
By phonebook ..................................... 141
By POI call .......................................... 147
By speed dial....................................... 143
By voice recognition ............................ 145
Calling using an SMS/MMS message .......................................... 147
CD........................................................... 212
CLOSE button......................................... 190
Color ................................................. 47, 223
Command list .......................................... 275
Contrast ............................................ 31, 223
Current position calibration ..................... 116
Current position display ............................ 33
D
Deleting destinations ................................ 85
Deleting personal data .............................. 51
Deleting previous destinations ................ 109
Deleting set destinations........................... 72
DEST button ............................................. 10
“Destination” screen.................................. 20
Destination search .................................... 56
By “Address” ......................................... 58
By “Address Book” ................................ 67
By “Coordinates” ................................... 71
By “Emergency” .................................... 68
By home ................................................ 57
By “Intersection & Freeway” .................. 68
By “Map”................................................ 71
By “Point of Interest” ............................. 61
By preset destinations ........................... 57
By “Previous Destinations” .................... 67
Selecting the search area ..................... 56 Detailed navigation settings .................... 111
Detour setting............................................ 86
Dial .................................................. 141, 145
Distance and time to destination ............... 83
DSP control ............................................. 195
DVD ........................................................ 212
DVD player.............................................. 212
DVD options ........................................ 221
DVD player and DVD video disc information ....................................... 230
Ejecting a disc ..................................... 212
If the player malfunctions .................... 229
Inserting a disc .................................... 212
Operating a DVD disc.......................... 218
Playing a disc ...................................... 213
Playing a DVD disc.............................. 219
Playing an audio disc .......................... 213
Playing an MP3/WMA disc .................. 215
E
Emergency ................................................ 68
Entune..................................................... 302
Expanded voice commands .................... 274
F
FM ........................................................... 198
Fuel consumption.................................... 280
Function index........................................... 18
G
General settings ........................................ 43
GPS (Global Positioning System) ..... 10, 125
H
HD Radio™ ............................................. 201
Heading-up screen.................................... 41
Home ...................................... 12, 17, 57, 96
Page 378 of 409
378
ALPHABETICAL INDEX
PRIUS v (US) NAVI 47675U
11.05.17 11:24
I
INFO/APPS (INFO) button ........................ 10
Information .............................................. 280
“Information” screen .................................. 24
Inputting letters and numbers ................... 28
Internet radio broadcast .......................... 211
iPod ......................................................... 237
Connecting iPod .................................. 237
Playing iPod ........................................ 237
K
Keyboard layout ........................................ 47
L
Language .................................................. 46
Limitations of the navigation system ....... 125
List screen operation................................. 28
M
MAP .......................................................... 71
Map database information and updates......................................... 382
Map database version and coverage area ..................................... 281
Map icons.................................................. 42
Map scale.................................................. 41
MAP/VOICE button ................................... 10
MEDIA button.......................................... 190
MP3......................................................... 215
N
Natural speech information ..................... 272
Navigation system..................... ................ 56
North-up screen ........................................ 41
O
Operation flow: Guiding the route .............16
Orientation of the map...............................41
Overview button and guidance screen ......10
P
Pausing guidance......................................90
Peripheral monitoring syst em..................316
Phone ......................................................130
Phone (Hands-free system for cellular phone) .....................................132
About the phonebook in this system....134
Using the phone switch .......................133
Using the steering switches .................134
When selling or disposing of the vehicle ........................................135
PHONE button ........................................130
Phone settings ........................................155
Message settings.................................170
Phone display settings.........................174
Phone sound settings ..........................155
Phonebook ..........................................157
Phonebook ......................................141, 157
POI call....................................................147
POI icons...................................................91
