F RELAY LOCATIONS
2: R/B No. 2Engine Compartment Left (See Page 18)
*1 : 15A H-LP LH
*2 : 15A H-LP RH

23
F
: J/B No. 4Right Kick Panel (See Page 18)
[J/B No. 4 Inner Circuit]

24
F RELAY LOCATIONS
5: R/B No. 5Left Kick Panel (See Page 18)

25
F
6: R/B No. 6Engine Compartment Left (See Page 18)
Fusible Link BlockNear The Battery (See Page 18)

26
F RELAY LOCATIONS
Fuse BlockLower Finish Panel (See Page 18)

27
MEMO

28
G ELECTRICAL WIRING ROUTING
Position of Parts in Engine Compartment
*1 : w/ A/C
*2 : w/o A/C
A 1 A/C Condenser Fan Motor E 1 Electronically Controlled Transmission Solenoid
A 2 A/C Magnetic Clutch and Lock Sensor E 2 Engine Coolant Temp. Sensor
A 3 A/C Triple Pressure SW (A/C Dual and Single
Pressure SW) F 1 Front Side Marker Light LH
A 4 A/C Water Temp. SW F 2 Front Side Marker Light RH
A 5 A/T Fluid Temp. SW F 3 Front Turn Signal Light LH and Front Parking
A 6 ABS Actuator Light LH
A 7 ABS Actuator F 4 Front Turn Signal Light RH and Front Parking
A 8 ABS Relay Light RH
A 9 ABS Relay F 5 Front Washer Motor
A 10 ABS Speed Sensor Front LH F 6 Front Wiper Motor
A 11 ABS Speed Sensor Front RH F 7 Fusible Link Block
B 1 Back-Up Light SW (M/T) G 1 Generator
B 2 Brake Fluid Level Warning SW G 2Generator
C 1 Center Diff. Lock Warning Buzzer SW H 1 Headlight LH
C 2 Crankshaft Position Sensor H 2 Headlight RH
C 3 Cruise Control Actuator H 3 Horn
D 1 Data Link Connector 1

29
G
Position of Parts in Engine Compartment
I 1 Idle Air Control Valve R 1Radiator Fan Motor
I 2 Igniter R 2 Rear Washer Motor
I 3 Ignition Coil and Distributor
I 4 Ignition Coil and Distributor S 1 Solenoid Valve SLD
I 5 Injector No. 1 S 2 Starter
I 6 Injector No. 2 S 3 Starter
I 7 Injector No. 3
I 8 Injector No. 4 T 1 Throttle Position Sensor
I 9 Intake Air Temp. Sensor
V 1 Vapor Pressure Sensor
K 1 Knock Sensor V 2 Vehicle Speed Sensor (Combination Meter)
V 3 Vehicle Speed Sensor (Front)
M 1 Manifold Absolute Pressure Sensor V 4 Vehicle Speed Sensor (Rear)
V 5 VSV (Center Diff. Lock No. 1)
N 1 Noise Filter (Ignition System) V 6 VSV (Center Diff. Lock No. 2)
V 7 VSV (EGR)
O 1 Oil Pressure SW V 8 VSV (EVAP)
O 2 Oxygen Sensor (Bank 1 Sensor 1) V 9 VSV (Vapor Pressure Sensor)
O 3 Oxygen Sensor (Bank 1 Sensor 2)
W 1 Water Temp. Sender
P 1 Park/Neutral Position SW (A/T)

30
G ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
A 12 A/C Amplifier C 6 Cigarette Lighter Illumination
A 13 A/C Control SW C 7 Clock
A 14 A/C Thermistor C 8 Clutch Start SW
A 15 ABS Deceleration Sensor C 9 Combination Meter
A 16 ABS ECU C 10 Combination Meter
A 17 ABS ECU C 11 Combination Meter
A 18 Airbag Sensor Assembly C 12 Combination SW
A 19 Airbag Squib (Front Passenger Airbag Assembly) C 13 Combination SW
A 20 Airbag Squib (Steering Wheel Pad) C 14 Combination SW
C 15 Cruise Control Clutch SW
B 3 Blower Motor C 16 Cruise Control ECU
B 4 Blower Resisitor
B 5 Blower SW D 2 Data Link Connector 3
B 6 Buckle SW LH D 3 Defroster Mode SW
D 4 Diode (Engine Idle-Up)
C 4 Center Diff. Lock Control SW D 5 Door Lock Control Relay
C 5 Cigarette Lighter
