When trouble arises
7
“Fasten Seat Belt”
Rear seat belt is not fastened
The warning buzzer will sound.
It will be displayed when the vehicle speed
exceeds approx. 20 km/h (12 mph) and the
seat belt is unfastened.
➞ Wear a seat belt
“Release Parking
Brake”
The parking brake is not released
If the vehicle speed exceeds approx. 5 km/h
(3 mph) with the parking brake being
applied, the warning buzzer will sound.
➞ Release the parking brake
“Sonar Sensor in Oper-
ation Pay Attention”―
Front corner sensors or reverse sensors is
activated
✽
The activated sonar is displayed.
The warning buzzer may sound.
➞ Check the situation around you and drive
accordingly such as stepping on the
brake pedal
“VSC in Operation”
(Flashing)
VSC is activated
➞Drive with extreme caution
“Turn Lights OFF”
The driver’s door was opened while the
front position lights are turned on
The warning buzzer will sound.
➞ Turn off the front position lights
“Steering Angle Left”
―
The steering wheel is mo ved to left or right
while the vehicle is stopped
➞ Check the tire direction and move the
vehicle safety
“Steering Angle Right”
“Roads may be Icy”―
The outside temperature has become
approx. 3°C (37 ℉) or below
➞ Since the road could be frozen, check the
road condition and drive with extreme
caution
Warning messages
Indicators/
Warning lights
Warning content/Action to take