Point of Interest .........................................61
Preset destinations..............................14, 57
Previous destinations ................................67
PWR VOL knob .......................................190
Q
Quick guide ...............................................10
Quick reference .........................20, 130, 190
Page 379 of 409
379
PRIUS v (US) NAVI 47675U
11.05.17 11:24
R
Radio ...................................................... 198
Listening to the radio ........................... 198
Presetting a station ............................. 198
Radio broadcast data system.............. 199
Selecting a station ............................... 199
Traffic announcement ......................... 200
Radio broadcast data system ................. 199
RADIO button ......................................... 190
Rear view monitor system ...................... 316 Area displayed on screen.................... 318
Rear view monitor system camera ...... 318
Receive on the Bluetooth
® phone .......... 148
Register a Bluetooth® phone .................. 137
Connecting a Bluetooth® phone.......... 138
Reconnecting the Bluetooth®
phone............................................... 140
Registering home...................................... 12
Registering preset destinations ................ 14
Reordering destinations ............................ 84
Resuming guidance .................................. 90
Route guidance......................................... 73
Route guidance screen ............................. 77
Route overview ......................................... 87
Route preference ...................................... 88
Route trace ............................................... 94
S
Satellite radio (SAT)................................ 194
Screen adjustment .................................... 31
Screen Off................................................. 31
Screen scroll operation ............................. 33
Screen settings adjustment ...................... 31
Screens for navigation settings................. 95 SEEK/TRACK button .............................. 190
Setting home as the destination................ 17
Setting up the “Address Book” ................ 100
Setting up the “Areas to Avoid” ............... 105
Setting up the “Home” ............................... 96
Setting up the “Preset Destinations” ......... 98
SETUP button ........................... 10, 130, 190
“Setup” screen .......................................... 22
Show on map ............................................ 91
SMS/MMS message ....................... 147, 152
Speed dial ............................................... 143
Standard map icons .................................. 42
Starting route guidance ............................. 73
Steering switches .................... 134, 250, 266
Surround ................................................. 195
Switching the screens ............................... 38
T
Talk on the Bluetooth® phone ................. 149
Incoming call waiting ........................... 151
Time zone ................................................. 45
Tire change calibration............................ 116
Tone ........................................................ 223
Tone and balance ................................... 195
Touch screen operation ............................ 27
Traffic incidents ....................................... 296
TUNE SCROLL knob .............................. 190
Typical voice guidance prompts................ 80
U
USB memory........................................... 232 Connecting a USB mdmory ................. 232
Playing a USB memory ....................... 233
USB port ................................................. 197
Page 380 of 409
380
ALPHABETICAL INDEX
PRIUS v (US) NAVI 47675U
11.05.17 11:24
V
Vehicle settings ....................................... 119
Maintenance ........................................ 119
Vehicle customization.......................... 124
Voice command system .................. 193, 266 Steering switches for the voice command system ................... 266
Voice recognition .................................... 145
Voice settings............................................ 52
Voice volume ............................................ 53
W
WMA ....................................... 215, 256, 258
X
XM Fuel Prices........................................ 290
Show XM Fuel Prices information ....... 290
View detailed fuel price information..... 290
XM Fuel Prices settings....................... 291
XM NavTraffic
®....................................... 296
Show traffic event ................................ 296
Show XM Navtraffic
® information ........ 297
XM NavWeather™ .................................. 293 Show XM NavWeather
™
information ....................................... 293
Weather information ............................ 294
Weather warnings ............................... 295
XM NavWeather™ indicator ................ 295
XM Satellite Radio broadcast.................. 205 Channel category ................................ 207
Displaying the radio ID ........................ 206
Displaying the title and name .............. 208
How to subscribe to an XM Satellite Radio ........................... 205
If the satellite radio tuner malfunctions..................................... 209
Listening to satellite radio .................... 206
Presetting a channel............................ 207
Selecting a channel ............................. 207 XM Sports ...............................................284
Receive sports information ..................284
XM Sports settings ..............................285
XM Stocks ...............................................287
Receive stock data ..............................287
XM Stocks settings ..............................288
Z
Zoom in button ..........................................10
Zoom out button ........................................10
