Brake fluid level
Make sure the brake fluid level is correct.
See page 222 in Section 7±2 for addition-
al information.
Engine oil level
Check the level on the dipstick with the
engine turned off and the vehicle parked
on a level spot. See page 220 in Section
7±2 for additional information.
Power steering fluid level
Check the level through the reservoir. The
level should be in the ªHOTº or ªCOLDº
range depending on the fluid temperature.
See page 223 in Section 7±2 for addition-
al information.
Exhaust system
If you notice any change in the sound of
the exhaust or smell exhaust fumes, have
the cause located and corrected immedi-
ately. (See ªEngine exhaust cautionsº on
page 157 in Section 2.)Be on the alert for changes in perfor-
mance, sounds, and visual tip±offs that
indicate service is needed. Some impor-
tant clues are as follows:

Engine missing, stumbling, or pinging

Appreciable loss of power

Strange engine noises

A leak under the vehicle (however, wa-
ter dripping from the air conditioning
after use is normal.)

Change in exhaust sound (This may
indicate a dangerous carbon monoxide
leak. Drive with the windows open and
have the exhaust system checked im-
mediately.)

Flat±looking tire; excessive tire squeal
when cornering; uneven tire wear

Vehicle pulls to one side when driving
straight on a level road

Strange noises related to suspension
movement

Loss of brake effectiveness; spongy
feeling brake or clutch pedal; pedal al-
most touches floor; vehicle pulls to one
side when braking

