TOYOTA PRIUS V 2013 Accessories, Audio & Navigation (in English)

i
1. BASIC INFORMATION BEFORE OPERATION
Introduction
This manual is made up of 2 sections.
The first describing available functions for models without navigation capabili-
ties (WITHOUT NAVIGATION) such as audio and hands-free.
The second describing available functions for models with navigation capabili-
ties (WITH NAVIGATION) such as navigation, audio, and hands-free.
For models that do not have navigation capabilities, refer to the “WITHOUT
NAVIGATION” section. For models that have navigation capabilities, refer to
the “WITH NAVIGATION” section.
■EXISTENCE OF NAVIGATION CAPABILITIES
Existence of navigation capabilities can be confirmed by performing the following:
1 When the ignition switch is turned to the “ACC” or “ON” position, the initial
screen will be displayed and the system will begin operating.
2 Press the “APPS” button.
Either of the following screens will be displayed.
If your system does not have the “APPS” button, the Display Audio system does not
have navigation capabilities, refer to the “WITHOUT NAVIGATION” section.
CONFIRMING DISPLAY AUDIO MODEL
Navigation capabilitiesReference
Not installedWITHOUT NAVIGATION (1ST SECTION on-
ly)
InstalledWITH NAVIGATION (2ND SECTION only)

ii
1. BASIC INFORMATION BEFORE OPERATION
If screen A is displayed, the Display Audio system does not have navigation ca-
pabilities.
If screen B is displayed, the Display Audio system has navigation capabilities.
In this manual, illustrations showing the typical Display Audio system layout,
USB port and rear view camera location, etc. has been used. The actual design
and button position may differ depending on the vehicles. For the correct loca-
tion of these items, please refer to Section 3 and the pictorial index of the “Own-
er’s Manual”.
This manual has been written using a vehicle with a gasoline engine vehicle
(without a smart entry and start system) as an example. For vehicles with a
smart entry and start system and hybrid vehicles, please refer to the following
table to confirm the engine switch name and mode.
COMMON ILLUSTRATIONS FOR ALL VEHICLE MODELS
ENGINE SWITCH NAMES AND MODES
Vehicle systemSwitch name and mode
Vehicles without a
smart key systemEngine switchACCONOFF (LOCK)
Vehicles with a smart
key system“ENGINE START
STOP” switchACCESSORYIGNITION
ONOFF
Hybrid vehicles“POWER” switchACCESSORYONOFF
Screen AScreen B

iii
1. BASIC INFORMATION BEFORE OPERATION
SYMBOLS USED IN ILLUSTRATIONS
Safety symbol
The symbol of a circle with a slash through it means “Do not”, “Do not
do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turning, etc.)
used to operate switches and other
devices.
Indicates the outcome of an operation (e.g.
a lid opens).
HOW TO READ THIS MANUAL
No.NameDescription
Operational OutlinesAn outline of the operation is explained.
Main OperationsThe steps of an operation are explained.
Related OperationsA main operation’s supplementary operations are described.
InformationUseful information for the user is described.

iv
1. BASIC INFORMATION BEFORE OPERATION
