TOYOTA RAV4 2016 XA40 / 4.G Owners Manual

370
RAV4_OM_OM42A41U_(U)
5-7. “SETUP” menu
Select “List audio” using the “TUNE•SCROLL” knob. The list of regis-
tered portable players will be displayed.
●Connecting the registered portable player to the audio system
Select the name of the portable pl ayer to be connected using the
“TUNE•SCROLL” knob.
Select “Select” using the knob.
● Deleting the registered portable player
Select the name of the portable player to be deleted using the
“TUNE•SCROLL” knob.
Select “Delete” using the knob.
Press (YES).
● Disconnecting the registered portabl e player from the audio system
Select the name of the portable player to be disconnected using
the “TUNE•SCROLL” knob.
Select “Disconnect” using the knob.
Press (YES).
● Selecting the connection method
Select the name of the desired portable player using the
“TUNE•SCROLL” knob.
Select “Connection Method” using the knob.
Select “From vehicle” or “From audio” using the knob.
Listing the registered portable players
1
2
1
2
3
1
2
3
1
2
3

RAV4_OM_OM42A41U_(U)
3715-7. “SETUP” menu
5
Audio system
Select “Passkey” using the “TUNE•SCROLL” knob.
Select a 4 to 8-digit passkey using the knob.
Input the number 1 digit at a time.
When the entire number to be registered as a passkey has been
input, press (ENTER).
If the passkey to be registered has 8 digits, pressing (ENTER) is not
necessary.
If “BT power” is set to on, the registered device will be connected
automatically when the engine switch is turned to the “ACC” position
(vehicles without smart key syst em) or ACCESSORY mode (vehicles
with smart key system).
Select “BT Power” using the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Bluetooth
* info” using the “TUNE•SCROLL” knob.
● Displaying the device name
Select “Device name” using the “TUNE•SCROLL” knob.
● Displaying the device address
Select “Device address” using the “TUNE•SCROLL” knob.
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Changing the passkey
Setting automatic connection of the device on or off
Displaying the device status
1
2
3
1
2

372
RAV4_OM_OM42A41U_(U)
5-7. “SETUP” menu
If the “Display setting” is set to on, the portable player connection sta-
tus will be displayed when the engine sw itch is turned to the “ACC” or
“ON” position (vehicles without sm art key system) or ACCESSORY or
IGNITION ON mode (vehicles with smart key system).
Select “Display setting” us ing the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Initialize” using the “TUNE•SCROLL” knob.
● Initializing the sound settings
Select “Sound setting” using the “TUNE•SCROLL” knob and press
(YES).
For details about sound settings: →P. 373
●Initializing the device information
Select “Car device info” using the “TUNE•SCROLL” knob and press
(YES).
Automatic connection of a portable device, automatic connection confirma-
tion display and the passkey will be initialized.
● Initializing all the settings
Select “All initialize” using the “TUNE•SCROLL” knob and press
(YES).
■The number of Bluetooth® device that can be registered
Up to 5 Bluetooth® device can be registered in the system.
■ Bluetooth
® audio/phone system functions
Certain functions may not be available during driving.
Setting the automatic connection confirmation display to on or off
Initialization
1
2

373
RAV4_OM_OM42A41U_(U)
5-7. “SETUP” menu
5
Audio system
Using the “SETUP” menu (“PHONE” menu)∗
■Functions and operation procedures
To enter the menu for each function, press the “SETUP” button and
follow the steps below using the “TUNE•SCROLL” knob:
●Adding a new phone number
1. “PHONE” → 2. “Phonebook” → 3. “Add contacts”
● Setting speed dials
1. “PHONE” → 2. “Phonebook” → 3. “Add SD”
● Deleting call histories
1. “PHONE” → 2. “Phonebook” → 3. “Delete call history”
● Deleting a registered phone number
1. “PHONE” → 2. “Phonebook” → 3. “Delete contacts”
● Deleting another cellular phone’s phonebook
1. “PHONE” → 2. “Phonebook” → 3. “Delete other PB”
● Setting call volume
1. “PHONE” → 2. “HF sound setting” → 3. “Call volume”
● Setting ring tone volume
1. “PHONE” → 2. “HF sound setting” → 3. “Ringtone volume”
● Setting ring tone
1. “PHONE” → 2. “HF sound setting” → 3. “Ringtone”
● Transferring call histories
1. “PHONE” → 2. “Transfer histories”
● Setting automatic transferring of the phonebook
1. “PHONE” → 2. “Auto transfer”
∗: If equipped

