TOYOTA RAV4 2018 Owners Manual (in English)

RAV4_OM_OM0R012U_(U)
4815-22. Bluetooth®
5
Audio system
WARNING
■While driving
Do not operate the portable audio play er, cellular phone or connect a device
to the Bluetooth
® system.
■ Caution regarding interfer ence with electronic devices
● Your audio unit is fitted with Bluetooth
® antennas. People with implantable
cardiac pacemakers, cardiac resynchronization therapy-pacemakers or
implantable cardioverter defibrillators should maintain a reasonable dis-
tance between themselves and the Bluetooth
® antennas. The radio waves
may affect the operation of such devices.
● Before using Bluetooth
® devices, users of any electrical medical device
other than implantable cardiac pacemakers, cardiac resynchronization
therapy-pacemakers or implantable cardioverter defibrillators should con\
-
sult the manufacturer of the device for information about its operation
under the influence of radio waves. Radio waves could have unexpected
effects on the operation of such medical devices.
NOTICE
■ When leaving the vehicle
Do not leave your portable audio player or cellular phone in the vehicle. The
inside of the vehicle may become hot, causing damage to the portable
audio player or cellular phone.

482
RAV4_OM_OM0R012U_(U)
5-23. Other function
Voice command system
Press the talk switch.Select to train voice recogni-
tion.
Select to start the voice rec-
ognition tutorial.
Select “OK” and say the desired command.
On the list screen, you can select the desired command.
To cancel the voice command system, press and hold the talk switch.
The voice command system enables the hands-free system to
be operated using voice commands.
Using the voice command system
1
1
2
2

RAV4_OM_OM0R012U_(U)
4835-23. Other function
5
Audio system
■Microphone
→P. 446
■ When using the microphone
●It is unnecessary to speak directly into the microphone when giving a com-
mand.
● When “Voice Prompt Interrupt” is set on, it is not necessary to wait for the
confirmation beep before speaking a command. ( →P. 406)
● Voice commands may not be recognized if:
• They are spoken too quickly.
• They are spoken at a low or high volume.
• The roof or windows are open.
• Passengers are talking while voice commands are spoken.
• The air conditioning speed is set high.
• The air conditioning vents are turned towards the microphone.
● In the following conditions, the system may not recognize the command
properly and using voice commands may not be possible:
• The command is incorrect or unclear. Note that certain words, accents or
speech patterns may be difficult for the system to recognize.
• There is excessive background noise, such as wind noise.
Due to natural language speech recognition technology, this system
enables recognition of a command when spoken naturally. However,
the system cannot recognize ev ery variation of each command.
In some situations, it is possibl e to omit the command for the proce-
dure and directly state the desired operation.
Not all voice commands are displayed in the shortcut menu.
This function is available in English, Spanish and French.
■Expression examples for each function
Casual speech recognization
CommandExpression examples
“Call
”Get me .
I need to call at right away.
“Dial ”Please dial the number <3334445555>.
Ring <3334445555>.

484
RAV4_OM_OM0R012U_(U)
5-23. Other function
Some recognizable voice commands and their actions are shown
below as examples.
Basic
Phone
Command list
CommandAction
“Help”Prompts voice guidance to offer examples of com-
mands or operation methods
“Go Back”Returns to the previous screen
CommandAction
“Redial”Places a call to the phone number of the latest outgo-
ing call
“Call Back”Places a call to the phone number of latest incoming
call
“Show Recent
Calls”Displays the call history screen
“Dial ber>”Places a call to the said phone number
“Call
”Places a call to the said phone type of the contact
from the phone book

RAV4_OM_OM0R012U_(U)
4855-23. Other function
5
Audio system
The Mobile Assistant feature will activate Apple’s Siri® Eyes Free
mode via the steering wheel switc hes. To operate the Mobile Assis-
tant, a compatible cellular phone must be registered and connected to
this system via Bluetooth
®. ( → P. 438)
Press and hold the until
you hear the beeps.
The Mobile Assistant can be
used only when the following
screen is displayed.
To cancel the Mobile Assistant,
select “Cancel”, or press and hold
the on the steering wheel.
To restart the Mobile Assistant for
additional commands, press the on the steering wheel.
• Mobile Assistant can only be restarted after the system responds to a voice command.
• After some phone and music commands, the Mobile Assistant feature will automatically end to complete the requested action.
■
Adjusting the Mobile Assistant volume
The volume of the Mobile Assistant can be adjusted using the
“PWR/VOL” knob or steering wheel volume control switches. The
Mobile Assistant and phone call volumes are synchronized.
Mobile Assistant
1
2

