TOYOTA RAV4 2006 Service Repair Manual

PP–40PREPARATION – U151E AUTOMATIC TRANSMISSION
PP
EQUIPMENT
Straight edge
To r q u e w r e n c h
Vernier calipers
Dial indicator with magnetic base
Slide calipers
Chain block
Feeler gauge
Plastic hammer
Press

PREPARATION – U151E AUTOMATIC TRANSMISSIONPP–41
PP
LUBRICANT
Automatic transaxle fluid
Dry fill
Drain and refill8.1 liter (8.6 US qts, 7.1 Imp.qts)
3.6 liter (3.8 US qts, 3.2 Imp.qts)Toyota Genuine ATF WS

PP–42PREPARATION – U151E AUTOMATIC TRANSMISSION
PP
SSM
Toyota Genuine Seal Packing 1281
Three Bond 1281 or Equivalent-
Toyota Genuine Adhesive 1344
Three Bond 1344 or Equivalent-

PREPARATION – U151F AUTOMATIC TRANSMISSIONPP–45
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm -
09031-00030 Pin Punch -
09031-00040 Pin Punch . -
09040-00011 Hexagon Wrench Set -
(09043-20050) Socket Hexagon Wrench 5 -
(09043-20060) Socket Hexagon Wrench 6 -
(09043-20100) Socket Hexagon Wrench 10 -
09070-20010 Moulding Remover -
09090-04020 Engine Sling Device -
09905-00012 Snap Ring No.1 Expander -
09905-00013 Snap Ring Pliers -

PP–46PREPARATION – U151F AUTOMATIC TRANSMISSION
PP
EQUIPMENT
Straight edge
To r q u e w r e n c h
Vernier calipers
Dial indicator with magnetic base
Slide calipers
Chain block
Feeler gauge
Plastic hammer
Press

PREPARATION – U151F AUTOMATIC TRANSMISSIONPP–47
PP
LUBRICANT
Automatic transaxle fluid
Dry fill
Drain and refill8.1 liter (8.6 US qts, 7.1 Imp.qts)
3.6 liter (3.8 US qts, 3.2 Imp.qts)Toyota Genuine ATF WS

PP–48PREPARATION – U151F AUTOMATIC TRANSMISSION
PP
SSM
Toyota Genuine Seal Packing 1281
Three Bond 1281 or Equivalent-
Toyota Genuine Adhesive 1344
Three Bond 1344 or Equivalent-

PP–52PREPARATION – U140F AUTOMATIC TRANSAXLE
PP
RECOMMENDED TOOLS
09011-12301 Socket Wrench 30 mm -
09031-00030 Pin Punch -
09040-00011 Hexagon Wrench Set -
(09043-20060) Socket Hexagon Wrench 6 -
(09043-20100) Socket Hexagon Wrench 10 -
09042-00010 Torx Socket T30 -
09904-00010 Expander Set -
09905-00012 Snap Ring No.1 Expander -
09905-00013 Snap Ring Pliers -

PREPARATION – U140F AUTOMATIC TRANSAXLEPP–53
PP
EQUIPMENT
Straight edge -
Vernier calipers -
Dial indicator or dial indicator with magnetic base -
Torque wrench -
Feeler gauge -
Plastic-faced hammer -
Press -
Seal packing 2403, THREE BOND 2403 or equivalent -

PP–54PREPARATION – U140F AUTOMATIC TRANSAXLE
PP
LUBRICANT
Automatic transaxle fluid
Dry fill (w/ Warmer)8.1 liters (8.6 US qts, 7.2 Imp. qts) Toyota Genuine ATF WS
Automatic transaxle fluid
Drain and refill (w/ Warmer)3.5 liters (3.7 US qts, 3.1 Imp. qts)
