PREPARATION – 2GR-FE COOLINGPP–25
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent -

PP–24PREPARATION – 2AZ-FE LUBRICATION
PP
EQUIPMENT
Feeler gauge -
Precision straight edge -
To r q u e w r e n c h -
Vernier calipers -
Wooden block -

PREPARATION – 2AZ-FE LUBRICATIONPP–25
PP
LUBRICANT
Item Condition Capacity Classification
Oil grade - - Use API grade SL "Energy-
Conserving" or ILSAC multigrade
engine oil. SAE 5W-20 and SAE
0W-20 engine oil may be used.
However, SAE0W-20 is the best
choice for good fuel economy and
good starting in cold weather.
Drain and refill with oil filter change 4.3 liters (4.5 US qts, 3.8 Imp.
qts)-
without oil filter change 4.1 liters (4.3 US qts, 3.6 Imp.
qts)-
Dry fill Dry fill 5.0 liters (5.3 US qts, 4.4 Imp.
qts)-

PP–26PREPARATION – 2AZ-FE LUBRICATION
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344B or Equivalent -

PREPARATION – 2GR-FE LUBRICATIONPP–25
PP
EQUIPMENT
Container -
Deep socket wrench (24 mm) -
Hose Oil filter
Oil pressure gauge -
Socket wrench (27 mm) -
Straightedge -
Torque wrench -
Wooden block -

PP–26PREPARATION – 2GR-FE LUBRICATION
PP
LUBRICANT
Item Capacity Classification
Oil grade - ILSAC multigrade engine oil is
recommended. SAE 5W-30 is the
best choice for good fuel
economy and good starting in
cold weather.
Drain and refill With oil filter change 6.1 liters ( 6.4 US qts, 5.4 Imp.
qts)-
Without oil filter change 5.7 liters ( 6.0 US qts, 5.0 Imp.
qts)-
Dry fill 6.5 liters ( 6.9 US qts, 5.7 Imp.
qts)-

PREPARATION – 2GR-FE LUBRICATIONPP–27
PP
SSM
Toyota Genuine Adhesive 1344, Three Bond 1344 or Equivalent -
Toyota Genuine Seal Packing Block, Three Bond 1207B or Equivalent -
Toyota Genuine Seal Packing 1282B, Three Bond 1282B or
Equivalent-

PREPARATION – 2GR-FE CHARGINGPP–33
PP
RECOMMENDED TOOLS
09082-00040 TOYOTA Electrical Tester -
(09083-00150) Test Lead Set -

PP–34PREPARATION – 2GR-FE CHARGING
PP
EQUIPMENT
Ammeter -
Ohmmeter -
Service wire -
To r q u e w r e n c h -
Vernier calipers -

PREPARATION – U151E AUTOMATIC TRANSMISSIONPP–39
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm -
09031-00030 Pin Punch -
09031-00040 Pin Punch . -
09040-00011 Hexagon Wrench Set -
(09043-20050) Socket Hexagon Wrench 5 -
(09043-20060) Socket Hexagon Wrench 6 -
(09043-20100) Socket Hexagon Wrench 10 -
09070-20010 Moulding Remover -
09090-04020 Engine Sling Device -
09905-00012 Snap Ring No.1 Expander -
09905-00013 Snap Ring Pliers -