Engine coolant temperature continually
higher than normalIf you notice any of these clues, take your
vehicle to your Toyota dealer as soon as
possible. It probably needs adjustment or
repair.
CAUTION
Do not continue driving with the ve-
hicle unchecked. It could result in se-
rious vehicle damage and possibly
personal injury.
Does your vehicle need
repairing?
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2122001 RAV4 (OM42483U)
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2452001 RAV4 (OM42483U)
SPECIFICATIONS
Dimensions and weight246 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine246 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service specifications247 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires249 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION 8
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2462001 RAV4 (OM42483U)
Dimensions and weight Engine
Model:
1AZ±FE
Type:
4 cylinder in line, 4 cycle, gasoline
Bore and stroke, mm (in.):
86.0
86.0 (3.39
3.39)
Displacement, cm
3
(cu. in.):
1998 (121.9)
Overall length mm (in.)
Overall width mm (in.)
Overall height
*
1mm (in.)
Wheelbase mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Vehicle capacity
weight (occupants
+ luggage) kg (lb.)215/70R16 tires 235/60R16 tires
4195 (165.2)
4200 (165.4)
*
2
4205 (165.6)*
3
4245 (167.1)*
4
4210 (165.7)
4215 (165.9)*
3
4245 (167.1)*
4
1735 (68.3) 1785 (70.3)
1670 (65.7)
1705 (67.1)
*
7
2490 (98.0) 2490 (98.0)
1505 (59.3)
*
6
1510 (59.4)*
51525 (60.0)
1495 (58.9)
*
6
1500 (59.1)*
51520 (59.8)
345 (761)
*
6, 8
375 (868)*
6, 9
434 (957)*
5, 8
464 (1023)*
5, 9
345 (761)*
6, 8
375 (868)*
6, 9
434 (957)*
5, 8
464 (1023)*
5, 9
*
1
: Unladen vehicle*
2: With steel wheel spare tire and half spare tire cover*
3: With aluminum wheel spare tire and half spare tire cover*
4: With full spare tire cover*
5: Two±wheel drive models*
6: Four±wheel drive models*
7: With roof rails*
8: With automatic transmission*
9: With manual transmission1670 (65.7)
*
5
1680 (66.1)*
6
1705 (67.1)*
5, 7
1715 (67.5)*
6, 7
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2472001 RAV4 (OM42483U)
Fuel
Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or higher
Fuel tank capacity, L (gal., lmp. gal.):
56 (14.8, 12.3)
Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
Intake 0.19Ð0.29 (0.007Ð0.012)
Exhaust 0.30Ð0.40 (0.012Ð0.016)
Spark plug type:
DENSO SK20R11
NGK IFR6A11
Spark plug gap, mm (in.):
1.1 (0.043)
ENGINE LUBRICATION
Oil capacity (drain and refill),
L (qt., Imp. qt.):
With filter 4.2 (4.4, 3.7)
Without filter 4.0 (4.2, 3.5)
Oil grade:
API grade SJ, ªEnergy±Conservingº or
ILSAC multigrade engine oil is recom-
mended.Recommended oil viscosity (SAE):
5W-30 Preferred
Temperature range anticipated before
next oil change
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Manual transaxle 6.3 (6.7, 5.6)
Automatic transaxle 6.2 (6.6, 5.5)
Coolant type:
ªTOYOTA Long Life Coolantº or equiva-
lent
With ethylene±glycol type coolant for a
proper corrosion protection of aluminum
components
Do not use alcohol type antifreeze or
plain water alone.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2482001 RAV4 (OM42483U)
BATTERY
Open voltage
* at 20
C (68
F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
*: Voltage that is checked 20 minutes af-
ter the key is removed with all the lights
turned off
Charging rates:
5 A max.
CLUTCH
Pedal free play, mm (in.):
5Ð15 (0.2Ð0.6)
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3
MANUAL TRANSAXLE
Oil capacity, L (qt., Imp. qt.):
Two±wheel drive models
2.5 (2.6, 2.2)
Four±wheel drive models
3.4 (3.6, 3.0)
Oil type:
Gear oil API GL±4 or GL±5
Recommended oil viscosity:
SAE 75W±90AUTOMATIC TRANSAXLE
Fluid capacity (drain and refill), L (qt.,
Imp. qt.):
Two±wheel drive models
Up to 3.3 (3.5, 2.9)
Four±wheel drive models
Up to 3.9 (4.1, 3.4)
Fluid type:
Automatic transmission fluid Type T±IV
Change automatic transmission fluid only
as necessary.
Generally, it is necessary to change
automatic transmission fluid only if your
vehicle is driven under one of the Special
Operating Conditions listed in your
ªScheduled Maintenance Guideº or
ªOwner 's Manual Supplementº. When
changing the automatic transmission fluid,
use only Toyota Genuine ATF Type T±IV
(ATF JWS3309 or NWS6500) to aid in
assuring optimum transaxle performance.
Notice: Using automatic transmission
fluid other than Toyota Genuine ATF
Type T±IV may cause deterioration in
shift quality, locking up of your trans-
mission accompanied by vibration, and
