PREPARATION – U140F AUTOMATIC TRANSAXLEPP–55
PP
SSM
Toyota Genuine Seal Packing 1281
Three Bond 1281 or Equivalent-
Toyota Genuine Adhesive 1344
Three Bond 1344 or Equivalent-

PREPARATION – U241E AUTOMATIC TRANSAXLEPP–59
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm -
09031-00030 Pin Punch -
09040-00011 Hexagon Wrench Set -
(09043-20060) Socket Hexagon Wrench 6 -
(09043-20100) Socket Hexagon Wrench 10 -
09042-00010 Torx Socket T30 -
09904-00010 Expander Set -
09905-00012 Snap Ring No.1 Expander -
09905-00013 Snap Ring Pliers -

PP–60PREPARATION – U241E AUTOMATIC TRANSAXLE
PP
EQUIPMENT
Straight edge -
Vernier calipers -
Dial indicator or dial indicator with magnetic base -
To r q u e w r e n c h -
Feeler gauge -
Plastic-faced hammer -
Press -
Seal packing 2403, THREE BOND 2403 or equivalent -

PREPARATION – U241E AUTOMATIC TRANSAXLEPP–61
PP
LUBRICANT
Automatic transaxle fluid
Dry fill8.1 liters (8.6 US qts, 7.2 Imp. qts) Toyota Genuine ATF WS
Automatic transaxle fluid
Drain and refill3.5 liters (3.7 US qts, 3.1 Imp. qts)

PP–62PREPARATION – U241E AUTOMATIC TRANSAXLE
PP
SSM
Toyota Genuine Seal Packing 1281
Three Bond 1281 or Equivalent-
Toyota Genuine Adhesive 1344
Three Bond 1344 or Equivalent-

PREPARATION – GF1A TRANSFERPP–63
PP
RECOMMENDED TOOLS
09904-00010 Expander Set
09905-00012 Snap Ring No.1 Expander

PP–64PREPARATION – GF1A TRANSFER
PP
EQUIPMENT
Dial indicator or dial indicator with magnetic base
Plastic-faced hammer
Hammer
Press
To r q u e w r e n c h

PP–80PREPARATION – STEERING COLUMN
PP
EQUIPMENT
Torque wench -
Drill -

PREPARATION – POWER STEERINGPP–81
PP
EQUIPMENT
Torque wrench -

PP–82PREPARATION – AIR CONDITIONING
PP
EQUIPMENT
To r q u e w r e n c h -
Tape To avoid surface damage