486
RAV4_OM_OM0R012U_(U)
5-23. Other function
■Notes about Mobile Assistant
●The available features and functions may vary based on the iOS version
installed on the connected device.
● Some Siri
® features are limited in Eyes Free mode. If you attempt to use an
unavailable function, Siri® will inform you that the function is not available.
● If Siri
® is not enabled on the cellular phone connected via Bluetooth®, an
error message will be displayed on the screen.
● While a phone call is active, the Mobile Assistant cannot be used.
● If using the navigation feature of the cellular phone, ensure the active audio
source is Bluetooth
® audio or iPod in order to hear turn by turn direction
prompts.

487
RAV4_OM_OM0R012U_(U)
6Interior features
6-1. Using the air conditioning system and defogger
Manual air conditioning system ............................ 488
Automatic air conditioning system ... 494
Heated steering wheel/ seat heaters .................... 503
6-2. Using the interior lights Interior lights list ................ 505• Interior lights ................. 506
• Personal lights .............. 506
6-3. Using the storage features List of storage features ..... 508• Glove box...................... 509
• Console box .................. 509
• Cup holders .................. 510
• Bottle holders ................ 511
• Auxiliary box ................. 511
Luggage compartment features ........................... 512
6-4. Using the other interior features
Other interior features ....... 523 • Sun visors .................... 523
• Vanity mirrors ............... 523
• Power outlets ................ 524
• Armrest ......................... 526
• Coat hooks.................... 526
• Assist grips .................. 527
Garage door opener.......... 528
Compass ........................... 535

488
RAV4_OM_OM0R012U_(U)
6-1. Using the air conditioning system and defogger
Manual air conditioning system∗
■Adjusting the temperature setting
Turn the temperature control dial clockwise (warm) or counterclock-
wise (cool).
If the “A/C” button is not pressed, the system will blow ambient tempera-
ture air or heated air.
■
Adjusting the fan speed setting
Turn the fan speed control dial clockwise (increase) or counter-
clockwise (decrease).
Turning the dial to “0” turns off the fan.
∗: If equipped
Control panel

RAV4_OM_OM0R012U_(U)
4896-1. Using the air conditioning system and defogger
6
Interior features
■Changing the air flow mode
Turn the air outlet selector dial
to change the airflow mode.
The positions between the air
outlet selections can also be
selected for more delicate
adjustment.
Air flows to the upper body.
Air flows to the upper body
and feet.
Air flows to the feet.
Air flows to the feet and the windshield defogger operates.
■Switching between outside air and recirculated air modes
Press .
The mode switches between outside air mode (indicator off) and recir-
culated air mode (indicator on) each time is pressed.
■
Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.
Turn the air outlet selector dial to position.
Set the outside/recirculated air mode button to outside air mode if recir-
culated air mode is used.
Adjust the fan speed and temperature setting.( →P. 488)
If the dehumidification function is not operating, press the “A/C” but-
ton to operate the dehumi dification function.
To defog the windshield and the side windows early, turn the air flow and
temperature up.
1
2
Other functions
3
4

490
RAV4_OM_OM0R012U_(U)
6-1. Using the air conditioning system and defogger
■Defogging the rear window and out side rear view mirrors (if
equipped)
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.
Press .
The defoggers will automatically turn off after a period of time.
■
Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the wind-
shield and wiper blades.
Press the switch to turn the sys-
tem on/off.
The indicator comes on when
the system is on.
The windshield wiper de-icer will
automatically turn off after a
period of time.
■
Location of air outlets
The air outlets and air volume
changes according to the
selected air flow mode.
Air outlets