374
RAV4_OM_OM42A41U_(U)
5-7. “SETUP” menu
Select “Add contacts” using the “TUNE•SCROLL” knob.
● Transferring all contacts from the cellular phone
Select “Overwrite all” using th e “TUNE•SCROLL” knob and press
(YES).
● Transferring one contact from the cellular phone
Select “Add one contact” using the “TUNE•SCROLL” knob and
press (YES).
Select “Add SD” using the “TUNE•SCROLL” knob.
Select the desired data using the knob.
Press the desired preset butt on (from [1] to [5]).
For details about setting speed dials from the call history: →P. 382
For details about deleting speed dials: →P. 3 8 1
Adding a new phone number
Setting speed dials
1
2
3

RAV4_OM_OM42A41U_(U)
3755-7. “SETUP” menu
5
Audio system
Select “Delete call history” using the “TUNE•SCROLL” knob.
●Deleting outgoing call history
Select “Outgoing calls” using the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all outgoing call history data, press (ALL) and then
press (YES).
● Deleting incoming call history
Select “Incoming calls” us ing the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all incoming call history data, press (ALL) and then
press (YES).
● Deleting missed call history
Select “Missed calls” usi ng the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all missed call history data, press (ALL) and then
press (YES).
● Deleting a number from all call histories (Outgoing calls, Incoming
calls and Missed calls)
Select “All calls” using the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all of the call histories data, press (ALL) and then
press (YES).
Deleting call histories
1
2
1
2
1
2
1
2

376
RAV4_OM_OM42A41U_(U)
5-7. “SETUP” menu
Select “Delete contacts” using the “TUNE•SCROLL” knob.
Select the desired phone number using the knob and press
(YES).
To delete all the registered phone numbers, press (ALL) and then
press (YES).
Press (A-Z) to display the regi stered names in alphabetical order
of the initial.
Select “Delete other PB” using the “TUNE•SCROLL” knob.
Select the desired phonebook using the knob and press (YES).
Select “Auto transfer” usi ng the “TUNE•SCROLL” knob.
Select “ON” or “OFF” using the knob.
Select “Call volume” using the “TUNE•SCROLL” knob.
Change the call volume.
To decrease the volume: Turn the knob counterclockwise.
To increase the volume: Turn the knob clockwise.
To set the volume, press (SAVE).
Select “Ringtone volume” using the “TUNE•SCROLL” knob.
Change the ring tone volume.
To decrease the volume: Turn the knob counterclockwise.
To increase the volume: Turn the knob clockwise.
To set the volume, press (SAVE).
Deleting a registered phone number
Deleting another cellular phone’s phonebook
Setting automatic transferring of the phonebook on or off
Setting call volume
Setting ring tone volume
1
2
1
2
1
2
1
2
1
2

RAV4_OM_OM42A41U_(U)
3775-7. “SETUP” menu
5
Audio system
Select “Ringtone” using the “TUNE•SCROLL” knob.
Using the knob, select a ring tone (1 - 3). To set the selected ring
tone, press (SAVE).
Select “Transfer histories” usi ng the “TUNE•SCROLL” knob and press
(YES).
■ Phone number
Up to 1000 names can be stored.
■ Call history
Up to 10 numbers can be stored in each of the outgoing, incoming and
missed call history memories.
■ Limitation of number of digits
A phone number that exceeds 24 digits cannot be registered.
■ Bluetooth
® phone system functions
Certain functions may not be available during driving.
Setting ring tone
Transferring call histories
1
2

378
RAV4_OM_OM42A41U_(U)
5-8. Bluetooth® Audio
Operating a Bluetooth® enabled portable
player
∗
∗: If equipped
Power
Vo l u m e
Search playback
Next commands, random play
or back button
Repeat play
Fast-forwarding, rewinding or
selecting an album Changing the audio source/
playback
Playback/pause
Previous commands
Selecting a track
Displaying text message1
2
3
4
5
6
7
8
9
10
11

RAV4_OM_OM42A41U_(U)
3795-8. Bluetooth® Audio
5
Audio system
Press () to select desired album.
Press (MORE>) to display the commands.
Press and hold the “SCAN” button until you hear a beep.
The first 10 seconds of the first track in each album will be played.
To cancel, press the button again.
When the desired album is reached, press the button again.
Press “ ∧” or “∨ ” on the “SEEK/TRACK” butt on to select the desired
track.
Press the “SCAN” button.
The first 10 seconds of each track will be played.
To cancel, press the button again.
When the desired track is reac hed, press the button again.
Press ( ) or ( ).
Press ( Pressing (RPT) changes modes in the following order:
Track repeat →Album repeat →Off.
Press (MORE>) to display the command.
Pressing (RDM) changes modes in the following order:
Album random →All track random →Off.
Press (MORE>) to display the command.
Selecting an album
Scanning an album
Selecting a track
Scanning the tracks in an album
Fast-forwarding and rewinding tracks
Repeat play
Random play
1
2
1
2