ultimately damage the automatic trans-
mission of your vehicle.TRANSFER
(four±wheel drive models)
Oil capacity, L (qt., Imp. qt.):
0.9 (1.0, 0.8)
Oil type:
Hypoid gear oil API GL±5
Recommended oil viscosity:
Above ±18
C (0
F)
SAE 90 or 85W±90
Below ±18
C (0
F)
SAE 80W or 80W±90
REAR DIFFERENTIAL
(four±wheel drive models)
Oil capacity, L (qt., Imp. qt.):
0.9 (1.0, 0.8)
Oil type:
Hypoid gear oil API GL±5
Recommended oil viscosity:
Above ±18
C (0
F)
SAE 90
Below ±18
C (0
F)
SAE 80W or 80W±90
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2492001 RAV4 (OM42483U)
BRAKES
Minimum pedal clearance when depressed
with the force of 490 N (50 kgf, 110 lbf)
with the engine running, mm (in.):
118 (4.6)
Pedal free play, mm (in.):
1Ð6 (0.04Ð0.24)
Pad wear limit, mm (in.):
1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf):
6Ð8 clicks
Fluid type:
SAE J1703 or FMVSS No.116 DOT 3STEERING
Wheel free play:
Less than 30 mm (1.2 in.)
Power steering fluid type:
Automatic transmission fluid DEXRONII
or III
Tires
Tire size:
215/70R16 99S
235/60R16 100H
Tire pressure, kPa (kgf/cm
2 or bar, psi):
200 (2.0, 29)
Wheel size:
Steel wheel 16
6.5J
Aluminum Wheel 16
7JJ
Wheel nut torque, N
´m (kgf´m, ft´lbf):
103 (10.5, 76)
NOTE: For a complete information on
tires (e.g. replacing tires or re-
placing wheels), see ªChecking
tire pressureº through ªAluminum
wheel precautionsº, pages 225
through 230, in Section 7±2.
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2502001 RAV4 (OM42483U)
Fuses
Instrument panel
Fuses (type A)
1. RADIO 15 A: Car audio system
2. DOME 10 A: Clock, personal light, in-
terior lights, air conditioning system,
wireless remote control system, head-
light high beam indicator light, gauges
and meters
3. CUT 30 A: ªRADIOº and ªDOMEº fuses
4. A/C 5 A: Air conditioning system
5. MAIN 30 A: ªH±LP RHº and ªH±LP LHº
fuses
6. HAZ 10 A: Emergency flashers7. ALT±S 5 A: Charging system
8. IGN 15 A: Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system
9. EFI3 10 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, emission control system
10. EFI2 5 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system
11. A/F 20 A: A/F sensor
12. ABS2 30 A: Anti±lock brake system
13. EFI1 20 A: Multiport fuel injection sys-
tem/sequential multiport fuel injection
system, ªEFI2º and ªEFI3º fuses
14. H±LP RH 10 A: Right±hand headlight
15. H±LP LH 10 A: Left±hand headlight
16. ST 5 A: Starting system
17. STOP 10 A: Stop lights, high±mounted
stoplight, anti±lock brake system, shift
lock control system, multiport fuel in-
jection system/sequential multiport fuel
injection system, cruise control system
18. CIG 15 A: Cigarette lighter
19. POWER OUTLET 15 A: Power outlets
20. S±HTR 10 A: No circuit
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2512001 RAV4 (OM42483U)
21. PANEL 7.5 A: Instrument panel light,
gauges and meters, front fog lights,
instrument panel light control, outside
rear view mirror defoggers, air condi-
tioning system
22. FR FOG 15 A: Front fog lights
23. HORN 10 A: Horn
24. TAIL 7.5 A: Tail lights, license plate
lights, instrument cluster lights
25. TAIL&PANEL 15 A: ªPANELº and
ªTAILº fuses
26. ACC 7.5 A: Car audio system, shift
lock control system, clock, power rear
view mirrors
27. DEF 20 A: Rear window defogger
28. GAUGE 10 A: Back±up lights, electric
cooling fans, air conditioning system,
automatic transmission indicator lights,
charging system
29. OBD 7.5 A: On±board diagnosis sys-
tem
30. IG2 10 A: Discharge warning light,
multiport fuel injection system/sequen-
tial multiport fuel injection system,
starting system, SRS airbag system
31. DOOR 20 A: Power door lock system32. MIR HTR 10 A: Outside rear view mir-
ror defoggers
33. RR WIP 15 A: Rear window wiper and
washer
34. WIP 25 A: Windshield wipers and
washer
35. ECU IG 10 A: Emergency flashers,
gauges and meters, anti±lock brake
system, SRS airbag system, shift lock
control system, cruise control system
Fuses (type B)
36. RDI 30 A: Electric cooling fan
37. CDS 30 A: Electric cooling fan
38. AM2 30 A: Discharge warning light,
multiport fuel injection system/sequen-
tial multiport fuel injection system,
starting system, SRS airbag system
and ªIG2º fuse
39. ABS 1 40 A: Anti±lock brake system
40. HTR 40 A: Air conditioning system
41. PWR 30 A: Electric moon roof, power
windows
42. AM1 40 A: Power outlets, rear window
defogger, ªACCº, ªCIGº, ªECU IGº,
ªGAUGEº, ªRR WIPº, ªS±HTRº and
ªWIPº fuses
ProCarManuals.com

'01 Rav4_U (L/O 0008)
2522001 RAV4 (OM42483U)
ProCarManuals.com
